Jeep Grand Cherokee

Date of manufacture

2017 – to this day (Large SUV)

Platform

Manufacturing locations

Detroit, Michigan, USA

Toluca, Mexico

Designer

Mark Allen

Car body style

Large SUV

after upgrade (facelift) (II)

Date of manufacture

2017 – to this day

Internal designation

WK2

Engine size

Petrol

3.6 V6

5.7 V8 HEMI

6.4 V8 SRT HEMI

6.2 V8 HEMI Trackhawk

Diesel

3.0 V6

3.0 V6 Trailhawk

Euro NCAP

Test year 2011

pre-facelift version (2011)

Technical data

Large SUV

	3.6 V6	5.7 V8 HEMI	6.4 V8 SRT HEMI	6.2 V8 HEMI Trackhawk	3.0 V6	3.0 V6
Date of sale	from to 2018	from to 2018	-	from 2019 to	from to 2018	-
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/16	8/16	8/16	6/24	6/24
Engine displacement [cm³]	3604	5654	6417	6166	2987	2987
Maximum output / speed [kW/min-1]	210/6350	259/5200	344/6250	522/6000	140/4000	184/4000
Maximum torque [Nm/min-1]	347/4300	520/4200	624/4100	868/4800	440/1600-2900	570/2000
Bore and stroke [mm x mm]	96.0 x 83.0	99.5 x 90.9	103.9 x 94.6	103.9 x 90.9	83.0 x 92.0	83.0 x 92.0
Compression ratio	10.2:1	10.5:1	10.9:1	9.5:1	16.5:1	16.5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing start&stop system	variable valve timing technology MDS (shuts down four cylinders if necessary)	variable valve timing technology MDS (shuts down four cylinders if necessary)	supercharging by mechanical compressor variable valve timing technology MDS (shuts down four cylinders if necessary)	direct injection Multijet III with Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system	direct injection Multijet III with Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	automatically controlled all-wheel drive eight-speed automatic gearbox	automatically controlled all-wheel drive eight-speed automatic gearbox	permanent all-wheel drive Quadra-Trac 4WD eight-speed automatic gearbox	permanent all-wheel drive Quadra-Trac 4WD eight-speed automatic gearbox	automatically controlled all-wheel drive eight-speed automatic gearbox	automatically controlled all-wheel drive eight-speed automatic gearbox

Top speed [km/h]	206	225	257	289	190	202
Acceleration 0–100 km/h [s]	8.3	7.3	4.9-5.0	3.7	10.2	8.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	13.5	19.6	21.4-20.3	25.4	9.7-8.0	9.8-8.0
Out of town [l]	8.0	9.2	10.7-9.6	12.3	6.9-6.7	7.0-6.7
Combined [l]	10.0	13.0	14.6-13.5	17.1	7.9-7.0	8.0-7.0
CO2 emissions [g/km]	233	304	338-315	395	208-184	212-184

Low speed [l]	-	-	-	-	-	-
Medium speed [l]	-	-	-	-	-	-
High speed [l]	-	-	-	-	-	-
Extra high speed [l]	-	-	-	-	-	-
Combined speed [l]	-	-	-	-	-	-
CO2 emissions [g/km]	-	-	340	382	-	257-246

Emission standard	EU6	EU6	EU6 - Euro 6d-Temp	Euro 6d-Temp	EU6 - Euro 6d-TEMP	EU6 - Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	2266-2354	2382-2499	2418-2458	2531-2558	2403-2522	2403-2573
Overall weight [kg]	2949	2949	2949	2993	2949	2949
Maximum trailer weight unbraked/braked [kg]	750/2268	750/2949	750/2949	750/2949	750/2949-3500	750/2949-3500
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	147	147	175	175
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	782	782	782-800	800	782-800	782-800
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1554	-/1554	-/1554-1689	980/1689	-/1554-1689	-/1554-1689
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	93.5	93.5	93.1	93.1	93.5	93.5
AdBlue tank volume [l]	-	-	-	-	30.3	30.3
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar
Tyre dimensions front	265/50 R20	265/50 R20	295/45 ZR20	295/45 ZR20	265/60 R18	265/60 R18
Tyre dimensions rear	265/50 R20	265/50 R20	295/45 ZR20	295/45 ZR20	265/60 R18	265/60 R18
Wheel size front	-	-	10J x 20	10J x 20	8J x 18	8J x 18
Wheel size rear	-	-	10J x 20	10J x 20	8J x 18	8J x 18
Brake dimensions front	-	-	380 x 34	400 x 36	-	350 x 32
Brake dimensions rear	-	-	350 x 28	350 x 28	-	330 x 22
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.6/-	11.6/-	11.6/-	11.6/-	11.6/-	11.6/-

Overall length [mm]	4828	4828	4846	4846	4828	4828
Overall width without/including mirrors [mm]	1943/2154	1943/2154	1954/-	1954/-	1943/2154	1943/2154
Overall height [mm]	1792	1792	1749	1749	1802	1802
Wheelbase [mm]	2915	2915	2915	2915	2915	2915
Front wheel track [mm]	1628	1628	1669	1669	1628	1628
Rear wheel track [mm]	1634	1634	1661	1661	1634	1634
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	213	216	203	203	218-274	218-274
Wading depth [mm]	-	-	508	508	508	508
Approach angle front [°]	19-25	19-25	18.4	18.4	26.2-30.5	26.2-30.5
Approach angle rear [°]	23	23	21.9	21.9	24-27.8	24-27.8
Transition angle [°]	18-19	18-19	17.8	17.8	19-23.5	19-23.5
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	966	966	966	966	966	966
Headroom rear [mm]	961	961	961	961	961	961
Front elbow/shoulder width [mm]	1491/-	1491/-	1491/-	1491/-	1491/-	1491/-
Rear elbow/shoulder width [mm]	1474/-	1474/-	1474/-	1474/-	1474/-	1474/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	3.0 V6 Trailhawk
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	6/24
Engine displacement [cm³]	2987
Maximum output / speed [kW/min-1]	184/4000
Maximum torque [Nm/min-1]	570/2000
Bore and stroke [mm x mm]	83.0 x 92.0
Compression ratio	16.5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Multijet III with Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	4x4
Gearbox	8 gear automatic
Drive specifications	automatically controlled all-wheel drive eight-speed automatic gearbox

Top speed [km/h]	190
Acceleration 0–100 km/h [s]	8.2
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	9.8
Out of town [l]	7.0
Combined [l]	8.0
CO2 emissions [g/km]	212

Low speed [l]	-
Medium speed [l]	-
High speed [l]	-
Extra high speed [l]	-
Combined speed [l]	-
CO2 emissions [g/km]	257-246

Emission standard	Euro 6d-TEMP
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	2403-2573
Overall weight [kg]	2949
Maximum trailer weight unbraked/braked [kg]	750/2949
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	175
Maximum load on roof/carrier [kg]	-

Boot volume [l]	782-800
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1554-1689
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	93.5
AdBlue tank volume [l]	30.3
Air resistance [Cd]	-
Front suspension	double wishbone
Rear suspension	five-link, stabiliser bar
Tyre dimensions front	265/60 R18
Tyre dimensions rear	265/60 R18
Wheel size front	8J x 18
Wheel size rear	8J x 18
Brake dimensions front	350 x 32
Brake dimensions rear	330 x 22
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	11.6/-

Overall length [mm]	4828
Overall width without/including mirrors [mm]	1943/2154
Overall height [mm]	1802
Wheelbase [mm]	2915
Front wheel track [mm]	1628
Rear wheel track [mm]	1634
Forward overhang [mm]	-
Rear overhang [mm]	-
Clearance [mm]	218-274
Wading depth [mm]	508
Approach angle front [°]	26.2-30.5
Approach angle rear [°]	24-27.8
Transition angle [°]	19-23.5
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	966
Headroom rear [mm]	961
Front elbow/shoulder width [mm]	1491/-
Rear elbow/shoulder width [mm]	1474/-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Jeep Grand Cherokee WK2 facelift 2017 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
