Land Rover Defender
Date of manufacture
1990 – 2016 (SUV)
Platform
-
Manufacturing locations
Solihull, United Kingdom
Designer
-
Tags
Offroad
British cars
The Land Rover Defender is an SUV that has been manufactured since 1990. Its home is the United Kingdom. The engine range only includes diesel and the highest power is achieved by the 2.2 TD 130 Double Cab with 90 kW. The highest speed it can reach is 145 km/h and the lowest fuel consumption of 10 l/100 km belongs to the 2.2 TD 90 Pick Up. CO2 emissions are 266 g/km.
Car body style
SUV (Offroad)
Date of manufacture
1990 – 2016Internal designation
-Technical data
SUV (Offroad)
| 2.2 TD 90 Pick Up | 2.2 TD 90 Hard/Soft Top | 2.2 TD 90 Station Wagon | 2.2 TD 110 Pick Up | 2.2 TD 110 Hard Top | 2.2 TD 110 Station Wagon | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2198 | 2198 | 2198 | 2198 | 2198 | 2198 |
| Maximum output / speed [kW/min-1] | 90/3500 | 90/3500 | 90/3500 | 90/3500 | 90/3500 | 90/3500 |
| Maximum torque [Nm/min-1] | 360/2000 | 360/2000 | 360/2000 | 360/2000 | 360/2000 | 360/2000 |
| Bore and stroke [mm x mm] | 86.0 x 94.6 | 86.0 x 94.6 | 86.0 x 94.6 | 86.0 x 94.6 | 86.0 x 94.6 | 86.0 x 94.6 |
| Compression ratio | 15.64:1 | 15.64:1 | 15.64:1 | 15.64:1 | 15.64:1 | 15.64:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual |
| Drive specifications | - | - | - | - | - | - |
| Top speed [km/h] | 145 | 145 | 145 | 145 | 145 | 145 |
| Acceleration 0–100 km/h [s] | 15.8 | 15.8 | 15.8 | 15.8 | 15.8 | 15.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 11.5 | 11.5 | 11.7 | 13.6 | 13.6 | 13.6 |
| Out of town [l] | 9.1 | 9.1 | 9.4 | 9.7 | 9.7 | 9.7 |
| Combined [l] | 10.0 | 10.0 | 10.2 | 11.1 | 11.1 | 11.1 |
| CO2 emissions [g/km] | 266 | 266 | 269 | 295 | 295 | 295 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1733-1828 | 1754-1872 | 1870-1976 | - | 1947-2041 | 2043-2150 [2105-2205 seven seats] |
| Overall weight [kg] | 2505 | 2505 | 2505 | 3050 | 3050 | 3050 |
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 |
| Maximum front/rear axle load [kg] | 1250/1500 | 1250/1500 | 1250/1500 | 1250/1980 | 1250/1980 | 1250/1980 |
| Maximum vertical load on the tow bar [kg] | 150 | 150 | 150 | 150 | 150 | 150 |
| Maximum load on roof/carrier [kg] | -/150 | -/150 | -/150 | -/150 | -/150 | -/150 |
| Boot volume [l] | - | - | - | - | - | - |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | 983 | 1144 | 1144 | 1740 | 1900 | 1900 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | -/800 | -/755 | -/660 | -/800 | -/755 | -/660 |
| Boot height to headliner/ceiling [mm] | -/1160 | -/1050 | -/1050 | -/1160 | -/1050 | -/1050 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 3 | 3 | 2 | 3 | 3 |
| Number of seats | 2 | 2 | 4 | 2 | 5 | 5/7 |
| Fuel tank volume [l] | 60 | 60 | 60 | 75 | 75 | 75 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | rigid with Panhard rod | rigid with Panhard rod | rigid with Panhard rod | rigid with Panhard rod | rigid with Panhard rod | rigid with Panhard rod |
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar |
| Tyre dimensions front | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 |
| Tyre dimensions rear | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 | 235/85 R16 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.3-13.34/- | 12.3-13.34/- | 12.3-13.34/- | 12.8-14.36/- | 12.8-14.36/- | 12.8-14.36/- |
| Overall length [mm] | 3681 | 4040 | 4040 | 4578 | 4785 | 4785 |
| Overall width without/including mirrors [mm] | 1790/- | 1790/- | 1790/- | 1790/- | 1790/- | 1790/- |
| Overall height [mm] | 2000-2182 | 2000-2182 | 2000-2182 | 2000-2182 | 2000-2182 | 2000-2182 |
| Wheelbase [mm] | 2360 | 2360 | 2360 | 2794 | 2794 | 2794 |
| Front wheel track [mm] | 1486 | 1486 | 1486 | 1486 | 1486 | 1486 |
| Rear wheel track [mm] | 1486 | 1486 | 1486 | 1486 | 1486 | 1486 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 250 | 250 | 250 | 250 | 250 | 250 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 47 | 47 | 47 | 49 | 49 | 49 |
| Approach angle rear [°] | 47 | 47 | 47 | 35 | 35 | 35 |
| Transition angle [°] | 147 | 147 | 147 | 150 | 150 | 150 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.2 TD 110 Double Cab | 2.2 TD 130 Double Cab | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 2198 | 2198 | ||||
| Maximum output / speed [kW/min-1] | 90/3500 | 90/3500 | ||||
| Maximum torque [Nm/min-1] | 360/2000 | 360/2000 | ||||
| Bore and stroke [mm x mm] | 86.0 x 94.6 | 86.0 x 94.6 | ||||
| Compression ratio | 15.64:1 | 15.64:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | 4x4 | ||||
| Gearbox | 6 gear manual | 6 gear manual | ||||
| Drive specifications | - | - | ||||
| Top speed [km/h] | 145 | 145 | ||||
| Acceleration 0–100 km/h [s] | 15.8 | 17.0 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 13.6 | 13.6 | ||||
| Out of town [l] | 9.7 | 9.7 | ||||
| Combined [l] | 11.1 | 11.1 | ||||
| CO2 emissions [g/km] | 295 | 295 | ||||
| Emission standard | EU5 | EU5 | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 2023-2118 | 2005-2206 | ||||
| Overall weight [kg] | 3050 | 3380 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | ||||
| Maximum front/rear axle load [kg] | 1250/1980 | 1580/2200 | ||||
| Maximum vertical load on the tow bar [kg] | 150 | 150 | ||||
| Maximum load on roof/carrier [kg] | -/150 | -/150 | ||||
| Boot volume [l] | - | - | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | ||||
| Boot length [mm] | 1020 | 1680 | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | -/800 | -/1060 | ||||
| Boot height to headliner/ceiling [mm] | -/1160 | -/1160 | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 4 | 4 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 75 | 75 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | - | - | ||||
| Front suspension | rigid with Panhard rod | rigid with Panhard rod | ||||
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | ||||
| Tyre dimensions front | 235/85 R16 | 7.50R16 | ||||
| Tyre dimensions rear | 235/85 R16 | 7.50R16 | ||||
| Wheel size front | - | - | ||||
| Wheel size rear | - | - | ||||
| Brake dimensions front | - | - | ||||
| Brake dimensions rear | - | - | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 12.8-14.36/- | 15.08/- | ||||
| Overall length [mm] | 4578 | 5271 | ||||
| Overall width without/including mirrors [mm] | 1790/- | 1790/- | ||||
| Overall height [mm] | 2000-2182 | 2000-2182 | ||||
| Wheelbase [mm] | 2794 | 3226 | ||||
| Front wheel track [mm] | 1486 | 1511 | ||||
| Rear wheel track [mm] | 1486 | 1511 | ||||
| Forward overhang [mm] | - | - | ||||
| Rear overhang [mm] | - | - | ||||
| Clearance [mm] | 250 | 250 | ||||
| Wading depth [mm] | 500 | 500 | ||||
| Approach angle front [°] | 49 | 49 | ||||
| Approach angle rear [°] | 35 | 35 | ||||
| Transition angle [°] | 150 | 53 | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | - | - | ||||
| Headroom rear [mm] | - | - | ||||
| Front elbow/shoulder width [mm] | - | - | ||||
| Rear elbow/shoulder width [mm] | - | - | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
