Kia Sorento

Date of manufacture

11/2009 – 2012 (SUV)

Platform

Manufacturing locations

Hwaseong, South Korea

West Point, Georgia, USA

Kaliningrad, Russia

Designer

Peter Schreyer

Car body style

SUV

Date of manufacture

11/2009 – 2012

Internal designation

Engine size

Petrol

2.4 CVVT

Diesel

2.2 CRDI VGT

Euro NCAP

Technical data

SUV

	2.4 CVVT	2.4 CVVT	2.4 CVVT	2.4 CVVT	2.2 CRDI VGT	2.2 CRDI VGT
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2359	2359	2359	2359	2199	2199
Maximum output / speed [kW/min-1]	128/6000	128/6000	128/6000	128/6000	145/3800	145/3800
Maximum torque [Nm/min-1]	226/3750	226/3750	226/3750	226/3750	422/1800-2500	436/1800-2500
Bore and stroke [mm x mm]	88,0 x 97,0	88,0 x 97,0	88,0 x 97,0	88,0 x 97,0	85,4 x 96,0	85,4 x 96,0
Compression ratio	10,5:1	10,5:1	10,5:1	10,5:1	16,0:1	16,0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing CVVT	variable valve timing CVVT	variable valve timing CVVT	variable valve timing CVVT	direct injection Common Rail turbocharger with variable blade geometry	direct injection Common Rail turbocharger with variable blade geometry

Drive axle	Front	Front	4x4	4x4	Front	Front
Gearbox	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	-	automatic gearbox	permanent front axle drive with automatic rear axle engagement	permanent front axle drive with automatic rear axle engagement automatic gearbox	-	automatic gearbox

Top speed [km/h]	190	187	190	186	190	190
Acceleration 0–100 km/h [s]	10.5	11.1	11.1	11.6	9.4	9.7
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	11.2	11.3	11.4	11.4	8.5	9.0
Out of town [l]	6.9	7.0	7.1	7.2	5.3	6.1
Combined [l]	8.5	8.6	8.7	8.8	6.5	7.2
CO2 emissions [g/km]	203	205	208	209	171	189

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1710-1830	1725-1853	1770-1890	1790-1913	1795-1915	1825-1948
Overall weight [kg]	2510	2510	2510	2510	2510	2510
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2000	750/2000	750/2000	750/2500	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	531	531	531	531	531	531
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1546	-/1546	-/1546	-/1546	-/1546	-/1546
Boot length [mm]	1078	1078	1078	1078	1078	1078
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-/870	-/870	-/870	-/870	-/870	-/870
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5-7	5-7	5-7	5-7	5-7	5-7
Fuel tank volume [l]	70	70	70	70	70	70
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.38	0.38	0.38	0.38	0.38	0.38
Front suspension	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser
Rear suspension	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers
Tyre dimensions front	235/65 R17	235/65 R17	235/65 R17	235/65 R17	235/65 R17	235/65 R17
Tyre dimensions rear	235/65 R17	235/65 R17	235/65 R17	235/65 R17	235/65 R17	235/65 R17
Wheel size front	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Wheel size rear	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.88/-	10.88/-	10.88/-	10.88/-	10.88/-	10.88/-

Overall length [mm]	4685	4685	4685	4685	4685	4685
Overall width without/including mirrors [mm]	1885/-	1885/-	1885/-	1885/-	1885/-	1885/-
Overall height [mm]	1745	1745	1745	1745	1745	1745
Wheelbase [mm]	2700	2700	2700	2700	2700	2700
Front wheel track [mm]	1618	1618	1618	1618	1618	1618
Rear wheel track [mm]	1621	1621	1621	1621	1621	1621
Forward overhang [mm]	945	945	945	945	945	945
Rear overhang [mm]	1040	1040	1040	1040	1040	1040
Clearance [mm]	184	184	184	184	184	184
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	25.1	25.1	25.1	25.1	25.1	25.1
Approach angle rear [°]	23.1	23.1	23.1	23.1	23.1	23.1
Transition angle [°]	17.1	17.1	17.1	17.1	17.1	17.1
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.2 CRDI VGT	2.2 CRDI VGT
Date of sale	-	-
Engine type	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	2199	2199
Maximum output / speed [kW/min-1]	145/3800	145/3800
Maximum torque [Nm/min-1]	422/1800-2500	4361800-2500
Bore and stroke [mm x mm]	85,4 x 96,0	85,4 x 96,0
Compression ratio	16,0:1	16,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry	direct injection Common Rail turbocharger with variable blade geometry

Drive axle	4x4	4x4
Gearbox	6 gear manual	6 gear automatic
Drive specifications	permanent front axle drive with automatic rear axle engagement	permanent front axle drive with automatic rear axle engagement automatic gearbox

Top speed [km/h]	190	190
Acceleration 0–100 km/h [s]	9.6	10.0
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	8.6	9.3
Out of town [l]	5.4	6.2
Combined [l]	6.6	7.4
CO2 emissions [g/km]	174	194

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1835-1975	1885-2008
Overall weight [kg]	2510	2510
Maximum trailer weight unbraked/braked [kg]	750/2500	750/2000
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	100/-	100/-

Boot volume [l]	531	531
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1546	-/1546
Boot length [mm]	1078	1078
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-/870	-/870
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	5-7	5-7
Fuel tank volume [l]	70	70
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.38	0.38
Front suspension	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser
Rear suspension	multilink, coil springs, stabiliser bar, hydraulic shock absorbers	multilink, coil springs, stabiliser bar, hydraulic shock absorbers
Tyre dimensions front	235/65 R17	235/65 R17
Tyre dimensions rear	235/65 R17	235/65 R17
Wheel size front	7.0J x 17	7.0J x 17
Wheel size rear	7.0J x 17	7.0J x 17
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.88/-	10.88/-

Overall length [mm]	4685	4685
Overall width without/including mirrors [mm]	1885/-	1885/-
Overall height [mm]	1745	1745
Wheelbase [mm]	2700	2700
Front wheel track [mm]	1618	1618
Rear wheel track [mm]	1621	1621
Forward overhang [mm]	945	945
Rear overhang [mm]	1040	1040
Clearance [mm]	184	184
Wading depth [mm]	-	-
Approach angle front [°]	25.1	25.1
Approach angle rear [°]	23.1	23.1
Transition angle [°]	17.1	17.1
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
