	AMG GT 43	AMG GT 43 4MATIC	AMG GT 53 4MATIC	AMG GT 63 4MATIC	AMG GT 63 S 4MATIC
Date of sale	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	6/24	6/24	6/24	8/32	8/32
Engine displacement [cm³]	2999	2999	2999	3982	3982
Maximum output / speed [kW/min-1]	270/5500-6100 16 el.	270/5500-6100 16 el.	320/6100 16 el.	430/5500-6500	470/5500-6500
Maximum torque [Nm/min-1]	500/1800-4500 250 el.	500/1800-4500 250 el.	520/1800-5800 250 el.	800/2350-5000	900/2500-6500
Bore and stroke [mm x mm]	83.0 x 92.4	83.0 x 92.4	83.0 x 92.4	83.0 x 92.4	83.0 x 92.4
Compression ratio	10.5:1	10.5:1	10.5:1	8.6:1	8.6:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	Mild Hybrid direct injection starter-generator EQ Boost turbo-supercharged Twin-Scroll electrically driven compressor eZV Gasoline Particulate Filter start&stop system	Mild Hybrid direct injection starter-generator EQ Boost turbo-supercharged Twin-Scroll electrically driven compressor eZV Gasoline Particulate Filter start&stop system	Mild Hybrid direct injection starter-generator EQ Boost turbo-supercharged Twin-Scroll electrically driven compressor eZV Gasoline Particulate Filter start&stop system	direct injection supercharging by twin turbochargers variable timing of intake and exhaust valves CAMTRONIC technology AMG Cylinder Management (shuts down four cylinders if necessary) Gasoline Particulate Filter start&stop system	direct injection supercharging by twin turbochargers variable timing of intake and exhaust valves CAMTRONIC technology AMG Cylinder Management (shuts down four cylinders if necessary) Gasoline Particulate Filter start&stop system

Drive axle	Rear	4x4	4x4	4x4	4x4
Gearbox	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic
Drive specifications	nine-speed automatic gearbox TCT	nine-speed automatic gearbox TCT	nine-speed automatic gearbox TCT	nine-speed automatic gearbox MCT	nine-speed automatic gearbox MCT

Top speed [km/h]	270	270	285	310	315
Acceleration 0–100 km/h [s]	5.0	4.9	4.5	3.4	3.2
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	-	12.3-11.7	12.3-11.7	15.2-15.0	15.2
Out of town [l]	-	8.0-7.7	8.0-7.7	8.9-8.8	8.9
Combined [l]	-	9.4-9.1	9.4-9.1	11.2-11.1	11.3
CO2 emissions [g/km]	-	215-209	215-209	256-252	257

Low speed [l]	-	-	-	-	-
Medium speed [l]	-	-	-	-	-
High speed [l]	-	-	-	-	-
Extra high speed [l]	-	-	-	-	-
Combined speed [l]	10,1 - 9,6	10,3 - 9,8	10,3 - 9,8	13,3 - 12,9	13,3 - 12,9
CO2 emissions [g/km]	230 - 217	235 - 222	235 - 222	302 - 293	302 - 292

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

System voltage [V]	48	48	48	-	-
Battery type and capacity	-	-	-	-	-
Range with fully charged battery [km]	-	-	-	-	-
Charging time	-	-	-	-	-
Number of modules/cells	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-
Charger	-	-	-	-	-

Standby weight [kg]	1980	2040	2045	2105	2135
Overall weight [kg]	2495	2550	2550	2550	2560
Maximum trailer weight unbraked/braked [kg]	750/2100	750/2100	750/2100	750/2100	750/2100
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	456	456	456	456	456
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	2079	2079	2079	2064	2064
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	4	4	4	4	4
Number of seats	5	5	5	5	5
Fuel tank volume [l]	66 or 80	66 or 80	66 or 80	66 or 80	80
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	four-link	four-link	four-link	four-link	four-link
Rear suspension	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	255/45 R19	255/45 R19	255/45 R19	255/45 R19	265/40 R20
Tyre dimensions rear	285/40 R19	285/40 R19	285/40 R19	285/40 R19	295/35 R20
Wheel size front	9.5J x 19	9.5J x 19	9.5J x 19	9.5J x 19	9.5J x 20
Wheel size rear	11J x 19	11J x 19	11J x 19	11J x 19	11 J x 20
Brake dimensions front	360	360	360	390	390
Brake dimensions rear	360	360	360	360	360
Steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	12.6/-	12.6/-	12.6/-	12.6/-	12.6/-

Overall length [mm]	5054	5054	5054	5054	5054
Overall width without/including mirrors [mm]	1953/2069	1953/2069	1953/2069	1953/2069	1953/2069
Overall height [mm]	1442	1442	1442	1442	1442
Wheelbase [mm]	2951	2951	2951	2951	2951
Front wheel track [mm]	1675	1675	1675	1675	1675
Rear wheel track [mm]	1666	1666	1666	1666	1666
Forward overhang [mm]	911	911	911	911	911
Rear overhang [mm]	1192	1192	1192	1192	1192
Clearance [mm]	116	116	116	122	122
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	12.0	12.0	12.0	12.0	12.0
Approach angle rear [°]	12.1	12.1	12.1	14.7	14.7
Transition angle [°]	12.2	12.2	12.2	13.2	13.2
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1036	1036	1036	1036	1036
Headroom rear [mm]	970	970	970	970	970
Front elbow/shoulder width [mm]	1467/1495	1467/1495	1467/1495	1467/1495	1467/1495
Rear elbow/shoulder width [mm]	1452/1488	1452/1488	1452/1488	1452/1488	1452/1488
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
