Maserati GranTurismo

Date of manufacture

2007 – 2017 (Coupé)

Platform

Maserati M139

Manufacturing locations

Modena, Italy

Designer

Jason Castriota

Car body style

Coupé

Date of manufacture

2007 – 2017

Internal designation

M139

Engine size

GranTurismo

GranTurismo Sport

GranTurismo MC Stradale

Technical data

Coupé

	GranTurismo	GranTurismo Sport	GranTurismo Sport	GranTurismo MC Stradale
Date of sale	-	from 2012 to	from 2012 to	from 2013 to
Engine type	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	8/32	8/32	8/32	8/32
Engine displacement [cm³]	4244	4691	4691	4691
Maximum output / speed [kW/min-1]	302/7100	338/7000	338/7000	338/7000
Maximum torque [Nm/min-1]	460/4750	520/4750	520/4750	520/4750
Bore and stroke [mm x mm]	-	94.0 x 84.5	94.0 x 84.5	94.0 x 84.5
Compression ratio	11.01:1	11.25:1	11.25:1	11.25:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing	variable valve timing	variable valve timing	variable valve timing

Drive axle	Rear	Rear	Rear	Rear
Gearbox	6 gear automatic	6 gear robotic manual	6 gear automatic	6 gear automatic
Drive specifications	six-speed automatic gearbox	robotic manual gearbox MC Shift	six-speed automatic gearbox	six-speed automatic gearbox

Top speed [km/h]	285	298	300	303
Acceleration 0–100 km/h [s]	5.2	4.8	4.7	4.5
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	21.5	23.8	21.9	23.8-22.7
Out of town [l]	10,0	10.7	9.8	10.7-9.7
Combined [l]	14.3	15.5	14.3	15.5-14.4
CO2 emissions [g/km]	330	360	331	360-337

Emission standard	Euro 5 - Euro 6	Euro 5 - Euro 6	Euro 5 - Euro 6	Euro 5 - Euro 6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1955	1880	1880	1800
Overall weight [kg]	-	-	-	-
Maximum trailer weight unbraked/braked [kg]	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	260	260	260	320
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	2	2	2	2
Number of seats	4	4	4	4
Fuel tank volume [l]	86	86	86	90
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	-	-	-	-
Rear suspension	-	-	-	-
Tyre dimensions front	245/40 ZR19	245/35 ZR20	245/35 ZR20	255/35 ZR20
Tyre dimensions rear	285/40 ZR19	285/35 ZR20	285/35 ZR20	295/35 ZR20
Wheel size front	8.5J x 19	8.5J x 20	8.5J x 20	8.5J x 20
Wheel size rear	10.5J x 19	10.5J x 20	10.5J x 20	10.5J x 20
Brake dimensions front	-	360 x 32	360 x 32	380 x 34
Brake dimensions rear	-	330 x 28	330 x 28	360 x 32
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.7/-	10.7/-	10.7/-	10.5/-

Overall length [mm]	4881	4881	4881	4933
Overall width without/including mirrors [mm]	1915/2056	1915/2056	1915/2056	1903/2044
Overall height [mm]	1380	1353	1353	1343
Wheelbase [mm]	2942	2942	2942	2938
Front wheel track [mm]	1586	1586	1586	1588
Rear wheel track [mm]	1590	1590	1590	1571
Forward overhang [mm]	873	873	873	927
Rear overhang [mm]	1066	1066	1066	1067
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Maserati GranTurismo Sport M139 2016 interior

Maserati GranTurismo Sport M139 2012 front seats

Maserati GranTurismo Sport M139 2013 rear seats
