	Quattroporte	Quattroporte S	Quattroporte S Q4	Quattroporte S	Quattroporte S Q4	Quattroporte GTS
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	6/24	6/24	6/24	6/24	6/24	8/32
Engine displacement [cm³]	2979	2979	2979	2979	2979	3799
Maximum output / speed [kW/min-1]	257/5500	302/5500	302/5500	316/5750	316/5750	390/6500-6800
Maximum torque [Nm/min-1]	500/1750-4000	550/1750-5000	550/1750-5000	580/2250-4000	580/2250-4000	710/2250-3500
Bore and stroke [mm x mm]	86.5 x 84.5	86.5 x 84.5	86.5 x 84.5	86.5 x 84.5	86.5 x 84.5	86.5 x 80.8
Compression ratio	9.7:1	9.7:1	9.7:1	9.7:1	9.7:1	9.5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves start&stop system	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves start&stop system	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves start&stop system	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves start&stop system	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves start&stop system	direct injection GDI supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves

Drive axle	Rear	Rear	4x4	Rear	4x4	Rear
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	eight-speed automatic gearbox	eight-speed automatic gearbox	automatically controlled all-wheel drive All Wheel Drive ATC eight-speed automatic gearbox	eight-speed automatic gearbox	automatically controlled all-wheel drive All Wheel Drive ATC eight-speed automatic gearbox	eight-speed automatic gearbox

Top speed [km/h]	270	286	286	288	288	310
Acceleration 0–100 km/h [s]	5.5	5.1	4.9	5.0	4.8	4.7
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	15.5-15.4	13.8	14.2	15.5-15.4	15.7-15.0	15.6
Out of town [l]	8.9-8.6	7.2	7.1	8.9-8.6	10.0-9.4	7.9
Combined [l]	11.3-11.1	9.6	9.7	11.3-11.1	11.8-11.7	10.7
CO2 emissions [g/km]	350-349	223	226	350-349	355-339	250

Emission standard	Euro 6d-TEMP	Euro 6	Euro 6	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1860	1860	1920	1860	1920	1900
Overall weight [kg]	-	-	-	-	-	-
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	530	530	530	530	530	530
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	80	80	80	80	80	80
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	245/45 R19	245/45 R19	245/45 R19	245/45 R19	245/45 R19	245/35 ZR21
Tyre dimensions rear	275/40 R19	275/40 R19	275/40 R19	275/40 R19	275/40 R19	285/30 ZR21
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	345 x 28	345 x 28	360 x 32	345 x 28	360 x 32	380 x 34
Brake dimensions rear	330 x 22	330 x 22	345 x 28	330 x 22	345 x 28	345 x 28
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.8/-	11.8/-	11.8/-	11.8/-	11.8/-	11.8/-

Overall length [mm]	5262	5262	5262	5262	5262	5262
Overall width without/including mirrors [mm]	1948/2100	1948/2100	1948/2100	1948/2100	1948/2100	1948/2100
Overall height [mm]	1481	1481	1481	1481	1481	1481
Wheelbase [mm]	3171	3171	3171	3171	3171	3171
Front wheel track [mm]	1634	1634	1634	1634	1634	1634
Rear wheel track [mm]	1647	1647	1647	1647	1647	1647
Forward overhang [mm]	968	968	968	968	968	968
Rear overhang [mm]	1123	1123	1123	1123	1123	1123
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	Quattroporte Diesel
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	6/24
Engine displacement [cm³]	2987
Maximum output / speed [kW/min-1]	202/4000
Maximum torque [Nm/min-1]	600/2000-2600
Bore and stroke [mm x mm]	83.0 x 92.0
Compression ratio	16.5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter start&stop system

Drive axle	Rear
Gearbox	8 gear automatic
Drive specifications	eight-speed automatic gearbox

Top speed [km/h]	252
Acceleration 0–100 km/h [s]	6.4
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	9.1-7.9
Out of town [l]	6.7-5.2
Combined [l]	7.6-6.2
CO2 emissions [g/km]	199-163

Emission standard	Euro 6 - Euro 6d-TEMP
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1925
Overall weight [kg]	-
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	530
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	4
Number of seats	5
Fuel tank volume [l]	70
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	double wishbone
Rear suspension	multilink
Tyre dimensions front	245/45 R19
Tyre dimensions rear	275/40 R19
Wheel size front	-
Wheel size rear	-
Brake dimensions front	345 x 28
Brake dimensions rear	330 x 22
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	11.8/-

Overall length [mm]	5262
Overall width without/including mirrors [mm]	1948/2100
Overall height [mm]	1481
Wheelbase [mm]	3171
Front wheel track [mm]	1634
Rear wheel track [mm]	1647
Forward overhang [mm]	968
Rear overhang [mm]	1123
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Maserati Quattroporte M156 facelift 2017 interior

Maserati Quattroporte M156 facelift 2017 front seats

Maserati Quattroporte M156 facelift 2017 rear seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
