Basic information Technical Specifications Gallery

Kia Rio

Date of manufacture

2020 – to this day (Five-door hatchback)

Platform

Hyundai-Kia GB

Manufacturing locations

Gwangmyeong, South Korea

Pesquería, Mexico

Designer

Peter Schreyer

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2020 – to this day

Internal designation

Engine size

1.2

1.0 T-GDI 100

1.0 T-GDI 48V 120

Euro NCAP

Test year 2017

pre-facelift version (2017)

Technical data

Five-door hatchback

	1.2	1.0 T-GDI 100	1.0 T-GDI 100	1.0 T-GDI 48V 120	1.0 T-GDI 48V 120
Date of sale	-	-	-	-	-
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	3/12	3/12	3/12	3/12
Engine displacement [cm³]	1197	998	998	998	998
Maximum output / speed [kW/min-1]	62/6000	73.6/4500	73.6/4500	88/6000	88/6000
Maximum torque [Nm/min-1]	120/4200	172/1500-4000	172/1500-4000	172/1500-4000	200/2000-3500
Bore and stroke [mm x mm]	71,0 x 75,6	71,0 x 84,0	71,0 x 84,0	71,0 x 84,0	71,0 x 84,0
Compression ratio	11.0:1	10,5:1	10,5:1	10,5:1	10,5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	multipoint fuel injection DPFI variable timing of intake and exhaust valves start&stop system ISG	direct injection GDI turbo-supercharged continuously variable valve period CVVD Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	direct injection GDI turbo-supercharged continuously variable valve period CVVD Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	Mild Hybrid MHEV starter-generator MHSG direct injection GDI turbo-supercharged continuously variable valve period CVVD Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	Mild Hybrid MHEV starter-generator MHSG direct injection GDI turbo-supercharged continuously variable valve period CVVD Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	7 gear automatic	6 gear manual	7 gear automatic
Drive specifications	-	-	seven-speed dual-clutch automatic gearbox DCT	-	seven-speed dual-clutch automatic gearbox DCT

Top speed [km/h]	173	188	185	190	190
Acceleration 0–100 km/h [s]	13.1	10.4	11.4	10.2	10.3
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	24.9	14.2	8.8	11.9	7.5

City [l]	6.4	6.1	5.7	4.9	5.7
Out of town [l]	4.4	4.3	4.4	4.3	4.2
Combined [l]	5.2	5.0	4.8	4.5	4.7
CO2 emissions [g/km]	118	114	110	103	108

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	70	69	70	69	70

System voltage [V]	-	-	-	48	48
Battery type and capacity	-	-	-	Lithium-polymer, - Ah	Lithium-polymer, - Ah
Range with fully charged battery [km]	-	-	-	-	-
Charging time	-	-	-	-	-
Number of modules/cells	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-
Charger	-	-	-	-	-

Standby weight [kg]	1120-1218	1175-1273	1200-1298	1205-1303	1230-1328
Overall weight [kg]	1570	1620	1650	1650	1680
Maximum trailer weight unbraked/braked [kg]	450/910	450/900	450/900	450/900	450/900
Maximum front/rear axle load [kg]	945/840	945/840	945/840	945/840	945/840
Maximum vertical load on the tow bar [kg]	75	75	75	75	75
Maximum load on roof/carrier [kg]	70/-	70/-	70/-	70/-	70/-

Boot volume [l]	325	325	325	325	325
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1103	-/1103	-/1103	-/1103	-/1103
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	717	717	717	717	717
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, coil springs, gas shock absorbers	MacPherson, coil springs, gas shock absorbers	MacPherson, coil springs, gas shock absorbers	MacPherson, coil springs, gas shock absorbers	MacPherson, coil springs, gas shock absorbers
Rear suspension	twist beam axle with trailing arms, gas shock absorbers and torsion bar	twist beam axle with trailing arms, gas shock absorbers and torsion bar	twist beam axle with trailing arms, gas shock absorbers and torsion bar	twist beam axle with trailing arms, gas shock absorbers and torsion bar	twist beam axle with trailing arms, gas shock absorbers and torsion bar
Tyre dimensions front	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H
Tyre dimensions rear	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H	185/65 R15 88H
Wheel size front	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46
Wheel size rear	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46	6,0J x 15 ET46
Brake dimensions front	256 or 280	280	280	280	280
Brake dimensions rear	203 or 262	203 or 262	203 or 262	203 or 262	203 or 262
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	2.6	2.6	2.6	2.6	2.6
Turning diameter track/circumference [m]	10,2/-	10,2/-	10,2/-	10,2/-	10,2/-

Overall length [mm]	4065	4065	4065	4065	4065
Overall width without/including mirrors [mm]	1725/1993	1725/1993	1725/1993	1725/1993	1725/1993
Overall height [mm]	1450	1450	1450	1450	1450
Wheelbase [mm]	2580	2580	2580	2580	2580
Front wheel track [mm]	1518	1518	1518	1518	1518
Rear wheel track [mm]	1524	1524	1524	1524	1524
Forward overhang [mm]	830	830	830	830	830
Rear overhang [mm]	655	655	655	655	655
Clearance [mm]	140	140	140	140	140
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	987	987	987	987	987
Headroom rear [mm]	964	964	964	964	964
Front elbow/shoulder width [mm]	1344/1375	1344/1375	1344/1375	1344/1375	1344/1375
Rear elbow/shoulder width [mm]	1330/1355	1330/1355	1330/1355	1330/1355	1330/1355
Legroom front knees/total [mm]	-/1070	-/1070	-/1070	-/1070	-/1070
Legroom rear knees/total [mm]	-/850	-/850	-/850	-/850	-/850

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
