Jaguar F-Pace
Date of manufacture
2020 – to this day (Medium SUV)
Platform
JLR D7a
Manufacturing locations
Solihull, United Kingdom
Designer
Ian Callum
Tags
Compact SUV
British cars
The Jaguar F-Pace is a mid-size SUV produced by the British carmaker since 2020. It is built on the JLR D7a platform and offers petrol, diesel and hybrid powertrains. The most powerful model SVR P550 AWD has a power output of 405 kW and reaches a top speed of 286 km/h with the best acceleration from 0-100 km/h in 4.0 seconds. The most efficient variant is the P400e AWD with a combined fuel consumption of 2.4 l/100 km and CO2 emissions of 54 g/km. The boot has a capacity of 619 l. In terms of safety, EURONCAP rated this model 5 out of 5 in 2017.
Car body style
Technical data
Medium SUV
| P250 AWD | P340 AWD | P400 AWD | SVR P550 AWD | P400e AWD | D165 AWD | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 6/24 | 6/24 | 8/32 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1997 | 2995 | 2995 | 5000 | 1997 | 1997 |
| Maximum output / speed [kW/min-1] | 184/5500 | 250/5500-6500 | 294/5500-6500 | 405/6250-6500 | 297/5500 | 120/4250 |
| Maximum torque [Nm/min-1] | 365/1300-4500 | 480/1500-4500 | 550/2000-5000 | 680/3500-5000 | 640/1500-4400 | 380/1500-2500 |
| Bore and stroke [mm x mm] | 83.0 x 92.3 | 83.0 x 92.3 | 83.0 x 92.3 | 92.5 x 93.0 | 83.0 x 92.3 | 83.0 x 92.3 |
| Compression ratio | 10.5:1 | 9.5:1 | 9.5:1 | 9.5:1 | 9.5:1 | 16.5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 217 | 240 | 250 | 286 | 240 [140 el.] | 195 |
| Acceleration 0–100 km/h [s] | 7,3 | 6.1 | 5,4 | 4,0 | 5,3 | 9,9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 5,1 | 3.9 | 3,2 | 2,4 | 3,3 | 7,6 |
| City [l] | 9,6-9,4 | - | 11,9 | 15,8 | - | 5,8-5,7 |
| Out of town [l] | 6,8-6,7 | - | 7,2 | 8,9 | - | 4,9 |
| Combined [l] | 7,8-7,7 | - | 8,9 | 11,4 | 2.4 [17.6-17.5 kWh] | 5,2 |
| CO2 emissions [g/km] | 177-174 | - | 202 | 260 | 54 | 138-137 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 10.1-9.3 | - | 10.4-9.8 | 12.2 | - | 6.7-6.2 |
| CO2 emissions [g/km] | 228-209 | - | 234-221 | 275 | - | 176-163 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | 48 | 48 | - | - | 48 |
| Battery type and capacity | - | Lithium-Ionen-Akkumulator, - A⋅h | Lithium-Ionen-Akkumulator, - A⋅h | - | Lithium-ion, 17.1 kWh (13.6 net) | Lithium-Ionen-Akkumulator, - A⋅h |
| Range with fully charged battery [km] | - | - | - | - | 47-53 | - |
| Charging time | - | - | - | - |
| - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1897 | 1953 | 2028 | 2133 | 2189 | 1951 |
| Overall weight [kg] | 2520 | - | 2600 | 2590 | 2690 | 2540 |
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | - | 750/2400 | 750/2400 | 750/2000 | 750/2400 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 793 | 755 | 755 | 793 | 619 | 755 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1842 | -/1804 | -/1804 | -/1842 | -/1662 | -/1804 |
| Boot length [mm] | 1005 | 1005 | 1005 | 1005 | 1018 | 1005 |
| Boot length with rear seats folded [mm] | 1824 | 1824 | 1824 | 1824 | 1852 | 1824 |
| Boot width between wheels/max [mm] | 1048/1091 | 1048/1091 | 1048/1091 | 1048/1091 | 1048/1299 | 1048/1091 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 750 | 750 | 750 | 750 | 750 | 750 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 82 | 82 | 82 | 82 | 69 | 60 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.32 | 0.33 | 0.33 | 0.36 | 0.34 | 0.31 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension |
| Tyre dimensions front | - | - | - | - | - | - |
| Tyre dimensions rear | - | - | - | - | - | - |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 350 | 370 | 370 | 395 | - | 350 |
| Brake dimensions rear | 325 | 325 | 325 | 396 | - | 325 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 2.52 | 2.52 | 2.52 | 2.52 | 2.52 | 2.52 |
| Turning diameter track/circumference [m] | 11.93/- | 11.93/- | 11.93/- | 12.01/- | 11.93/- | 11.93/- |
| Overall length [mm] | 4747 | 4747 | 4747 | 4762 | 4747 | 4747 |
| Overall width without/including mirrors [mm] | -/2071 | -/2071 | -/2071 | -/2071 | -/2071 | -/2071 |
| Overall height [mm] | 1664 | 1664 | 1664 | 1670 | 1664 | 1664 |
| Wheelbase [mm] | 2874 | 2874 | 2874 | 2874 | 2874 | 2874 |
| Front wheel track [mm] | 1640 | 1640 | 1640 | 1648 | 1640 | 1640 |
| Rear wheel track [mm] | 1656 | 1656 | 1656 | 1666 | 1656 | 1656 |
| Forward overhang [mm] | 845 | 845 | 845 | 866 | 845 | 845 |
| Rear overhang [mm] | 1028 | 1028 | 1028 | 1022 | 1028 | 1028 |
| Clearance [mm] | 213 | 213 | 213 | 213 | 213 | 213 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 22.5 | 22.5 | 22.5 | 20.5 | 22.5 | 22.5 |
| Approach angle rear [°] | 22.9 | 22.9 | 22.9 | 23.1 | 22.9 | 22.9 |
| Transition angle [°] | 19.0 | 19.0 | 19.0 | 20.7 | 19.0 | 19.0 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 960 | 960 | 960 | 960 | 960 | 960 |
| Headroom rear [mm] | 952 | 952 | 952 | 952 | 952 | 952 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | -/1023 | -/1023 | -/1023 | -/1023 | -/1023 | -/1023 |
| Legroom rear knees/total [mm] | -/944 | -/944 | -/944 | -/944 | -/944 | -/944 |
| D200 AWD | D300 AWD | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 6/24 | ||||
| Engine displacement [cm³] | 1997 | 2996 | ||||
| Maximum output / speed [kW/min-1] | 150/4250 | 221/4000 | ||||
| Maximum torque [Nm/min-1] | 430/1500-2500 | 650/1500-2500 | ||||
| Bore and stroke [mm x mm] | 83.0 x 92.3 | 83.0 x 92.3 | ||||
| Compression ratio | 16.5:1 | 15.5:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | 4x4 | ||||
| Gearbox | 8 gear automatic | 8 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 210 | 230 | ||||
| Acceleration 0–100 km/h [s] | 8,0 | 6,4 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | 5,8 | 4,4 | ||||
| City [l] | 5,8-5,7 | 9,0 | ||||
| Out of town [l] | 4,9 | 5,8 | ||||
| Combined [l] | 5,2 | 6,9 | ||||
| CO2 emissions [g/km] | 138-137 | 183 | ||||
| Low speed [l] | - | - | ||||
| Medium speed [l] | - | - | ||||
| High speed [l] | - | - | ||||
| Extra high speed [l] | - | - | ||||
| Combined speed [l] | 6.7-6.2 | 7.8-7.4 | ||||
| CO2 emissions [g/km] | 176-163 | 206-194 | ||||
| Emission standard | Euro 6d | Euro 6d | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| System voltage [V] | 48 | 48 | ||||
| Battery type and capacity | Lithium-Ionen-Akkumulator, - A⋅h | Lithium-Ionen-Akkumulator, - A⋅h | ||||
| Range with fully charged battery [km] | - | - | ||||
| Charging time | - | - | ||||
| Number of modules/cells | - | - | ||||
| Battery weight [kg] | - | - | ||||
| Charger | - | - | ||||
| Standby weight [kg] | 1951 | 2083 | ||||
| Overall weight [kg] | 2540 | 2660 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | 750/2400 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | - | - | ||||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | ||||
| Boot volume [l] | 755 | 755 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1804 | -/1804 | ||||
| Boot length [mm] | 1005 | 1005 | ||||
| Boot length with rear seats folded [mm] | 1824 | 1824 | ||||
| Boot width between wheels/max [mm] | 1048/1091 | 1048/1091 | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | 750 | 750 | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 60 | 66 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.31 | 0.33 | ||||
| Front suspension | double wishbone | double wishbone | ||||
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | ||||
| Tyre dimensions front | - | - | ||||
| Tyre dimensions rear | - | - | ||||
| Wheel size front | - | - | ||||
| Wheel size rear | - | - | ||||
| Brake dimensions front | 350 | 370 | ||||
| Brake dimensions rear | 325 | 325 | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | 2.52 | 2.52 | ||||
| Turning diameter track/circumference [m] | 11.93/- | 11.93/- | ||||
| Overall length [mm] | 4747 | 4747 | ||||
| Overall width without/including mirrors [mm] | -/2071 | -/2071 | ||||
| Overall height [mm] | 1664 | 1664 | ||||
| Wheelbase [mm] | 2874 | 2874 | ||||
| Front wheel track [mm] | 1640 | 1640 | ||||
| Rear wheel track [mm] | 1656 | 1656 | ||||
| Forward overhang [mm] | 845 | 845 | ||||
| Rear overhang [mm] | 1028 | 1028 | ||||
| Clearance [mm] | 213 | 213 | ||||
| Wading depth [mm] | 500 | 500 | ||||
| Approach angle front [°] | 22.5 | 22.5 | ||||
| Approach angle rear [°] | 22.9 | 22.9 | ||||
| Transition angle [°] | 19.0 | 19.0 | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 960 | 960 | ||||
| Headroom rear [mm] | 952 | 952 | ||||
| Front elbow/shoulder width [mm] | - | - | ||||
| Rear elbow/shoulder width [mm] | - | - | ||||
| Legroom front knees/total [mm] | -/1023 | -/1023 | ||||
| Legroom rear knees/total [mm] | -/944 | -/944 |
