Jaguar XJ
Date of manufacture
2015 – 2019 (Sedan)
Platform
-
Manufacturing locations
Birmingham, United Kingdom
Designer
Ian Callum
Tags
F-segment
British cars
Since 2015, the Jaguar XJ has been produced in the United Kingdom as a sedan. It offers a wide range of petrol and diesel engines, the most powerful of which is the XJR with 423 kW. It is also the fastest model with a top speed of 300 km/h and the best acceleration from 0-100 km/h in 4.4 seconds. The most fuel-efficient variant is the 3.0 L V6 DIESEL, which has a combined fuel consumption of 5.7 l/100 km and CO2 emissions of 149 g/km. The luggage compartment volume is 478 l.
Car body style
Sedan
after upgrade (facelift)
Date of manufacture
2015 – 2019Internal designation
X351 Technical data
Sedan
| 3.0 L V6 KOMPRESOR | 3.0 L V6 KOMPRESOR LWB | 5.0 Supercharged | 5.0 Supercharged LWB | XJR | XJR | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from to 2018 | from to 2018 | from to 2018 | from to 2017 | from 2017 to 2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 8/32 | 8/32 | 8/32 | 8/32 |
| Engine displacement [cm³] | 2995 | 2995 | 5000 | 5000 | 5000 | 5000 |
| Maximum output / speed [kW/min-1] | 250/6500 | 250/6500 | 375/6000-6500 | 375/6000-6500 | 405/6000-6500 | 423/6250-6500 |
| Maximum torque [Nm/min-1] | 450/3500-5000 | 450/3500-5000 | 625/2500-5500 | 625/2500-5500 | 680/3500-4000 | 700/3500-4500 |
| Bore and stroke [mm x mm] | 84,5 x 89,0 | 84,5 x 89,0 | 92,5 x 93,0 | 92,5 x 93,0 | 92,5 x 93,0 | 92,5 x 93,0 |
| Compression ratio | 10,5:1 | 10,5:1 | 9,5:1 | 9,5:1 | 9,5:1 | 9,6:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 300 |
| Acceleration 0–100 km/h [s] | 6.4 | 6.4 | 4.9 | 4.9 | 4.6 | 4.4 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 13.6 | 13.6 | 16.2 | 16.2 | 16.2 | 16.2 |
| Out of town [l] | 7.6 | 7.6 | 8.2 | 8.2 | 8.2 | 8.2 |
| Combined [l] | 9.8 | 9.8 | 11.1 | 11.1 | 11.1 | 11.1 |
| CO2 emissions [g/km] | 234 | 234 | 264 | 264 | 264 | 264 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1865 | 1875 | 1875 | 1875 | 1875 | 1875 |
| Overall weight [kg] | 2430 | 2450 | 2400 | 2400 | 2400 | 2400 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 478 | 478 | 478 | 478 | 478 | 478 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 |
| Fuel tank volume [l] | 80 | 80 | 80 | 80 | 80 | 80 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Tyre dimensions front | 245/45 ZR19 | 245/45 ZR19 | 265/35 R20 | 265/35 R20 | 265/35 R20 | 265/35 R20 |
| Tyre dimensions rear | 275/40 ZR19 | 275/40 ZR19 | 295/30 R20 | 295/30 R20 | 295/30 R20 | 295/30 R20 |
| Wheel size front | 9.0J x 19 | 9.0J x 19 | 9.0J x 20 | 9.0J x 20 | 9.0J x 20 | 9.0J x 20 |
| Wheel size rear | 10.0J x 19 | 10.0J x 19 | 10.0J x 20 | 10.0J x 20 | 10.0J x 20 | 10.0J x 20 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.4/- | 12.9/- | 11.9 | 11.9 | 12.4/- | 11.9 |
| Overall length [mm] | 5130 | 5255 | 5130 | 5255 | 5130 | 5130 |
| Overall width without/including mirrors [mm] | 1899/- | 1899/- | 1899/2105 | 1899/2105 | 1899/- | 1899/- |
| Overall height [mm] | 1460 | 1460 | 1460 | 1460 | 1460 | 1460 |
| Wheelbase [mm] | 3032 | 3157 | 3032 | 3157 | 3032 | 3032 |
| Front wheel track [mm] | 1626 | 1626 | 1626 | 1626 | 1626 | 1626 |
| Rear wheel track [mm] | 1604 | 1604 | 1604 | 1604 | 1604 | 1604 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1004 | 1004 | 1004 | 1004 | 1004 | 1004 |
| Headroom rear [mm] | 946 | 946 | 946 | 946 | 946 | 946 |
| Front elbow/shoulder width [mm] | -/1464 | -/1464 | -/1464 | -/1464 | -/1464 | -/1464 |
| Rear elbow/shoulder width [mm] | -/1437 | -/1437 | -/1437 | -/1437 | -/1437 | -/1437 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 3.0 L V6 DIESEL | 3.0 L V6 DIESEL LWB | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 6/24 | 6/24 | ||||
| Engine displacement [cm³] | 2993 | 2993 | ||||
| Maximum output / speed [kW/min-1] | 221/4000 | 221/4000 | ||||
| Maximum torque [Nm/min-1] | 700/2000 | 700/2000 | ||||
| Bore and stroke [mm x mm] | 84,5 x 89,0 | 84,5 x 89,0 | ||||
| Compression ratio | 10,5:1 | 10,5:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | Rear | Rear | ||||
| Gearbox | 8 gear automatic | 8 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 250 | 250 | ||||
| Acceleration 0–100 km/h [s] | 6.2 | 6.2 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 7.0 | 7.0 | ||||
| Out of town [l] | 5.2 | 5.2 | ||||
| Combined [l] | 5.7 | 5.7 | ||||
| CO2 emissions [g/km] | 149 | 149 | ||||
| Emission standard | EU6 | EU6 | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1835 | 1860 | ||||
| Overall weight [kg] | 2400 | 2450 | ||||
| Maximum trailer weight unbraked/braked [kg] | - | - | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | - | - | ||||
| Maximum load on roof/carrier [kg] | - | - | ||||
| Boot volume [l] | 478 | 478 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 4 | 4 | ||||
| Number of seats | 4-5 | 4-5 | ||||
| Fuel tank volume [l] | 77 | 77 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.29 | 0.29 | ||||
| Front suspension | double wishbone | double wishbone | ||||
| Rear suspension | double wishbone | double wishbone | ||||
| Tyre dimensions front | 245/45 ZR19 | 245/45 ZR19 | ||||
| Tyre dimensions rear | 275/40 ZR19 | 275/40 ZR19 | ||||
| Wheel size front | 9.0J x 19 | 9.0J x 19 | ||||
| Wheel size rear | 10.0J x 19 | 10.0J x 19 | ||||
| Brake dimensions front | - | - | ||||
| Brake dimensions rear | - | - | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 11.9/- | 12.3/- | ||||
| Overall length [mm] | 5130 | 5255 | ||||
| Overall width without/including mirrors [mm] | 1899/- | 1899/- | ||||
| Overall height [mm] | 1460 | 1460 | ||||
| Wheelbase [mm] | 3032 | 3157 | ||||
| Front wheel track [mm] | 1626 | 1626 | ||||
| Rear wheel track [mm] | 1604 | 1604 | ||||
| Forward overhang [mm] | - | - | ||||
| Rear overhang [mm] | - | - | ||||
| Clearance [mm] | - | - | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1004 | 1004 | ||||
| Headroom rear [mm] | 946 | 946 | ||||
| Front elbow/shoulder width [mm] | -/1464 | -/1464 | ||||
| Rear elbow/shoulder width [mm] | -/1437 | -/1437 | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
