Mazda 5

5 CR 2008

Date of manufacture

2008 – 4/2010 (MPV)

Platform

Mazda BK platform

Manufacturing locations

Hiroshima, Japan

Designer

Koji Tabata

Tags

Mid-size MPV
Japanese cars
The Mazda 5 MPV is the only body style of this car that has been produced since 2008. The car is built on the Mazda BK platform and offers petrol and diesel engines. The highest power is achieved by the 2.0 MZR with 107 kW, while the fastest model 2.0 MZR-CD can reach a speed of up to 196 km/h with the best acceleration from 0-100 km/h in 10.2 seconds. The fuel consumption of this model is 6.1 l/100 km with emissions of 162 g/km. The trunk has a capacity of 112 l. EURONCAP safety tests gave this car a rating of 5 out of 5. Japan is the country of manufacture of this car.

Car body style

MPV

after upgrade (facelift)
Date of manufacture
2008 – 4/2010
Internal designation
CR

Euro NCAP

Pre-2009 Rating
pre-facelift version (2005)
Adults
star iconstar iconstar iconstar iconstar icon
33
Children
star iconstar iconstar iconstar iconstar icon
32
Pedestrians
star iconstar iconstar iconstar iconstar icon
12

Technical data

MPV

1.8 MZR 2.0 MZR 2.0 MZR 2.0 MZR-CD 2.0 MZR-CD
Date of sale-----
Engine typePetrolPetrolPetrolDiesel superchargedDiesel supercharged
Number of cylinders/valves4/164/164/164/164/16
Engine displacement [cm³]17981999199919981998
Maximum output / speed [kW/min-1]
85/5300
107/6500
107/6500
81/3500
105/3500
Maximum torque [Nm/min-1]
165/4000
185/4000
185/4000
310/2000
360/2000
Drive axleFrontFrontFrontFrontFront
Gearbox5 gear manual6 gear manual5 gear automatic6 gear manual6 gear manual
Top speed [km/h]182194186177196
Acceleration 0–100 km/h [s]11.310.212.413.911.0
City [l]10.110.611.37.37.3
Out of town [l]6.16.36.45.45.4
Combined [l]7.67.98.26.16.1
CO2 emissions [g/km]182187194162162
Emission standardEU4EU4EU4EU4EU4
Standby weight [kg]14001410147515351535
Overall weight [kg]21102125215022452250
Maximum trailer weight unbraked/braked [kg]600/1300600/1400600/1400600/1400600/1400
Boot volume [l]538112112538112
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/1678-/1566-/1566-/1678-/1566
Boot volume, third row of seats [l]-----
Number of doors55555
Number of seats5-7775-77
Fuel tank volume [l]6060606060
AdBlue tank volume [l]-----
Overall length [mm]45054505450545054505
Overall width without/including mirrors [mm]1755/-1755/-1755/-1755/-1755/-
Overall height [mm]16151615161516151615
Wheelbase [mm]27502750275027502750
Headroom front [mm]10331033103310331033
Headroom rear [mm]10001000100010001000
Front elbow/shoulder width [mm]-/1410-/1410-/1410-/1410-/1410
Rear elbow/shoulder width [mm]-/1411-/1411-/1411-/1411-/1411
Third row of seats, headroom [mm]942942942942942
Third row elbow/shoulder width [mm]12501250125012501250

Gallery

Mazda 5 CR facelift 2008 interiorMazda 5 CR facelift 2008 front seatsMazda 5 CR facelift 2008 rear seatsMazda 5 CR facelift 2008 rear folding seatsMazda 5 CR facelift 2008 bootMazda 5 CR facelift 2008 rear folding seats
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
