	G 500 4MATIC	G 500 4x4² 4MATIC	G 63 AMG 4MATIC	G 65 AMG 4MATIC
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	8/32	8/32	8/32	12/36
Engine displacement [cm³]	3982	3982	5461	5980
Maximum output / speed [kW/min-1]	310/5250-5500	310/5250-5500	420/5500	463/5000-5300
Maximum torque [Nm/min-1]	610/2250-4750	610/2250-4750	760/1750-5000	1000/2300-4300
Bore and stroke [mm x mm]	83,0 x 92,0	83,0 x 92,0	98,0 x 90,5	82,6 x 93,0
Compression ratio	10,5:1	10,5:1	10,0:1	9,0:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection BlueDIRECT supercharging by twin turbochargers variable timing of intake and exhaust valves start&stop system	direct injection BlueDIRECT supercharging by twin turbochargers variable timing of intake and exhaust valves start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	supercharging by twin turbochargers variable valve timing

Drive axle	4x4	4x4	4x4	4x4
Gearbox	7 gear automatic	7 gear automatic	7 gear automatic	7 gear automatic
Drive specifications	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC	permanent all-wheel drive 4MATIC automatic gearbox AMG SPEEDSHIFT PLUS 7G‐TRONIC	permanent all-wheel drive 4MATIC automatic gearbox AMG SPEEDSHIFT PLUS 7G‐TRONIC

Top speed [km/h]	210	210	210	230
Acceleration 0–100 km/h [s]	5.9	7.4	5.4	5.3
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	14.5	16.3	17.2	22.7
Out of town [l]	11.0	12.3	11.8	13.7
Combined [l]	12.3	13.8	13.8	17.0
CO2 emissions [g/km]	289	323	322	397

Emission standard	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	2595	3021	2550	2580
Overall weight [kg]	3200	3490	3200	3200
Maximum trailer weight unbraked/braked [kg]	750/3500	-	750/3500	750/3500
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	200/-	-	200/-	200/-

Boot volume [l]	480	480	480	480
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2250	-/2250	-/2250	-/2250
Boot length [mm]	750	750	750	750
Boot length with rear seats folded [mm]	1720	1720	1720	1720
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-/1182	-/1182	-/1182	-/1182
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	4	4	4	4
Number of seats	5	5	5	5
Fuel tank volume [l]	96	96	96	96
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.54	-	0.54	0.54
Front suspension	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar
Rear suspension	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar
Tyre dimensions front	265/60 R18	325/55 R222	275/50 R20	275/50 R20
Tyre dimensions rear	265/60 R18	325/55 R222	275/50 R20	275/50 R20
Wheel size front	7.5J x 18 ET63	9.5J x 22	9.5J x 20 ET50	9.5J x 20 ET50
Wheel size rear	7.5J x 18 ET63	9.5J x 22	9.5J x 20 ET50	9.5J x 20 ET50
Brake dimensions front	-	380 x 36	375 x 36	375 x 36
Brake dimensions rear	-	370 x 18	330 x 22	330 x 22
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	13.6/-	14.3/-	13.6/-	13.6/-

Overall length [mm]	4764	4500	4764	4764
Overall width without/including mirrors [mm]	1867/-	-/2100	1867/-	1867/-
Overall height [mm]	1954	2235	1954	1954
Wheelbase [mm]	2850	2850	2850	2850
Front wheel track [mm]	1515	1774	1515	1515
Rear wheel track [mm]	1515	1774	1515	1515
Forward overhang [mm]	783	830	-	-
Rear overhang [mm]	820	820	-	-
Clearance [mm]	235	438	220	220
Wading depth [mm]	600	1000	600	600
Approach angle front [°]	29	52	27	27
Approach angle rear [°]	28	44	27	27
Transition angle [°]	24	47	24	24
Climbing rate [°]	100	100	80	80
Maximum side tilt [°]	54	47	54	54

Headroom front [mm]	1072	1072	1072	1072
Headroom rear [mm]	1015	1015	1015	1015
Front elbow/shoulder width [mm]	1430/1450	1430/1450	1430/1450	1430/1450
Rear elbow/shoulder width [mm]	1430/1452	1430/1452	1430/1452	1430/1452
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

	G 350 BlueTEC 4MATIC
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	6/24
Engine displacement [cm³]	2987
Maximum output / speed [kW/min-1]	180/3600
Maximum torque [Nm/min-1]	600/1600-2400
Bore and stroke [mm x mm]	83,0 x 92,0
Compression ratio	15,5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	4x4
Gearbox	7 gear automatic
Drive specifications	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC

Top speed [km/h]	192
Acceleration 0–100 km/h [s]	8.8
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	11.1
Out of town [l]	9.1
Combined [l]	9.9
CO2 emissions [g/km]	261

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	2612
Overall weight [kg]	3200
Maximum trailer weight unbraked/braked [kg]	750/3500
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	200/-

Boot volume [l]	480
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2250
Boot length [mm]	750
Boot length with rear seats folded [mm]	1720
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-/1182
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	4
Number of seats	5
Fuel tank volume [l]	96
AdBlue tank volume [l]	-
Air resistance [Cd]	0.54
Front suspension	rigid with trailing arms and torsion bar
Rear suspension	rigid with trailing arms and torsion bar
Tyre dimensions front	265/60 R18
Tyre dimensions rear	265/60 R18
Wheel size front	7.5 J x 18 ET43
Wheel size rear	7.5 J x 18 ET43
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	13.6/-

Overall length [mm]	4764
Overall width without/including mirrors [mm]	1867/-
Overall height [mm]	1954
Wheelbase [mm]	2850
Front wheel track [mm]	1515
Rear wheel track [mm]	1515
Forward overhang [mm]	783
Rear overhang [mm]	820
Clearance [mm]	235
Wading depth [mm]	600
Approach angle front [°]	29
Approach angle rear [°]	28
Transition angle [°]	24
Climbing rate [°]	100
Maximum side tilt [°]	54

Headroom front [mm]	1072
Headroom rear [mm]	1015
Front elbow/shoulder width [mm]	1430/1450
Rear elbow/shoulder width [mm]	1430/1452
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
