Jaguar E-Pace
Date of manufacture
2017 – 2020 (Medium SUV)
Platform
JLR PTA
Manufacturing locations
Graz, Austria
Changshu, People's Republic of China
Designer
Ian Callum
Tags
Compact SUV
British cars
The Jaguar E-Pace is a mid-size SUV that has been manufactured since 2017. This luxury vehicle can be made in two countries - Austria and China. The JLR PTA platform provides a list of power units with the highest power of 221 kW, speed of 243 km/h and the best acceleration 0-100 km/h in 6.5 seconds, which is offered by the P300 AWD model. The lowest consumption of 4.7 l/100 km and emissions of 124 g/km are offered by the D150 models. The luggage compartment has a volume of 577 liters. The car successfully passed the EURONCAP safety tests and received a rating of 5 out of 5.
Car body style
Technical data
Medium SUV
| P200 AWD | P250 AWD | P300 AWD | D150 | D150 AWD | D150 AWD | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1998 | 1998 | 1998 | 1999 | 1999 | 1999 |
| Maximum output / speed [kW/min-1] | 146/5500 | 183/5500 | 221/5500 | 110/3500 | 110/3500 | 110/3500 |
| Maximum torque [Nm/min-1] | 340/1250 | 365/1200-4500 | 400/1500-4500 | 380/1750 | 380/1750 | 380/1750 |
| Bore and stroke [mm x mm] | 83.0 x 92.3 | 83.0 x 92.99 | 83.0 x 92.99 | 83,0 x 92,3 | 83,0 x 92,3 | 83,0 x 92,3 |
| Compression ratio | 10,5:1 | 10,5:1 | 9.5:1 | 15,5:1 | 15,5:1 | 15,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | Rear | 4x4 | 4x4 |
| Gearbox | 9 gear automatic | 9 gear automatic | 9 gear automatic | 6 gear manual | 6 gear manual | 9 gear automatic |
| Drive specifications |
|
|
| - |
|
|
| Top speed [km/h] | 216 | 230 | 243 | 199 | 194 | 193 |
| Acceleration 0–100 km/h [s] | 8.2 | 7.1 | 6.5 | 10.1 | 10.7 | 10.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | 9.5 | 9.7 | 5.8-5.6 | 6.0 | 6.5 |
| Out of town [l] | - | 6.6 | 7.0 | 4.4-4.2 | 4.8 | 5.1 |
| Combined [l] | - | 7.7 | 8.0 | 4.9-4.7 | 5.2 | 5.6 |
| CO2 emissions [g/km] | - | 174 | 181 | 129-124 | 137 | 147 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 8.2 | 8.2 | 8.5 | - | - | - |
| CO2 emissions [g/km] | 216 | 186 | 194 | - | - | - |
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1832 | 1832 | 1894 | 1775 | 1831 | 1843 |
| Overall weight [kg] | 2400 | 2400 | 2400 | 2320 | 2400 | 2400 |
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | 750/2400 | 750/2400 | 750/1600 | 750/1800 | 750/1800 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 577 | 577 | 577 | 577 | 577 | 577 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1234 | -/1234 | -/1234 | -/1234 | -/1234 | -/1234 |
| Boot length [mm] | 806 | 806 | 806 | 806 | 806 | 806 |
| Boot length with rear seats folded [mm] | 1568 | 1568 | 1568 | 1568 | 1568 | 1568 |
| Boot width between wheels/max [mm] | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 | 1057/1311 |
| Boot height to headliner/ceiling [mm] | -/748 | -/748 | -/748 | -/748 | -/748 | -/748 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 705 | 705 | 705 | 705 | 705 | 705 |
| Boot opening width min/max [mm] | -/994 | -/994 | -/994 | -/994 | -/994 | -/994 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 69 | 69 | 69 | 56 | 56 | 56 |
| AdBlue tank volume [l] | - | - | - | 16 | 16 | 16 |
| Air resistance [Cd] | 0.34 | 0.34 | 0.36 | 0.325 | 0.325 | 0.325 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension |
| Tyre dimensions front | 225/65 R17 | 225/65 R17 | 235/60 R18 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Tyre dimensions rear | 225/65 R17 | 225/65 R17 | 235/60 R18 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Brake dimensions front | 325 | 325 [349 subject to a surcharge] | 349 | 325 | 325 | 325 |
| Brake dimensions rear | 300 | 300 | 300 | 300 | 300 | 300 |
| Steering | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS |
| Number of steering wheel turns | 2.31 | 2.31 | 2.31 | 2.31 | 2.31 | 2.31 |
| Turning diameter track/circumference [m] | 11,46/- | 11,46/- | 11,46/- | 11,46/- | 11,46/- | 11,46/- |
| Overall length [mm] | 4395 | 4395 | 4395 | 4395 | 4395 | 4395 |
| Overall width without/including mirrors [mm] | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 | 1984/2088 |
| Overall height [mm] | 1649 | 1649 | 1649 | 1649 | 1649 | 1649 |
| Wheelbase [mm] | 2681 | 2681 | 2681 | 2681 | 2681 | 2681 |
| Front wheel track [mm] | 1625 | 1625 | 1625 | 1625 | 1625 | 1625 |
| Rear wheel track [mm] | 1624 | 1624 | 1624 | 1624 | 1624 | 1624 |
| Forward overhang [mm] | 882 | 882 | 882 | 882 | 882 | 882 |
| Rear overhang [mm] | 832 | 832 | 832 | 832 | 832 | 832 |
| Clearance [mm] | 204 | 204 | 204 | 204 | 204 | 204 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 22.8 | 22.8 | 22.8 | 22.8 | 22.8 | 22.8 |
| Approach angle rear [°] | 21.1 | 21.1 | 21.1 | 21.1 | 21.1 | 21.1 |
| Transition angle [°] | 29.4 | 29.4 | 29.4 | 29.4 | 29.4 | 29.4 |
| Climbing rate [°] | 45 | 45 | 45 | 45 | 45 | 45 |
| Maximum side tilt [°] | 35 | 35 | 35 | 35 | 35 | 35 |
| Headroom front [mm] | 996 | 996 | 996 | 996 | 996 | 996 |
| Headroom rear [mm] | 970 | 970 | 970 | 970 | 970 | 970 |
| Front elbow/shoulder width [mm] | -/1425 | -/1425 | -/1425 | -/1425 | -/1425 | -/1425 |
| Rear elbow/shoulder width [mm] | -/1417 | -/1417 | -/1417 | -/1417 | -/1417 | -/1417 |
| Legroom front knees/total [mm] | -/1018 | -/1018 | -/1018 | -/1018 | -/1018 | -/1018 |
| Legroom rear knees/total [mm] | -/892 | -/892 | -/892 | -/892 | -/892 | -/892 |
| D180 AWD | D180 AWD | D240 AWD | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1999 | 1999 | 1999 | |||
| Maximum output / speed [kW/min-1] | 132/4000 | 132/4000 | 177/4000 | |||
| Maximum torque [Nm/min-1] | 430/1750-2500 | 430/1750-2500 | 500/1500-2500 | |||
| Bore and stroke [mm x mm] | 83,0 x 92,3 | 83,0 x 92,3 | 83,0 x 92,4 | |||
| Compression ratio | 15,5:1 | 15,5:1 | 15,5:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | 4x4 | 4x4 | 4x4 | |||
| Gearbox | 6 gear manual | 9 gear automatic | 9 gear automatic | |||
| Drive specifications | - |
|
| |||
| Top speed [km/h] | 207 | 205 | 224 | |||
| Acceleration 0–100 km/h [s] | 9.9 | 9.3 | 7.4 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 6.0 | 9.8 | 7.2 | |||
| Out of town [l] | 4.8 | 5.1 | 5.5 | |||
| Combined [l] | 5.2 | 5.6 | 6.2 | |||
| CO2 emissions [g/km] | 137 | 147 | 162 | |||
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1831 | 1843 | 1926 | |||
| Overall weight [kg] | 2400 | 2400 | 2420 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/1800 | 750/1800 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | - | - | - | |||
| Boot volume [l] | 577 | 577 | 577 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1234 | -/1234 | -/1234 | |||
| Boot length [mm] | 806 | 806 | 806 | |||
| Boot length with rear seats folded [mm] | 1568 | 1568 | 1568 | |||
| Boot width between wheels/max [mm] | 1057/1311 | 1057/1311 | 1057/1311 | |||
| Boot height to headliner/ceiling [mm] | -/748 | -/748 | -/748 | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | 705 | 705 | 705 | |||
| Boot opening width min/max [mm] | -/994 | -/994 | -/994 | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 56 | 56 | 56 | |||
| AdBlue tank volume [l] | 16 | 16 | 16 | |||
| Air resistance [Cd] | 0.325 | 0.325 | 0.34 | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | multilink Integral Blade suspension | |||
| Tyre dimensions front | 225/65 R17 | 225/65 R17 | 235/60 R18 | |||
| Tyre dimensions rear | 225/65 R17 | 225/65 R17 | 235/60 R18 | |||
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | |||
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 | |||
| Brake dimensions front | 325 | 325 | 349 | |||
| Brake dimensions rear | 300 | 300 | 300 | |||
| Steering | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | |||
| Number of steering wheel turns | 2.31 | 2.31 | 2.31 | |||
| Turning diameter track/circumference [m] | 11,46/- | 11,46/- | 11,46/- | |||
| Overall length [mm] | 4395 | 4395 | 4395 | |||
| Overall width without/including mirrors [mm] | 1984/2088 | 1984/2088 | 1984/2088 | |||
| Overall height [mm] | 1649 | 1649 | 1649 | |||
| Wheelbase [mm] | 2681 | 2681 | 2681 | |||
| Front wheel track [mm] | 1625 | 1625 | 1625 | |||
| Rear wheel track [mm] | 1624 | 1624 | 1624 | |||
| Forward overhang [mm] | 882 | 882 | 882 | |||
| Rear overhang [mm] | 832 | 832 | 832 | |||
| Clearance [mm] | 204 | 204 | 204 | |||
| Wading depth [mm] | 500 | 500 | 500 | |||
| Approach angle front [°] | 22.8 | 22.8 | 22.8 | |||
| Approach angle rear [°] | 21.1 | 21.1 | 21.1 | |||
| Transition angle [°] | 29.4 | 29.4 | 29.4 | |||
| Climbing rate [°] | 45 | 45 | 45 | |||
| Maximum side tilt [°] | 35 | 35 | 35 | |||
| Headroom front [mm] | 996 | 996 | 996 | |||
| Headroom rear [mm] | 970 | 970 | 970 | |||
| Front elbow/shoulder width [mm] | -/1425 | -/1425 | -/1425 | |||
| Rear elbow/shoulder width [mm] | -/1417 | -/1417 | -/1417 | |||
| Legroom front knees/total [mm] | -/1018 | -/1018 | -/1018 | |||
| Legroom rear knees/total [mm] | -/892 | -/892 | -/892 |
