Kia Rio

Date of manufacture

2015 – 2017 (Five-door hatchback)

Platform

Manufacturing locations

Gwangmyeong, South Korea

Designer

Peter Schreyer

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2015 – 2017

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Test year 2011

pre-facelift version (2011)

Technical data

Five-door hatchback

	1.25 CVVT	1.25 CVVT ISG	1.4 CVVT	1.4 CVVT ISG	1.4 CVVT	1.1 CRDi
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	3/12
Engine displacement [cm³]	1248	1248	1396	1396	1396	1120
Maximum output / speed [kW/min-1]	62/6000	63/6000	80/6300	80/6300	80/6300	55/4000
Maximum torque [Nm/min-1]	121/4000	121/4000	137/4200	137/4200	137/4200	180/1750-2500
Bore and stroke [mm x mm]	71,0 x 78,8	71,0 x 78,8	77,0 x 74,99	77,0 x 74,99	77,0 x 74,99	75,0 x 84,5
Compression ratio	10,5:1	10,5:1	10,5:1	10,5:1	10,5:1	16,0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves CVVT	variable timing of intake and exhaust valves CVVT start&stop system	variable timing of intake and exhaust valves CVVT	variable timing of intake and exhaust valves CVVT start&stop system	variable timing of intake and exhaust valves CVVT	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	6 gear manual	6 gear manual	4 gear automatic	6 gear manual
Drive specifications	-	-	-	-	automatic gearbox	-

Top speed [km/h]	167	166	185	183	170	160
Acceleration 0–100 km/h [s]	13.4	13.4	11.4	11.4	13.2	16.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.3	5.9	7.2	6.5	8.5	4.5
Out of town [l]	4.2	4.1	4.5	4.2	5.0	3.4
Combined [l]	5.0	4.7	5.5	5.0	6.3	3.8
CO2 emissions [g/km]	115	109	127	114	147	99

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1127-1207	1127-1207	1154-1236	1154-1236	1184-1262	1200-1280
Overall weight [kg]	1560	1560	1600	1600	1630	1640
Maximum trailer weight unbraked/braked [kg]	450/900	450/900	450/1050	450/1050	450/850	450/800
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	70/-	70/-	70/-	70/-	70/-	70/-

Boot volume [l]	288	288	288	288	288	288
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/923	-/923	-/923	-/923	-/923	-/923
Boot length [mm]	684	684	684	684	684	684
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-/1059	-/1059	-/1059	-/1059	-/1059	-/1059
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	43	43	43	43	43	43
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Wheel size front	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15
Wheel size rear	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15
Brake dimensions front	256x22	256x22	280x22	280x22	280x22	256x22
Brake dimensions rear	262x10	262x10	262x10	262x10	262x10	262x10
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.52/-	10.52/-	10.52/-	10.52/-	10.52/-	10.52/-

Overall length [mm]	4050	4050	4050	4050	4050	4050
Overall width without/including mirrors [mm]	1720/-	1720/-	1720/-	1720/-	1720/-	1720/-
Overall height [mm]	1455	1455	1455	1455	1455	1455
Wheelbase [mm]	2570	2570	2570	2570	2570	2570
Front wheel track [mm]	1521	1521	1521	1521	1521	1521
Rear wheel track [mm]	1525	1525	1525	1525	1525	1525
Forward overhang [mm]	810	810	810	810	810	810
Rear overhang [mm]	670	670	670	670	670	670
Clearance [mm]	140	140	140	140	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1015	1015	1015	1015	1015	1015
Headroom rear [mm]	960	960	960	960	960	960
Front elbow/shoulder width [mm]	1323/1350	1323/1350	1323/1350	1323/1350	1323/1350	1323/1350
Rear elbow/shoulder width [mm]	1301/1324	1301/1324	1301/1324	1301/1324	1301/1324	1301/1324
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
