	1.3 MZR	1.3 MZR	1.5 MZR	1.4 MCD	1.6 MCD
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/8	4/16
Engine displacement [cm³]	1349	1349	1498	1399	1560
Maximum output / speed [kW/min-1]	55/6000	63/6000	76/6000	50/4000	66/4000
Maximum torque [Nm/min-1]	121/3500	122/3500	137/4000	160/2000	205/2000
Bore and stroke [mm x mm]	74,0 x 78,4	74,0 x 78,4	78,0 x 78,4	73,7 x 82,0	75,0 x 88,3
Compression ratio	10,0:1	10,0:1	10,0:1	18,0:1	18,3:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves SV‐T	variable timing of intake valves SV‐T	variable timing of intake valves SV‐T	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged particulate filter

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	5 gear manual
Drive specifications	-	-	-	-	-

Top speed [km/h]	168	172	188	162	173
Acceleration 0–100 km/h [s]	14.0	12.9	10.4	15.5	11.4
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	6.9	6.9	7.6	5.1-5.3	5.1
Out of town [l]	4.2-4.6	4.2-4.6	4.7-4.9	3.5-3.7	3.7
Combined [l]	5.2-5.4	5.2-5.4	5.7-5.9	4.1-4.3	4.2
CO2 emissions [g/km]	125-129	125-129	135-140	107-114	112

Emission standard	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1025	1025	1030	1045	1095
Overall weight [kg]	1455	1455	1455	1490	1535
Maximum trailer weight unbraked/braked [kg]	500/900	500/900	500/900	500/800	500/800
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-	50/-

Boot volume [l]	250	250	250	250	250
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/787	-/787	-/787	-/787	-/787
Boot length [mm]	674	674	674	674	674
Boot length with rear seats folded [mm]	1321	1321	1321	1321	1321
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	3	3	3	3	3
Number of seats	5	5	5	5	5
Fuel tank volume [l]	42.8	42.8	42.8	42.8	42.8
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.31	0.31	0.31	0.31	0.31
Front suspension	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	175/65 R14	185/55 R15	195/45 R16	175/65 R14	195/45 R16
Tyre dimensions rear	175/65 R14	185/55 R15	195/45 R16	175/65 R14	195/45 R16
Wheel size front	6.0JJ x 14	6.0JJ x 15	6.5JJ x 16	6.0JJ x 14	6.5JJ x 16
Wheel size rear	6.0JJ x 14	6.0JJ x 15	6.5JJ x 16	6.0JJ x 14	6.5JJ x 16
Brake dimensions front	258	258	258	258	258
Brake dimensions rear	200 drum	200 drum	200 drum	200 drum	200 drum
Steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	9.8/-	9.8/-	9.8/-	9.8/-	9.8/-

Overall length [mm]	3885	3885	3885	3885	3885
Overall width without/including mirrors [mm]	1695/1958	1695/1958	1695/1958	1695/1958	1695/1958
Overall height [mm]	1475	1475	1475	1475	1475
Wheelbase [mm]	2490	2490	2490	2490	2490
Front wheel track [mm]	1475	1465	1465	1475	1465
Rear wheel track [mm]	1465	1455	1455	1465	1455
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	150	150	150	150	150
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Five-door hatchback

	1.3 MZR	1.3 MZR	1.5 MZR	1.4 MCD	1.6 MCD
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/8	4/16
Engine displacement [cm³]	1349	1349	1498	1399	1560
Maximum output / speed [kW/min-1]	55/6000	63/6000	76/6000	50/4000	66/4000
Maximum torque [Nm/min-1]	121/3500	122/3500	137/4000	160/2000	205/2000
Bore and stroke [mm x mm]	74,0 x 78,4	74,0 x 78,4	78,0 x 78,4	73,7 x 82,0	75,0 x 88,3
Compression ratio	10,0:1	10,0:1	10,0:1	18,0:1	18,3:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves SV‐T	variable timing of intake valves SV‐T	variable timing of intake valves SV‐T	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged particulate filter

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	5 gear manual
Drive specifications	-	-	-	-	-

Top speed [km/h]	168	172	188	162	173
Acceleration 0–100 km/h [s]	14.0	12.9	10.4	15.5	11.4
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	6.9	6.9	7.6	5.1-5.3	5.1
Out of town [l]	4.2-4.6	4.2-4.6	4.7-4.9	3.5-3.7	3.7
Combined [l]	5.2-5.4	5.2-5.4	5.7-5.9	4.1-4.3	4.2
CO2 emissions [g/km]	125-129	125-129	135-140	107-114	112

Emission standard	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1030	1030	1035	1055	1105
Overall weight [kg]	1480	1480	1485	1520	1540
Maximum trailer weight unbraked/braked [kg]	500/900	500/900	500/900	500/800	500/800
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-	50/-

Boot volume [l]	250	250	250	250	250
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/787	-/787	-/787	-/787	-/787
Boot length [mm]	674	674	674	674	674
Boot length with rear seats folded [mm]	1321	1321	1321	1321	1321
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	42.8	42.8	42.8	42.8	42.8
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.31	0.31	0.31	0.31	0.31
Front suspension	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser	MacPherson, lower cross arms, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	175/65 R14	185/55 R15	195/45 R16	175/65 R14	195/45 R16
Tyre dimensions rear	175/65 R14	185/55 R15	195/45 R16	175/65 R14	195/45 R16
Wheel size front	6.0JJ x 14	6.0JJ x 15	6.5JJ x 16	6.0JJ x 14	6.5JJ x 16
Wheel size rear	6.0JJ x 14	6.0JJ x 15	6.5JJ x 16	6.0JJ x 14	6.5JJ x 16
Brake dimensions front	258	258	258	258	258
Brake dimensions rear	200 drum	200 drum	200 drum	200 drum	200 drum
Steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering	Rack & pinion with power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	9.8/-	9.8/-	9.8/-	9.8/-	9.8/-

Overall length [mm]	3885	3885	3885	3885	3885
Overall width without/including mirrors [mm]	1695/1958	1695/1958	1695/1958	1695/1958	1695/1958
Overall height [mm]	1475	1475	1475	1475	1475
Wheelbase [mm]	2490	2490	2490	2490	2490
Front wheel track [mm]	1475	1465	1465	1475	1465
Rear wheel track [mm]	1465	1455	1455	1465	1455
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	150	150	150	150	150
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
