Mercedes-Benz B
Date of manufacture
3/2005 – 2008 (MPV)
Platform
-
Manufacturing locations
Rastatt, Germany
Designer
-
Tags
Small MPV
German cars
The Mercedes-Benz B is a luxury MPV that has been produced since 2005. It is made in Germany and offers both petrol and diesel engines. The most powerful model is the B 200 Turbo with 142 kW, it has a top speed of 225 km/h and accelerates from 0-100 km/h in 7.4 seconds. The most economical version, the B 200 CDI, has a fuel consumption of 5.6 l/100 km and CO2 emissions of 146 g/km. The luggage compartment has a volume of 458 l. The Mercedes-Benz B has passed EURONCAP safety tests with a rating of 5 out of 5.
Car body style
Technical data
MPV
| B 150 | B 150 | B 170 | B 170 | B 200 | B 200 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 4/8 | 4/16 | 4/8 | 4/8 | 4/8 | 4/8 |
| Engine displacement [cm³] | 1498 | 1498 | 1699 | 1699 | 2034 | 2034 |
| Maximum output / speed [kW/min-1] | 70/5200 | 70/5200 | 85/5500 | 85/5500 | 100/5500 | 100/5500 |
| Maximum torque [Nm/min-1] | 140/3500-4000 | 140/3500-4000 | 155/3500-4000 | 155/3500-4000 | 185/3500-4000 | 185/3500-4000 |
| Bore and stroke [mm x mm] | 83,0 x 69,2 | 83,0 x 69,2 | 83,0 x 78,5 | 83,0 x 78,5 | 83,0 x 94,0 | 83,0 x 94,0 |
| Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications | - | - | - | - | - | - |
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 1 gear automatic | 5 gear manual | 1 gear automatic | 5 gear manual | 1 gear automatic |
| Drive specifications | - |
| - |
| - |
|
| Top speed [km/h] | 174 | 168 | 184 | 180 | 196 | 190 |
| Acceleration 0–100 km/h [s] | 13.2 | 14.2 | 11.3 | 12.0 | 10.1 | 10.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8.3-8.5 | 8.5-8.7 | 8.6-9.0 | 9.0-9.2 | 9.3-9.6 | 9.5-9.7 |
| Out of town [l] | 5.5-5.8 | 6.0-6.2 | 5.8-6.0 | 6.0-6.2 | 6.0-6.3 | 6.0-6.2 |
| Combined [l] | 6.6-6.8 | 6.9-7.1 | 6.8-7.1 | 7.1-7.3 | 7.2-7.5 | 7.3-7.5 |
| CO2 emissions [g/km] | 158-163 | 166-171 | 163-171 | 171-175 | 173-180 | 175-180 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1300 | 1350 | 1310 | 1360 | 1345 | 1390 |
| Overall weight [kg] | 1835 | 1835 | 1830 | 1830 | 1880 | 1880 |
| Maximum trailer weight unbraked/braked [kg] | 645/1000 | 645/1000 | 645/1300 | 645/1300 | 645/1500 | 645/1500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 458 | 458 | 458 | 458 | 458 | 458 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1530 | -/1530 | -/1530 | -/1530 | -/1530 | -/1530 |
| Boot length [mm] | 898 | 898 | 898 | 898 | 898 | 898 |
| Boot length with rear seats folded [mm] | 1475 | 1475 | 1475 | 1475 | 1475 | 1475 |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | -/920 | -/920 | -/920 | -/920 | -/920 | -/920 |
| Loading edge height [mm] | 621 | 621 | 621 | 621 | 621 | 621 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 850 | 850 | 850 | 850 | 850 | 850 |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 54 | 54 | 54 | 54 | 54 | 54 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle |
| Tyre dimensions front | 195/65 R15 91T | 195/65 R15 91T | 195/65 R15 91T | 195/65 R15 91T | 205/55 R16 91H | 205/55 R16 91H |
| Tyre dimensions rear | 195/65 R15 91T | 195/65 R15 91T | 195/65 R15 91T | 195/65 R15 91T | 205/55 R16 91H | 205/55 R16 91H |
| Wheel size front | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | 276 x 12 | 276 x 12 | 276 x 22 | 276 x 22 | 276 x 22 | 276 x 22 |
| Brake dimensions rear | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/11.95 | -/11.95 | -/11.95 | -/11.95 | -/11.95 | -/11.95 |
| Overall length [mm] | 4270 | 4270 | 4270 | 4270 | 4270 | 4270 |
| Overall width without/including mirrors [mm] | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 |
| Overall height [mm] | 1603 | 1603 | 1603 | 1603 | 1603 | 1603 |
| Wheelbase [mm] | 2778 | 2778 | 2778 | 2778 | 2778 | 2778 |
| Front wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Rear wheel track [mm] | 1551 | 1551 | 1551 | 1551 | 1551 | 1551 |
| Forward overhang [mm] | 842 | 842 | 842 | 842 | 842 | 842 |
| Rear overhang [mm] | 650 | 650 | 650 | 650 | 650 | 650 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 989 | 989 | 989 | 989 | 989 | 989 |
| Headroom rear [mm] | 980 | 980 | 980 | 980 | 980 | 980 |
| Front elbow/shoulder width [mm] | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 |
| Rear elbow/shoulder width [mm] | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| B 200 Turbo | B 200 Turbo | B 180 CDI | B 180 CDI | B 200 CDI | B 200 CDI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/8 | 4/8 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2034 | 2034 | 1991 | 1991 | 1991 | 1991 |
| Maximum output / speed [kW/min-1] | 142/5000 | 142/5000 | 85/4200 | 85/4200 | 103/4200 | 103/4200 |
| Maximum torque [Nm/min-1] | 280/1800-4850 | 280/1800-4850 | 250/1600-2600 | 250/1600-2600 | 300/1600-3000 | 300/1600-3000 |
| Bore and stroke [mm x mm] | 83,0 x 94,0 | 83,0 x 94,0 | 83,0 x 92,0 | 83,0 x 92,0 | 83,0 x 83,0 | 83,0 x 83,0 |
| Compression ratio | 9,0:1 | 9,0:1 | 18,0:1 | 18,0:1 | 18,0:1 | 18,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 1 gear automatic | 6 gear manual | 1 gear automatic | 1 gear automatic | 6 gear manual |
| Drive specifications | - |
| - |
|
| - |
| Top speed [km/h] | 225 | 218 | 183 | 178 | 195 | 200 |
| Acceleration 0–100 km/h [s] | 7.6 | 7.4 | 11.3 | 11.8 | 9.7 | 9.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 10.5-11.0 | 10.5-10.7 | 7.2-7.6 | 7.3-7.9 | 7.6-8.0 | 7.2-7.6 |
| Out of town [l] | 6.4-6.6 | 6.7-6.8 | 4.6-4.7 | 4.9-5.3 | 5.0-5.3 | 4.6-4.7 |
| Combined [l] | 7.9-8.1 | 8.1-8.2 | 5.6-5.8 | 5.9-6.2 | 6.0-6.3 | 5.6-5.8 |
| CO2 emissions [g/km] | 190-197 | 195-197 | 146-151 | 157-164 | 159-165 | 146-151 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1370 | 1405 | 1435 | 1470 | 1470 | 1435 |
| Overall weight [kg] | 1880 | 1880 | 1880 | 1880 | 1880 | 1880 |
| Maximum trailer weight unbraked/braked [kg] | 645/1500 | 645/1500 | 715/1500 | 715/1500 | 715/1500 | 715/1500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 458 | 458 | 458 | 458 | 458 | 458 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1530 | -/1530 | -/1530 | -/1530 | -/1530 | -/1530 |
| Boot length [mm] | 898 | 898 | 898 | 898 | 898 | 898 |
| Boot length with rear seats folded [mm] | 1475 | 1475 | 1475 | 1475 | 1475 | 1475 |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | -/920 | -/920 | -/920 | -/920 | -/920 | -/920 |
| Loading edge height [mm] | 621 | 621 | 621 | 621 | 621 | 621 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 850 | 850 | 850 | 850 | 850 | 850 |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 54 | 54 | 54 | 54 | 54 | 54 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.3 | 0.3 | 0.3 | 0.3 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle | parabolic rear axle |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | 288 x 25 | 288 x 25 | 288 x 25 | 288 x 25 | 288 x 25 | 288 x 25 |
| Brake dimensions rear | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 | 258 x 8 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/11.95 | -/11.95 | -/11.95 | -/11.95 | -/11.95 | -/11.95 |
| Overall length [mm] | 4270 | 4270 | 4270 | 4270 | 4270 | 4270 |
| Overall width without/including mirrors [mm] | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 | 1777/2040 |
| Overall height [mm] | 1603 | 1603 | 1603 | 1603 | 1603 | 1603 |
| Wheelbase [mm] | 2778 | 2778 | 2778 | 2778 | 2778 | 2778 |
| Front wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Rear wheel track [mm] | 1551 | 1551 | 1551 | 1551 | 1551 | 1551 |
| Forward overhang [mm] | 842 | 842 | 842 | 842 | 842 | 842 |
| Rear overhang [mm] | 650 | 650 | 650 | 650 | 650 | 650 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 989 | 989 | 989 | 989 | 989 | 989 |
| Headroom rear [mm] | 980 | 980 | 980 | 980 | 980 | 980 |
| Front elbow/shoulder width [mm] | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 | 1411/1422 |
| Rear elbow/shoulder width [mm] | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 | 1382/1446 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Gallery
