Basic information Technical Specifications Gallery

Mercedes-Benz G

Date of manufacture

2018 – to this day (Large SUV)

Platform

Manufacturing locations

Graz, Austria

Designer

Car body style

Large SUV

Date of manufacture

2018 – to this day

Internal designation

W463 II

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Large SUV

	G 500	G 63 AMG	G 350d	G 400d
Date of sale	-	-	from 2019 to	from 2019 to
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	8/32	8/32	4/24	6/24
Engine displacement [cm³]	3982	3982	2925	2925
Maximum output / speed [kW/min-1]	310/5250-5500	430/6000	210/4600	243/3600-4200
Maximum torque [Nm/min-1]	610/2250-4750	850/2500-3500	600/1200-3200	700/1200-3200
Bore and stroke [mm x mm]	83,0 x 92,0	83,0 x 92,0	82.0 x 92.3	82.0 x 92.3
Compression ratio	10.5:1	8.6:1	15.5:1	15.5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection BlueDIRECT supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves CAMTRONIC automatic four-cylinder shutdown Gasoline Particulate Filter start&stop system	direct injection BlueDIRECT supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves CAMTRONIC automatic four-cylinder shutdown Gasoline Particulate Filter start&stop system	direct injection Common Rail supercharging by twin turbochargers with variable blade geometry variable intake valve timing and lift CAMTRONIC particulate filter SCR catalytic converter with AdBlue additive injection start&stop system	direct injection Common Rail supercharging by twin turbochargers with variable blade geometry variable intake valve timing and lift CAMTRONIC particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	4x4	4x4	4x4	4x4
Gearbox	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic
Drive specifications	permanent all-wheel drive nine-speed automatic gearbox 9G-TRONIC	permanent all-wheel drive nine-speed automatic gearbox AMG SPEEDSHIFT TCT	permanent all-wheel drive nine-speed automatic gearbox 9G-TRONIC	permanent all-wheel drive nine-speed automatic gearbox 9G-TRONIC

Top speed [km/h]	210	220	199	210
Acceleration 0–100 km/h [s]	5.9	4.5	7.4	6.4
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	15.4-13.4	17.1-16.5	11.0-9.9	10.8-9.9
Out of town [l]	11.8-10.3	12.9-11.1	9.2-7.9	8.9-7.9
Combined [l]	13.2-11.5	14.4-13.1	9.8-8.7	9.6-8.7
CO2 emissions [g/km]	301-263	330-299	259-229	253-229

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	2470	2560	2489	2489
Overall weight [kg]	3150	3200	3150	3150
Maximum trailer weight unbraked/braked [kg]	750/3500	750/3500	750/3500	750/3500
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	140	140	140	140
Maximum load on roof/carrier [kg]	150/-	150/-	150/-	150/-

Boot volume [l]	667	667	667	667
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1941	-/1941	-/1941	-/1941
Boot length [mm]	758	758	758	758
Boot length with rear seats folded [mm]	1740	1740	1740	1740
Boot width between wheels/max [mm]	1077/-	1077/-	1077/-	1077/-
Boot height to headliner/ceiling [mm]	-/1124	-/1124	-/1124	-/1124
Loading edge height [mm]	754	754	754	754
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	1046	1046	1046	1046
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	100	100	100	100
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.54	0.55	0.54	0.54
Front suspension	double wishbone	four-link	double wishbone	double wishbone
Rear suspension	rigid, coil springs	five-link	rigid, coil springs	rigid, coil springs
Tyre dimensions front	265/60 R18 110H	275/50 R20 113W XL	265/60 R18 110H	265/60 R18 110H
Tyre dimensions rear	265/60 R18 110H	275/50 R20 113W XL	265/60 R18 110H	265/60 R18 110H
Wheel size front	7.5J x 18	9.5J x 20	7.5J x 18	7.5J x 18
Wheel size rear	7.5J x 18	9.5J x 20	7.5J x 18	7.5J x 18
Brake dimensions front	-	400	-	-
Brake dimensions rear	-	370	-	-
Steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	13.6/-	13.51/-	13.6/-	13.6/-

Overall length [mm]	4817	4881	4817	4817
Overall width without/including mirrors [mm]	1931/2187	1984/2187	1931/2187	1931/2187
Overall height [mm]	1969	1969	1969	1969
Wheelbase [mm]	2890	2890	2890	2890
Front wheel track [mm]	1638	1654	1638	1638
Rear wheel track [mm]	1638	1654	1638	1638
Forward overhang [mm]	877	884	877	877
Rear overhang [mm]	839	847	839	839
Clearance [mm]	241	266	241	241
Wading depth [mm]	700	700	700	700
Approach angle front [°]	30.9	26.7	30.9	30.9
Approach angle rear [°]	29.9	29.2	29.9	29.9
Transition angle [°]	25.7	24.5	25.7	25.7
Climbing rate [°]	45.0	45.0	45.0	45.0
Maximum side tilt [°]	35.0	35.0	35.0	35.0

Headroom front [mm]	1027	1027	1027	1027
Headroom rear [mm]	1028	1028	1028	1028
Front elbow/shoulder width [mm]	1446/1518	1446/1518	1446/1518	1446/1518
Rear elbow/shoulder width [mm]	1452/1508	1452/1508	1452/1508	1452/1508
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
