	CL 500	CL 500	CL 600	CL 63 AMG	CL 65 AMG
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Petrol	Ignition supercharged
Number of cylinders/valves	8/32	8/32	12/36	8/32	12/36
Engine displacement [cm³]	5461	5461	5513	6208	5980
Maximum output / speed [kW/min-1]	285/6000	285/6000	380/5000	386/6800	450/4800
Maximum torque [Nm/min-1]	530/2800-4800	530/2800-4800	830/1900-3500	630/5200	1000/2000-4000
Bore and stroke [mm x mm]	98,0 x 90,5	98,0 x 90,5	82,0 x 87,0	102,2 x 94,6	82,6 x 93,0
Compression ratio	10,7:1	10,7:1	9,0:1	11,3:1	9,0:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves	variable timing of intake and exhaust valves	supercharging by twin turbochargers	variable timing of intake and exhaust valves	supercharging by twin turbochargers

Drive axle	Rear	4x4	Rear	Rear	Rear
Gearbox	7 gear automatic	7 gear automatic	5 gear automatic	7 gear automatic	5 gear automatic
Drive specifications	automatic gearbox 7G‐TRONIC	all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC	automatic gearbox	automatic gearbox AMG SPEEDSHIFT 7G‐TRONIC	automatic gearbox AMG SPEEDSHIFT

Top speed [km/h]	250	250	250	250	250
Acceleration 0–100 km/h [s]	5.4	5.4	4.6	4.6	4.4
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	18.1	18.1	21.7	23.2	23.1
Out of town [l]	8.5	8.5	10.0	10.2	10.0
Combined [l]	12.1	12.1	14.3	14.9	14.8
CO2 emissions [g/km]	288	288	340	355	355

Emission standard	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1995	2045	2185	2085	2240
Overall weight [kg]	2510	2510	2510	2510	2635
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	490	490	490	490	490
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	2	2	2	2	2
Number of seats	4	4	4	4	4
Fuel tank volume [l]	90	90	90	90	90
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.27	0.28	0.28	0.27	0.28
Front suspension	four-link	four-link	four-link	four-link	four-link
Rear suspension	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	235/55 R17 W	225/45 R18 Y	255/45 R18 Y	225/40 R19 Y	255/35 R20 Y
Tyre dimensions rear	235/55 R17 W	225/45 R18 Y	275/45 R18 Y	275/40 R 19 Y	275/35 R20 Y
Wheel size front	8.0J x 17 ET 43	8.5J x 18 ET 43	8.5J x 18 ET43	8.5 J x 19 ET 43	8.5J x 20 ET43
Wheel size rear	8.0J x 17 ET 43	8.5J x 18 ET 43	9.5J x 18 ET43	9.5 J x 19 ET 43	9.5J x 20 ET43
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	11.63/-	11.63/-	11.63/-	11.63/-	11.63/-

Overall length [mm]	5065	5065	5065	5065	5065
Overall width without/including mirrors [mm]	1871/2130	1871/2130	1871/2130	1871/2130	1871/2130
Overall height [mm]	1419	1419	1419	1419	1419
Wheelbase [mm]	2955	2955	2955	2955	2955
Front wheel track [mm]	1601	1601	1601	1601	1601
Rear wheel track [mm]	1607	1607	1607	1607	1607
Forward overhang [mm]	917	917	917	917	917
Rear overhang [mm]	1193	1193	1193	1193	1193
Clearance [mm]	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	936	936	936	936	936
Headroom rear [mm]	925	925	925	925	925
Front elbow/shoulder width [mm]	1505/1575	1505/1575	1505/1575	1505/1575	1505/1575
Rear elbow/shoulder width [mm]	1403/1422	1403/1422	1403/1422	1403/1422	1403/1422
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Mercedes-Benz CL AMG C216 2007 front seats

Mercedes-Benz CL AMG C216 2008 rear seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
