Basic information Technical Specifications Gallery

Lamborghini Aventador S

Date of manufacture

2016 – to this day (Coupé)

2017 – to this day (Roadster)

Platform

Manufacturing locations

Bologna, Italy

Designer

Mitja Borkert

Car body style

Coupé

Date of manufacture

2016 – to this day

Internal designation

LB834

Engine size

Aventador S

Aventador SVJ

Roadster

Date of manufacture

2017 – to this day

Internal designation

LB834

Engine size

Aventador S

Aventador SVJ

Technical data

Coupé

	Aventador S	Aventador SVJ
Date of sale	from 2016 to	from 2018 to
Engine type	Petrol	Petrol
Number of cylinders/valves	12/48	12/48
Engine displacement [cm³]	6498	6498
Maximum output / speed [kW/min-1]	544/8400	566/8500
Maximum torque [Nm/min-1]	690/5500	720/6750
Bore and stroke [mm x mm]	95.0 x 76.4	95.0 x 76.4
Compression ratio	11.8:1	11.8:1
Oil volume [l]	13	13
Coolant volume [l]	25	25
Technical specifications	variable valve timing VVT	variable valve timing VVT

Drive axle	4x4	4x4
Gearbox	7 gear robotic manual	7 gear robotic manual
Drive specifications	automatically controlled all-wheel drive 4WD with Haldex inter-axle clutch IV generation robotic gearbox ISR	automatically controlled all-wheel drive 4WD with Haldex inter-axle clutch IV generation robotic gearbox ISR

Top speed [km/h]	350	> 350
Acceleration 0–100 km/h [s]	2.9	2.8
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	26.2	31.0
Out of town [l]	11.6	13.0
Combined [l]	16.9	19.6
CO2 emissions [g/km]	394	452

Emission standard	Euro 6	Euro 6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1575 net weight	1525 net weight
Overall weight [kg]	-	2050
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	140	140
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	85	85
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	double wishbone	double wishbone
Rear suspension	double wishbone	double wishbone
Tyre dimensions front	255/30 ZR20	255/30 ZR20
Tyre dimensions rear	355/25 ZR21	355/25 ZR21
Wheel size front	9.0J x 20 H2 ET 32.2	9.0J x 20 H2 ET 32.2
Wheel size rear	13.0J x 21 H2 ET 66.7	13.0J x 21 H2 ET 66.7
Brake dimensions front	400 x 38	400 x 38
Brake dimensions rear	380 x 38	380 x 38
Steering	-	-
Number of steering wheel turns	2.1-2.4	2.1-2.4
Turning diameter track/circumference [m]	11.5/-	11.5/-

Overall length [mm]	4797	4943
Overall width without/including mirrors [mm]	2030/-	2098/2273
Overall height [mm]	1136	1136
Wheelbase [mm]	2700	2700
Front wheel track [mm]	1720	1720
Rear wheel track [mm]	1680	1680
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	115	115
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Roadster

	Aventador S	Aventador SVJ
Date of sale	from 2017 to	from 2018 to
Engine type	Petrol	Petrol
Number of cylinders/valves	12/48	12/48
Engine displacement [cm³]	6498	6498
Maximum output / speed [kW/min-1]	544/8400	566/8500
Maximum torque [Nm/min-1]	690/5500	720/6750
Bore and stroke [mm x mm]	95.0 x 76.4	95.0 x 76.4
Compression ratio	11.8:1	11.8:1
Oil volume [l]	13	13
Coolant volume [l]	25	25
Technical specifications	variable valve timing VVT	variable valve timing VVT

Drive axle	4x4	4x4
Gearbox	7 gear robotic manual	7 gear robotic manual
Drive specifications	automatically controlled all-wheel drive 4WD with Haldex inter-axle clutch IV generation robotic gearbox ISR	automatically controlled all-wheel drive 4WD with Haldex inter-axle clutch IV generation robotic gearbox ISR

Top speed [km/h]	350	> 350
Acceleration 0–100 km/h [s]	3.0	2.9
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	26.2	-
Out of town [l]	11.6	-
Combined [l]	16.9	-
CO2 emissions [g/km]	394	-

Low speed [l]	-	-
Medium speed [l]	-	-
High speed [l]	-	-
Extra high speed [l]	-	-
Combined speed [l]	-	17.9
CO2 emissions [g/km]	-	486

Emission standard	Euro 6	Euro 6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1625 net weight	1575 net weight
Overall weight [kg]	-	2100
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	140	140
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	85	85
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	double wishbone	double wishbone
Rear suspension	double wishbone	double wishbone
Tyre dimensions front	255/30 ZR20	255/30 ZR20
Tyre dimensions rear	355/25 ZR21	355/25 ZR21
Wheel size front	9.0J x 20 H2 ET 32.2	9.0J x 20 H2 ET 32.2
Wheel size rear	13.0J x 21 H2 ET 66.7	13.0J x 21 H2 ET 66.7
Brake dimensions front	400 x 38	400 x 38
Brake dimensions rear	380 x 38	380 x 38
Steering	-	-
Number of steering wheel turns	2.1-2.4	2.1-2.4
Turning diameter track/circumference [m]	11.5/-	11.5/-

Overall length [mm]	4797	4943
Overall width without/including mirrors [mm]	2030/-	2098/2273
Overall height [mm]	1136	1136
Wheelbase [mm]	2700	2700
Front wheel track [mm]	1720	1720
Rear wheel track [mm]	1680	1680
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	115	115
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Lamborghini Aventador S Roadster 2017 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
