Kia Sportage
Date of manufacture
12/2015 – 2018 (SUV)
Platform
-
Manufacturing locations
Gwangju, South Korea
Žilina, Slovakia
Kaliningrad, Russia
Designer
Peter Schreyer
Tags
Compact SUV
Korean cars
The Kia Sportage is an SUV that has been produced since 2015 in three countries - South Korea, Slovakia and Russia. The engine range includes petrol and diesel units with a maximum output of 136 kW for the 2.0 CRDi. The fastest model, the 1.6 T-GDI, reaches a top speed of 205 km/h, while the most economical 1.7 CRDi has a fuel consumption of 4.7 l/100 km and emissions of 124 g/km. The boot capacity is 503 l. In 2015, the Kia Sportage underwent EURONCAP safety tests and received a rating of 5 out of 5.
Car body style
Technical data
SUV
| 1.6 GDI | 1.6 T-GDI | 1.6 T-GDI | 1.6 T-GDI | 1.7 CRDi | 1.7 CRDi | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | from 2017 to |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1591 | 1591 | 1591 | 1591 | 1685 | 1685 |
| Maximum output / speed [kW/min-1] | 97/6300 | 130/5500 | 130/5500 | 130/5500 | 85/4000 | 104/4000 |
| Maximum torque [Nm/min-1] | 161/4850 | 265/1500-4500 | 265/1500-4500 | 265/1500-4500 | 280/1250-2750 | 340/1750-2750 |
| Bore and stroke [mm x mm] | 77,0 x 85,44 | 77,0 x 85,44 | 77,0 x 85,44 | 77,0 x 85,44 | 77,2 x 90,0 | 77,2 x 90,0 |
| Compression ratio | 11,0:1 | 10,0:1 | 10,0:1 | 10,0:1 | 16,0:1 | 15.7:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | 4x4 | 4x4 | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic |
| Drive specifications | - | - |
|
| - |
|
| Top speed [km/h] | 182 | 205 | 202 | 201 | 176 | 185 |
| Acceleration 0–100 km/h [s] | 11.5 | 9.2 | 9.5 | 9.1 | 11.5 | 11.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8.6 | 9.8 | 10.0 | 9.2 | 5.7 | 5.4 |
| Out of town [l] | 5.6 | 5.8 | 6.2 | 6.5 | 4.2 | 4.7 |
| Combined [l] | 6.7 | 7.3 | 7.6 | 7.5 | 4.7 | 4.9 |
| CO2 emissions [g/km] | 156 | 169 | 177 | 175 | 124 | 129 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1454-1546 | 1524-1675 | 1583-1733 | 1609-1779 | 1500-1639 | 1545-1694 |
| Overall weight [kg] | 1895 | 2120 | 2120 | 2170 | 2000 | 2085 |
| Maximum trailer weight unbraked/braked [kg] | 650/1400 | 750/1900 | 750/1900 | 750/1600 | 750/1400 | 750/1600 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 503 | 503 | 503 | 503 | 503 | 503 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1492 | -/1492 | -/1492 | -/1492 | -/1492 | -/1492 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 62 | 62 | 62 | 62 | 62 | 62 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | 0.33 | 0.33 | 0.33 |
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser |
| Rear suspension | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers |
| Tyre dimensions front | 215/70 R16 | 245/45 R19 | 245/45 R19 | 245/45 R19 | 215/70 R16 | 215/70 R16 |
| Tyre dimensions rear | 215/70 R16 | 245/45 R19 | 245/45 R19 | 245/45 R19 | 215/70 R16 | 215/70 R16 |
| Wheel size front | 6.5J x 16 ET 42.5 | 7.5J x 19 ET 50.5 | 7.5J x 19 ET 50.5 | 7.5J x 19 ET 50.5 | 6.5J x 16 ET 42.5 | 6.5J x 16 ET 42.5 |
| Wheel size rear | 6.5J x 16 ET 42.5 | 7.5J x 19 ET 50.5 | 7.5J x 19 ET 50.5 | 7.5J x 19 ET 50.5 | 6.5J x 16 ET 42.5 | 6.5J x 16 ET 42.5 |
| Brake dimensions front | 305 | 305 | 305 | 305 | 305 | 305 |
| Brake dimensions rear | 302 | 302 | 302 | 302 | 302 | 302 |
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- |
| Overall length [mm] | 4480 | 4480 | 4480 | 4480 | 4480 | 4480 |
| Overall width without/including mirrors [mm] | 1855/- | 1855/- | 1855/- | 1855/- | 1855/- | 1855/- |
| Overall height [mm] | 1635 | 1635 | 1635 | 1635 | 1635 | 1635 |
| Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 | 2670 | 2670 |
| Front wheel track [mm] | 1625 | 1609 | 1609 | 1609 | 1625 | 1625 |
| Rear wheel track [mm] | 1636 | 1620 | 1620 | 1620 | 1636 | 1636 |
| Forward overhang [mm] | 910 | 910 | 910 | 910 | 910 | 910 |
| Rear overhang [mm] | 900 | 900 | 900 | 900 | 900 | 900 |
| Clearance [mm] | 172 | 172 | 172 | 172 | 172 | 172 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 16.7 | 16.7 | 16.7 | 16.7 | 16.7 | 16.7 |
| Approach angle rear [°] | 23.9 | 23.9 | 23.9 | 23.9 | 23.9 | 23.9 |
| Transition angle [°] | 18.6 | 18.6 | 18.6 | 18.6 | 18.6 | 18.6 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 997 | 997 | 997 | 997 | 997 | 997 |
| Headroom rear [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Front elbow/shoulder width [mm] | 1380/1450 | 1380/1450 | 1380/1450 | 1380/1450 | 1380/1450 | 1380/1450 |
| Rear elbow/shoulder width [mm] | 1300/1400 | 1300/1400 | 1300/1400 | 1300/1400 | 1300/1400 | 1300/1400 |
| Legroom front knees/total [mm] | -/1129 | -/1129 | -/1129 | -/1129 | -/1129 | -/1129 |
| Legroom rear knees/total [mm] | -/970 | -/970 | -/970 | -/970 | -/970 | -/970 |
| 2.0 CRDi | 2.0 CRDi | 2.0 CRDi | 2.0 CRDi | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 2016 | from to 2016 | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | ||
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | ||
| Maximum output / speed [kW/min-1] | 100/2750-4000 | 100/2750-4000 | 136/4000 | 136/4000 | ||
| Maximum torque [Nm/min-1] | 373/1500-2500 | 373/1500-2500 | 400/1750-2750 | 400/1750-2750 | ||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | ||
| Compression ratio | 16,0:1 | 16,0:1 | 16,0:1 | 16,0:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | ||
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 184 | 184 | 201 | 201 | ||
| Acceleration 0–100 km/h [s] | 10.5 | 12.0 | 9.5 | 9.5 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 6.0 | 7.0 | 7.1 | 7.9 | ||
| Out of town [l] | 4.8 | 5.2 | 5.2 | 5.3 | ||
| Combined [l] | 5.2 | 5.9 | 5.9 | 6.3 | ||
| CO2 emissions [g/km] | 139 | 154 | 154 | 166 | ||
| Emission standard | EU6 | EU6 | EU6 | EU6 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1662-1737 | 1690-1859 | 1662-1831 | 1690-1859 | ||
| Overall weight [kg] | 2250 | 2250 | 2250 | 2250 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/2200 | 750/1900 | 750/2200 | 750/1900 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | ||
| Boot volume [l] | 503 | 503 | 503 | 503 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1492 | -/1492 | -/1492 | -/1492 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 62 | 62 | 62 | 62 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | 0.33 | ||
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | ||
| Rear suspension | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | ||
| Tyre dimensions front | 225/60 R17 | 225/60 R17 | 225/60 R17 | 225/60 R17 | ||
| Tyre dimensions rear | 225/60 R17 | 225/60 R17 | 225/60 R17 | 225/60 R17 | ||
| Wheel size front | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | ||
| Wheel size rear | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | 7.0J x 17 ET 48.5 | ||
| Brake dimensions front | 305 | 305 | 305 | 305 | ||
| Brake dimensions rear | 302 | 302 | 302 | 302 | ||
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | ||
| Overall length [mm] | 4480 | 4480 | 4480 | 4480 | ||
| Overall width without/including mirrors [mm] | 1855/- | 1855/- | 1855/- | 1855/- | ||
| Overall height [mm] | 1635 | 1635 | 1635 | 1635 | ||
| Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 | ||
| Front wheel track [mm] | 1613 | 1613 | 1613 | 1613 | ||
| Rear wheel track [mm] | 1625 | 1625 | 1625 | 1625 | ||
| Forward overhang [mm] | 910 | 910 | 910 | 910 | ||
| Rear overhang [mm] | 900 | 900 | 900 | 900 | ||
| Clearance [mm] | 172 | 172 | 172 | 172 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | 16.7 | 16.7 | 16.7 | 16.7 | ||
| Approach angle rear [°] | 23.9 | 23.9 | 23.9 | 23.9 | ||
| Transition angle [°] | 18.6 | 18.6 | 18.6 | 18.6 | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 997 | 997 | 997 | 997 | ||
| Headroom rear [mm] | 993 | 993 | 993 | 993 | ||
| Front elbow/shoulder width [mm] | 1380/1450 | 1380/1450 | 1380/1450 | 1380/1450 | ||
| Rear elbow/shoulder width [mm] | 1300/1400 | 1300/1400 | 1300/1400 | 1300/1400 | ||
| Legroom front knees/total [mm] | -/1129 | -/1129 | -/1129 | -/1129 | ||
| Legroom rear knees/total [mm] | -/970 | -/970 | -/970 | -/970 |
