Mazda 2
Date of manufacture
2019 – to this day (Five-door hatchback)
Platform
Mazda DJ
Manufacturing locations
Hōfu, Japan
Rayong, Thailand
Salamanca, Mexico
Designer
Ikuo Maeda
Tags
B-segment
Japanese cars
Mazda 2 is a five-door hatchback produced since 2019 in Japan, Thailand and Mexico. The car is built on the Mazda DJ platform and offers only gasoline engines. The most powerful of them, SKYACTIV-G 90, has 66 kW and reaches a maximum speed of 183 km/h with the best acceleration 0-100 km/h in 9.8 seconds. The consumption of this engine is 5.3 l/100 km with emissions of 120 g/km. The trunk has a capacity of 280 l. In the safety area, EURONCAP gave the car a rating of 4 out of 5 in 2015.
Car body style
Five-door hatchback
after upgrade (facelift)
Date of manufacture
2019 – to this dayInternal designation
DJEngine size
Technical data
Five-door hatchback
| SKYACTIV-G 75 | SKYACTIV-G 90 | SKYACTIV-G 90 | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Petrol | Petrol | Petrol | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1496 | 1496 | 1496 | |||
| Maximum output / speed [kW/min-1] | 55/6000 | 66/6000 | 66/6000 | |||
| Maximum torque [Nm/min-1] | 135/3800 | 148/4000 | 148/4000 | |||
| Bore and stroke [mm x mm] | 74.5 x 85.8 | 74.5 x 85.8 | 74.5 x 85.8 | |||
| Compression ratio | 13:1 | 13:1 | 13:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | Front | |||
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | |||
| Drive specifications | - | - |
| |||
| Top speed [km/h] | 171 | 183 | 177 | |||
| Acceleration 0–100 km/h [s] | 11,4 | 9,8 | 12,0 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 4,8 | 4,8 | 6,0 | |||
| Out of town [l] | 3,7 | 3,7 | 4,7 | |||
| Combined [l] | 4,1 | 4,1 | 5,2 | |||
| CO2 emissions [g/km] | 94 | 94 | 118 | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | 5,3 | 5,3 | 5,9 | |||
| CO2 emissions [g/km] | 120 | 120 | 133 | |||
| Emission standard | Euro 6d | Euro 6d | Euro 6d | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| System voltage [V] | 22.5 | 22.5 | 22.5 | |||
| Battery type and capacity | Lithium-Ionen-Akkumulator, 0.012 kWh | Lithium-Ionen-Akkumulator, 0.012 kWh | Lithium-Ionen-Akkumulator, 0.012 kWh | |||
| Range with fully charged battery [km] | - | - | - | |||
| Charging time | - | - | - | |||
| Number of modules/cells | - | - | - | |||
| Battery weight [kg] | - | - | - | |||
| Charger | - | - | - | |||
| Standby weight [kg] | 1100-1144 | 1100-1151 | 1105-1157 | |||
| Overall weight [kg] | 1536 | 1536 | 1536 | |||
| Maximum trailer weight unbraked/braked [kg] | 550/900 | 550/900 | 550/900 | |||
| Maximum front/rear axle load [kg] | 828/786 | 828/786 | 828/786 | |||
| Maximum vertical load on the tow bar [kg] | 50 | 50 | 50 | |||
| Maximum load on roof/carrier [kg] | 50/- | 50/- | 50/- | |||
| Boot volume [l] | 280 | 280 | 280 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/950 | -/950 | -/950 | |||
| Boot length [mm] | 713 | 713 | 713 | |||
| Boot length with rear seats folded [mm] | 1367 | 1367 | 1367 | |||
| Boot width between wheels/max [mm] | - | - | - | |||
| Boot height to headliner/ceiling [mm] | - | - | - | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 44 | 44 | 44 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 185/65 R15 | 185/65 R15 | 185/65 R15 | |||
| Tyre dimensions rear | 185/65 R15 | 185/65 R15 | 185/65 R15 | |||
| Wheel size front | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | |||
| Wheel size rear | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | |||
| Brake dimensions front | 258 | 258 | 258 | |||
| Brake dimensions rear | 200 drum | 200 drum | 200 drum | |||
| Steering | Rack & pinion with electric power steering EPAS | Rack & pinion with electric power steering EPAS | Rack & pinion with electric power steering EPAS | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 10.1/10,4 | 10.1/10,4 | 10.1/10,4 | |||
| Overall length [mm] | 4065 | 4065 | 4065 | |||
| Overall width without/including mirrors [mm] | 1695/1983 | 1695/1983 | 1695/1983 | |||
| Overall height [mm] | 1495 | 1495 | 1495 | |||
| Wheelbase [mm] | 2570 | 2570 | 2570 | |||
| Front wheel track [mm] | 1495 | 1495 | 1495 | |||
| Rear wheel track [mm] | 1485 | 1485 | 1485 | |||
| Forward overhang [mm] | 815 | 815 | 815 | |||
| Rear overhang [mm] | 680 | 680 | 680 | |||
| Clearance [mm] | 143 | 143 | 143 | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 984 | 984 | 984 | |||
| Headroom rear [mm] | 945 | 945 | 945 | |||
| Front elbow/shoulder width [mm] | 1322/1352 | 1322/1352 | 1322/1352 | |||
| Rear elbow/shoulder width [mm] | 1212/1272 | 1212/1272 | 1212/1272 | |||
| Legroom front knees/total [mm] | -/1063 | -/1063 | -/1063 | |||
| Legroom rear knees/total [mm] | -/881 | -/881 | -/881 | |||
| Rating |    | - | - | |||
| Clean Air Index | 5.9/10 | - | - | |||
| Energy Efficiency Index | 6.9/10 | - | - | |||
| GHG index | 5.6/10 | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
