Jaguar E-Pace
Date of manufacture
2020 – to this day (Medium SUV)
Platform
JLR PTA
Manufacturing locations
Graz, Austria
Changshu, People's Republic of China
Designer
Ian Callum
Tags
Compact SUV
British cars
The Jaguar E-Pace can be purchased in a mid-size SUV body style. The vehicle has been manufactured since 2020. Production of the model takes place in countries such as Austria and the People's Republic of China. The vehicle is built on the JLR PTA platform. Plug-in hybrid models are also available. The list of power units includes gasoline, diesel and hybrid engines. The maximum power has the P300e AWD power unit and that is 227 kW. The P300 AWD is the fastest version available. The top speed is 241 km/h. The best acceleration 0-100 km/h in 6.5 seconds has the P300e AWD model. The most economical model is the P300e AWD with a combined consumption of 2 l/100 km and CO2 emissions of 43 g/km. The volume of the luggage compartment is 601 l. In the safety area, EURONCAP awarded the model a rating of 5 out of 5 in 2017.
Car body style
Technical data
Medium SUV
| P160 | P200 AWD | P250 AWD | P300 AWD | P300e AWD | D165 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | 3/12 | 4/16 |
| Engine displacement [cm³] | 1498 | 1997 | 1997 | 1997 | 1498 | 1997 |
| Maximum output / speed [kW/min-1] | 118/5500 | 147/5500 | 184/5500 | 221/5500 | 227/5500 | 120/4250 |
| Maximum torque [Nm/min-1] | 260/1600-4000 | 320/1200-4000 | 365/1300-4500 | 400/1500-4500 | 540/1600-4500 | 380/1500-2500 |
| Bore and stroke [mm x mm] | 83.0 x 92.3 | 83.0 x 92.3 | 83.0 x 92.3 | 83.0 x 92.3 | 83.0 x 92.3 | 83.0 x 92.3 |
| Compression ratio | 10.5:1 | 10.5:1 | 10.5:1 | 10.5:1 | 10.5:1 | 16.5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | 4x4 | 4x4 | 4x4 | 4x4 | Front |
| Gearbox | 8 gear automatic | 9 gear automatic | 9 gear automatic | 9 gear automatic | 8 gear automatic | 6 gear manual |
| Drive specifications |
|
|
|
|
| - |
| Top speed [km/h] | 197 | 212 | 229 | 241 | 216 | 206 |
| Acceleration 0–100 km/h [s] | 10.3 | 8.5 | 7.5 | 6.9 | 6.5 | 10.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 7.1 | 6.2 | 5.1 | 4.7 | 4.2 | 6.9 |
| City [l] | 8.1 | 10.5-10.3 | 10.5-10.3 | 9.9-9.5 | - | 5.9-5.6 |
| Out of town [l] | 6.0 | 6.4-6.2 | 6.5-6.3 | 6.7-6.6 | - | 5.1-4.6 |
| Combined [l] | 6.8 | 7.9-7.7 | 7.9-7.7 | 7.9-7.7 | 2.0 [15.9 kWh] | 5.4-5.0 |
| CO2 emissions [g/km] | 154 | 179-175 | 180-175 | 179-175 | 45-43 | 141-131 |
| Low speed [l] | 10.3-10.1 | 12.6-11.9 | 12.6-11.9 | 12.4-12.1 | - | 8.3-7.6 |
| Medium speed [l] | 8.1-7.7 | 9.5-8.8 | 9.5-8.8 | 9.7-9.1 | - | 6.9-6.0 |
| High speed [l] | 7.1-6.7 | 8.2-7.6 | 8.3-7.6 | 8.3-7.6 | - | 5.9-5.2 |
| Extra high speed [l] | 9.0-8.5 | 9.8-8.9 | 9.9-8.9 | 9.9-9.1 | - | 7.0-6.2 |
| Combined speed [l] | 8.4-8.0 | 9.7-8.9 | 9.7-8.9 | 9.7-9.0 | - | 6.8-6.0 |
| CO2 emissions [g/km] | 189-181 | 218-200 | 218-200 | 218-204 | - | 179-158 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | - | - | - | - | Lithium-Ionen-Akkumulator, 15 kWh | - |
| Range with fully charged battery [km] | - | - | - | - | 55 | - |
| Charging time | - | - | - | - |
| - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1783 | 1847 | 1889 | 1952 | 2173 | 1809 |
| Overall weight [kg] | 2300 | 2430 | 2430 | 2450 | 2670 | 2360 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/1800 | 750/1800 | 750/1800 | 750/1600 | 750/1600 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 601 [494 VDA] | 601 [494 VDA] | 601 [494 VDA] | 601 [494 VDA] | 601 [494 VDA] | 601 [494 VDA] |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1386 [- | -/1386 [- | -/1386 [- | -/1386 [- | -/1386 [- | -/1386 [- |
| Boot length [mm] | 806 | 806 | 806 | 806 | 806 | 806 |
| Boot length with rear seats folded [mm] | 1568 | 1568 | 1568 | 1568 | 1568 | 1568 |
| Boot width between wheels/max [mm] | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 |
| Boot height to headliner/ceiling [mm] | -/748 | -/748 | -/748 | -/748 | -/748 | -/748 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 57.6 | 54 [65 subject to a surcharge] |
| AdBlue tank volume [l] | - | - | - | - | - | 17 |
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | 0.34 | 0.34 | 0.32 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension |
| Tyre dimensions front | 225/65 R17 | 225/65 R17 | 235/60 R18 | 235/60 R18 | 235/60 R18 | 225/65 R17 |
| Tyre dimensions rear | 225/65 R17 | 225/65 R17 | 235/60 R18 | 235/60 R18 | 235/60 R18 | 225/65 R17 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 7.0J x 17 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 7.0J x 17 |
| Brake dimensions front | 325 [349 subject to a surcharge] | 325 [349 subject to a surcharge] | 349 | 349 | 349 | 325 [349 subject to a surcharge] |
| Brake dimensions rear | 300 | 300 | 325 | 325 | 325 | 300 |
| Steering | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS |
| Number of steering wheel turns | 2.31 | 2.31 | 2.31 | 2.31 | 2.31 | 2.31 |
| Turning diameter track/circumference [m] | 11.63/- | 11.63/- | 11.63/- | 11.63/- | 11.63/- | 11.63/- |
| Overall length [mm] | 4395 | 4395 | 4395 | 4395 | 4395 | 4395 |
| Overall width without/including mirrors [mm] | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 |
| Overall height [mm] | 1648 | 1648 | 1648 | 1648 | 1648 | 1648 |
| Wheelbase [mm] | 2681 | 2681 | 2681 | 2681 | 2681 | 2681 |
| Front wheel track [mm] | 1625 | 1625 | 1625 | 1625 | 1625 | 1625 |
| Rear wheel track [mm] | 1624 | 1624 | 1624 | 1624 | 1624 | 1624 |
| Forward overhang [mm] | 882 | 882 | 882 | 882 | 882 | 882 |
| Rear overhang [mm] | 832 | 832 | 832 | 832 | 832 | 832 |
| Clearance [mm] | 212 | 212 | 212 | 212 | 212 | 212 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 22 | 22 | 22 | 22 | 22 | 22 |
| Approach angle rear [°] | 28 | 28 | 28 | 28 | 28 | 28 |
| Transition angle [°] | 20.7 | 20.7 | 20.7 | 20.7 | 20.7 | 20.7 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 976 | 976 | 976 | 976 | 976 | 976 |
| Headroom rear [mm] | 974 | 974 | 974 | 974 | 974 | 974 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | -/1030 | -/1030 | -/1030 | -/1030 | -/1030 | -/1030 |
| Legroom rear knees/total [mm] | -/872 | -/872 | -/872 | -/872 | -/872 | -/872 |
| D165 AWD | D200 AWD | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1997 | 1997 | ||||
| Maximum output / speed [kW/min-1] | 120/4250 | 150/4250 | ||||
| Maximum torque [Nm/min-1] | 380/1500-2500 | 430/1500-2500 | ||||
| Bore and stroke [mm x mm] | 83.0 x 92.3 | 83.0 x 92.3 | ||||
| Compression ratio | 16.5:1 | 16.5:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | 4x4 | ||||
| Gearbox | 9 gear automatic | 9 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 200 | 211 | ||||
| Acceleration 0–100 km/h [s] | 9.8 | 8.4 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | 7.8 | 6.2 | ||||
| City [l] | 6.2-6.0 | 6.2-6.0 | ||||
| Out of town [l] | 5.0-4.9 | 5.0-4.9 | ||||
| Combined [l] | 5.4-5.2 | 5.4-5.3 | ||||
| CO2 emissions [g/km] | 143-139 | 144-140 | ||||
| Low speed [l] | 7.8-7.3 | 7.8-7.4 | ||||
| Medium speed [l] | 7.1-6.5 | 7.2-6.6 | ||||
| High speed [l] | 6.1-5.6 | 6.2-5.6 | ||||
| Extra high speed [l] | 7.2-6.7 | 7.4-6.7 | ||||
| Combined speed [l] | 6.9-6.4 | 7.0-6.4 | ||||
| CO2 emissions [g/km] | 182-167 | 185-169 | ||||
| Emission standard | Euro 6d | Euro 6d | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| System voltage [V] | 48 | 48 | ||||
| Battery type and capacity | Lithium-Ionen-Akkumulator, - A⋅h | Lithium-Ionen-Akkumulator, - A⋅h | ||||
| Range with fully charged battery [km] | - | - | ||||
| Charging time | - | - | ||||
| Number of modules/cells | - | - | ||||
| Battery weight [kg] | - | - | ||||
| Charger | - | - | ||||
| Standby weight [kg] | 1916 | 1952 | ||||
| Overall weight [kg] | 2470 | 2470 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/1800 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | 100 | 100 | ||||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | ||||
| Boot volume [l] | 601 [494 VDA] | 601 [494 VDA] | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1386 [- | -/1386 [- | ||||
| Boot length [mm] | 806 | 806 | ||||
| Boot length with rear seats folded [mm] | 1568 | 1568 | ||||
| Boot width between wheels/max [mm] | 1057/1311 | 1057/1311 | ||||
| Boot height to headliner/ceiling [mm] | -/748 | -/748 | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 54 [65 subject to a surcharge] | 54 [65 subject to a surcharge] | ||||
| AdBlue tank volume [l] | 17 | 17 | ||||
| Air resistance [Cd] | 0.32 | 0.32 | ||||
| Front suspension | MacPherson | MacPherson | ||||
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | ||||
| Tyre dimensions front | 225/65 R17 | 235/60 R18 | ||||
| Tyre dimensions rear | 225/65 R17 | 235/60 R18 | ||||
| Wheel size front | 7.0J x 17 | 8.0J x 18 | ||||
| Wheel size rear | 7.0J x 17 | 8.0J x 18 | ||||
| Brake dimensions front | 325 [349 subject to a surcharge] | 349 | ||||
| Brake dimensions rear | 300 | 300 | ||||
| Steering | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | ||||
| Number of steering wheel turns | 2.31 | 2.31 | ||||
| Turning diameter track/circumference [m] | 11.63/- | 11.63/- | ||||
| Overall length [mm] | 4395 | 4395 | ||||
| Overall width without/including mirrors [mm] | 1984/2088 | 1984/2088 | ||||
| Overall height [mm] | 1648 | 1648 | ||||
| Wheelbase [mm] | 2681 | 2681 | ||||
| Front wheel track [mm] | 1625 | 1625 | ||||
| Rear wheel track [mm] | 1624 | 1624 | ||||
| Forward overhang [mm] | 882 | 882 | ||||
| Rear overhang [mm] | 832 | 832 | ||||
| Clearance [mm] | 212 | 212 | ||||
| Wading depth [mm] | 500 | 500 | ||||
| Approach angle front [°] | 22 | 22 | ||||
| Approach angle rear [°] | 28 | 28 | ||||
| Transition angle [°] | 20.7 | 20.7 | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 976 | 976 | ||||
| Headroom rear [mm] | 974 | 974 | ||||
| Front elbow/shoulder width [mm] | - | - | ||||
| Rear elbow/shoulder width [mm] | - | - | ||||
| Legroom front knees/total [mm] | -/1030 | -/1030 | ||||
| Legroom rear knees/total [mm] | -/872 | -/872 |
