Mazda CX-3
Date of manufacture
2018 – to this day (Small SUV)
Platform
-
Manufacturing locations
Hiroshima, Japan
Designer
Ikuo Maeda
Tags
Small SUV
Japanese cars
The Mazda CX-3 is a small SUV that was released in 2018. The car is manufactured in Japan and offers both petrol and diesel engines. The highest performance is achieved by the 2.0 SKYACTIV-G 150 AWD with 110 kW and a top speed of 200 km/h. The same model has an acceleration of 0-100 km/h in 8.8 seconds. The most economical variant is the 1.8 SKYACTIV-D 115 with a consumption of 5.2 l/100 km and emissions of 138 g/km. The trunk of the car provides a volume of 350 l. In terms of safety, the car tested in 2015 received a rating of 4 out of 5 according to EURONCAP.
Car body style
Small SUV
after upgrade (facelift)
Date of manufacture
2018 – to this dayInternal designation
DK
Technical data
Small SUV
| 2.0 SKYACTIV-G 120 | 2.0 SKYACTIV-G 120 | 2.0 SKYACTIV-G 120 | 2.0 SKYACTIV-G 120 | 2.0 SKYACTIV-G 150 AWD | 2.0 SKYACTIV-G 150 AWD | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2021 | from to 2021 | from 2021 to | from 2021 to | from to 2021 | from to 2021 |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1998 | 1998 | 1998 | 1998 | 1998 | 1998 |
| Maximum output / speed [kW/min-1] | 89/6000 | 89/6000 | 89/6000 | 89/6000 | 110/6000 | 110/6000 |
| Maximum torque [Nm/min-1] | 207/2800 | 207/2800 | 207/2800 | 207/2800 | 207/2800 | 207/2800 |
| Bore and stroke [mm x mm] | 83,5 x 91,2 | 83,5 x 91,2 | 83,5 x 91,2 | 83,5 x 91,2 | 83,5 x 91,2 | 83,5 x 91,2 |
| Compression ratio | 14,0:1 | 14,0:1 | 14,0:1 | 14,0:1 | 14,0:1 | 14,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications | - |
| - |
|
|
|
| Top speed [km/h] | 192 | 187 | 192 | 187 | 200 | 195 |
| Acceleration 0–100 km/h [s] | 9,0 | 9,9 | 9,1 | 9,9 | 8,8 | 9,7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7,5 | 7,2 | 6.1 | 6.8 | 8,5 | 7,7 |
| Out of town [l] | 5,4 | 5,5 | 4.9 | 5.5 | 6,1 | 6,1 |
| Combined [l] | 6,2 | 6,1 | 5.3 | 6.0 | 7,0 | 6,7 |
| CO2 emissions [g/km] | 141 | 140 | 121 | 136 | 160 | 152 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 6,6 | 7,2 | 6,2 | 7,1 | 7,4 | 8,1 |
| CO2 emissions [g/km] | 149 | 161 | 140 | 160 | 166 | 181 |
| Emission standard | EURO 6d-Temp | EURO 6d-Temp | EURO 6d-Temp | EURO 6d-Temp | EURO 6d-Temp | EURO 6d-Temp |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1259-1310 | 1288-1340 | 1254-1305 | 1269-1340 | 1331-1385 | 1363-1415 |
| Overall weight [kg] | 1692 | 1727 | 1692 | 1727 | 1773 | 1808 |
| Maximum trailer weight unbraked/braked [kg] | 625/1200 | 640/1200 | 625/1200 | 630/1200 | 665/1200 | 680/1200 |
| Maximum front/rear axle load [kg] | 900/867 | 940/862 | 878/814 | 918/809 | 931/915 | 965/918 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 50/- | 50/- | 50/- | 50/- | 50/- | 50/- |
| Boot volume [l] | 350 | 350 | 350 | 350 | 350 | 350 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1260 | -/1260 | -/1260 | -/1260 | -/1260 | -/1260 |
| Boot length [mm] | 800 | 800 | 800 | 800 | 800 | 800 |
| Boot length with rear seats folded [mm] | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | 575/- | 575/- | 575/- | 575/- | 575/- | 575/- |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 882 | 882 | 882 | 882 | 882 | 882 |
| Boot opening width min/max [mm] | -/969 | -/969 | -/969 | -/969 | -/969 | -/969 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 48 | 48 | 48 | 48 | 44 | 44 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/60 R16 | 215/60 R16 | 215/60 R16 | 215/60 R16 | 215/50 R18 | 215/50 R18 |
| Tyre dimensions rear | 215/60 R16 | 215/60 R16 | 215/60 R16 | 215/60 R16 | 215/50 R18 | 215/50 R18 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 295 | 295 | 295 | 295 | 295 | 295 |
| Brake dimensions rear | 281 | 281 | 281 | 281 | 281 | 281 |
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/11.38 | -/11.38 | -/11.38 | -/11.38 | -/11.38 | -/11.38 |
| Overall length [mm] | 4275 | 4275 | 4275 | 4275 | 4275 | 4275 |
| Overall width without/including mirrors [mm] | 1765/2049 | 1765/2049 | 1765/2049 | 1765/2049 | 1765/2049 | 1765/2049 |
| Overall height [mm] | 1535 | 1535 | 1535 | 1535 | 1535 | 1535 |
| Wheelbase [mm] | 2570 | 2570 | 2570 | 2570 | 2570 | 2570 |
| Front wheel track [mm] | 1525 | 1525 | 1525 | 1525 | 1525 | 1525 |
| Rear wheel track [mm] | 1520 | 1520 | 1520 | 1520 | 1520 | 1520 |
| Forward overhang [mm] | 910 | 910 | 910 | 910 | 910 | 910 |
| Rear overhang [mm] | 795 | 795 | 795 | 795 | 795 | 795 |
| Clearance [mm] | 155 | 155 | 155 | 155 | 155 | 155 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 976 | 976 | 976 | 976 | 976 | 976 |
| Headroom rear [mm] | 944 | 944 | 944 | 944 | 944 | 944 |
| Front elbow/shoulder width [mm] | 1329/1360 | 1329/1360 | 1329/1360 | 1329/1360 | 1329/1360 | 1329/1360 |
| Rear elbow/shoulder width [mm] | 1245/1281 | 1245/1281 | 1245/1281 | 1245/1281 | 1245/1281 | 1245/1281 |
| Legroom front knees/total [mm] | -/1058 | -/1058 | -/1058 | -/1058 | -/1058 | -/1058 |
| Legroom rear knees/total [mm] | -/888 | -/888 | -/888 | -/888 | -/888 | -/888 |
| 1.8 SKYACTIV-D 115 | 1.8 SKYACTIV-D 115 | 1.8 SKYACTIV-D 115 AWD | ||||
|---|---|---|---|---|---|---|
| Date of sale | from to 2021 | from to 2021 | from to 2021 | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1759 | 1759 | 1759 | |||
| Maximum output / speed [kW/min-1] | 85/4000 | 85/4000 | 85/4000 | |||
| Maximum torque [Nm/min-1] | 270/1600-2600 | 270/1600-2600 | 270/1600-2600 | |||
| Bore and stroke [mm x mm] | 79.0 x 89.7 | 79.0 x 89.7 | 79.0 x 89.7 | |||
| Compression ratio | 14,8:1 | 14,8:1 | 14,8:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | 4x4 | |||
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear automatic | |||
| Drive specifications | - |
|
| |||
| Top speed [km/h] | 184 | 183 | 181 | |||
| Acceleration 0–100 km/h [s] | 9,9 | 11,0 | 10,5 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 4,8 | 5,3 | 5,4 | |||
| Out of town [l] | 4,1 | 4,7 | 4,5 | |||
| Combined [l] | 4,4 | 4,9 | 4,8 | |||
| CO2 emissions [g/km] | 114 | 129 | 126 | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | 5,2 | 5,9 | 6,1 | |||
| CO2 emissions [g/km] | 138 | 156 | 160 | |||
| Emission standard | EURO 6d-Temp | EURO 6d-Temp | EURO 6d-Temp | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1318-1370 | 1336-1385 | 1382-1435 | |||
| Overall weight [kg] | 1755 | 1780 | 1823 | |||
| Maximum trailer weight unbraked/braked [kg] | 655/1200 | 665/1200 | 690/1200 | |||
| Maximum front/rear axle load [kg] | 969/861 | 995-860 | 989/909 | |||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | |||
| Maximum load on roof/carrier [kg] | 50/- | 50/- | 50/- | |||
| Boot volume [l] | 350 | 350 | 350 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1260 | -/1260 | -/1260 | |||
| Boot length [mm] | 800 | 800 | 800 | |||
| Boot length with rear seats folded [mm] | 1440 | 1440 | 1440 | |||
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | |||
| Boot height to headliner/ceiling [mm] | 575/- | 575/- | 575/- | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | 882 | 882 | 882 | |||
| Boot opening width min/max [mm] | -/969 | -/969 | -/969 | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 48 | 48 | 44 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 215/60 R16 | 215/60 R16 | 215/60 R16 | |||
| Tyre dimensions rear | 215/60 R16 | 215/60 R16 | 215/60 R16 | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | 295 | 295 | 295 | |||
| Brake dimensions rear | 281 | 281 | 281 | |||
| Steering | Rack & pinion with electric power steering EPS | Rack & pinion with electric power steering EPS | Rack & pinion with electric power steering EPS | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | -/11.38 | -/11.38 | -/11.38 | |||
| Overall length [mm] | 4275 | 4275 | 4275 | |||
| Overall width without/including mirrors [mm] | 1765/2049 | 1765/2049 | 1765/2049 | |||
| Overall height [mm] | 1535 | 1535 | 1535 | |||
| Wheelbase [mm] | 2570 | 2570 | 2570 | |||
| Front wheel track [mm] | 1525 | 1525 | 1525 | |||
| Rear wheel track [mm] | 1520 | 1520 | 1520 | |||
| Forward overhang [mm] | 910 | 910 | 910 | |||
| Rear overhang [mm] | 795 | 795 | 795 | |||
| Clearance [mm] | 155 | 155 | 155 | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 976 | 976 | 976 | |||
| Headroom rear [mm] | 944 | 944 | 944 | |||
| Front elbow/shoulder width [mm] | 1329/1360 | 1329/1360 | 1329/1360 | |||
| Rear elbow/shoulder width [mm] | 1245/1281 | 1245/1281 | 1245/1281 | |||
| Legroom front knees/total [mm] | -/1058 | -/1058 | -/1058 | |||
| Legroom rear knees/total [mm] | -/888 | -/888 | -/888 |
