Hyundai Santa Fe

Santa Fe TM 2020

Date of manufacture

2020 – to this day (Medium SUV)

Platform

Hyundai-Kia N3

Manufacturing locations

Ulsan, South Korea
Montgomery, Alabama, USA

Designer

-

Tags

Compact SUV
Korean cars
The Hyundai Santa Fe is a mid-size SUV that has been produced since 2020. The car can be purchased in three versions: regular, hybrid or plug-in hybrid. The engine range includes petrol and hybrid engines with the highest power of 195 kW for the 1.6 T-GDI PHEV 265 model and the fastest model 2.2 CRDi e-VGT 202 reaching a top speed of 205 km/h. The best acceleration 0-100 km/h in 8.8 seconds is for the 1.6 T-GDI PHEV 265 model and the most economical variant is the same model with a combined fuel consumption of 1.6 l/100 km and CO2 emissions of 36.9 g/km. The boot offers a capacity of 634–831 l and the Hyundai Santa Fe passed the EURONCAP safety tests in 2018 with a rating of 5 out of 5. The car is built on the Hyundai-Kia N3 platform and is produced in collaboration with South Korea and the USA.

Car body style

Medium SUV

after upgrade (facelift)
Date of manufacture
2020 – to this day
Internal designation
TM

Euro NCAP

Test year 2018
pre-facelift version (2018)
Rating
star iconstar iconstar iconstar iconstar icon
Adults
94 %
Adults
Children
88 %
Children
Pedestrians
67 %
Pedestrians
Assist systems
76 %
Assist systems

Technical data

Medium SUV

1.6 T-GDI HEV 230 1.6 T-GDI HEV 230 1.6 T-GDI PHEV 265 2.2 CRDi e-VGT 202 2.2 CRDi e-VGT 202
Date of sale-----
Engine typePetrol supercharged + ElectricPetrol supercharged + ElectricPetrol supercharged + ElectricDiesel superchargedDiesel supercharged
Number of cylinders/valves4/164/164/164/164/16
Engine displacement [cm³]15981598159821512151
Maximum output / speed [kW/min-1]
132,2/5500 combustion
44.2 el.
169/5500 total
132,2/5500 combustion
44.2 el.
169/5500 total
132,2/5500 combustion
66.9 el.
195/5500 total
148/3800
148/3800
Maximum torque [Nm/min-1]
265/1500-4500 combustion
265 el.
350/1500-4500 total
265/1500-4500 combustion
265 el.
350/1500-4500 total
265/1500-4500 combustion
304 el.
350/1500-4500 total
440/17502750
440/17502750
Drive axleFront4x44x4Front4x4
Gearbox6 gear automatic6 gear automatic6 gear automatic8 gear automatic8 gear automatic
Top speed [km/h]187187187205205
Acceleration 0–100 km/h [s]8,99,18,89,09,2
City [l]5,3-5,56,2-6,2-6,1-6,56,7-6,8
Out of town [l]5,2-5,55,6-6,0-5,0-5,15,4-5,4
Combined [l]5,3-5,55,8-6,11,5 [16.3 kWh]5,4-5,65,9-5,9
CO2 emissions [g/km]120-126132-13934143-148155-155
Combined speed [l]6,4-6,96,9-7,61,6 [18.1 kWh]6,1-6,36,7-6,9
CO2 emissions [g/km]146-157157-17236,9161-166176-181
Emission standardEuro 6dEuro 6dEuro 6dEuro 6dEuro 6d
System voltage [V]270270---
Battery type and capacityLithium polymer, 1.49 kWhLithium polymer, 1.49 kWhLithium polymer, 13.8 kWh--
Range with fully charged battery [km]--58--
Charging time-----
Standby weight [kg]1809-1932 [1855-1981 seven seats]1871-2006 [1917-2055 seven seats]2040-2144 [2080-2187 seven seats]1800-1946 [1845-1994 seven seats]1865-2011 [1910-2059 seven seats]
Overall weight [kg]2510 [2580 seven seats]2530 [2630 seven seats]2690 [2690 seven seats]2510 [2550 seven seats]2510 [2600 seven seats]
Maximum trailer weight unbraked/braked [kg]750/1650750/1650750/1350750/2500750/2500
Boot volume [l]634-831 [130 seven seats]634-831 [130 seven seats]634-831 [130 seven seats]634-831 [130 seven seats]634-831 [130 seven seats]
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/1704 [1649 seven seats]-/1704 [1649 seven seats]-/1704 [1649 seven seats]-/1704 [1649 seven seats]-/1704 [1649 seven seats]
Boot volume, third row of seats [l]-----
Number of doors55555
Number of seats5 [7 subject to a surcharge]5 [7 subject to a surcharge]5 [7 subject to a surcharge]5 [7 subject to a surcharge]5 [7 subject to a surcharge]
Fuel tank volume [l]6767476767
AdBlue tank volume [l]---1818
Overall length [mm]47854785478547854785
Overall width without/including mirrors [mm]1900/21451900/21451900/21451900/21451900/2145
Overall height [mm]16851685168516851685
Wheelbase [mm]27652765276527652765
Headroom front [mm]10161016101610161016
Headroom rear [mm]995995995995995
Front elbow/shoulder width [mm]-/1500-/1500-/1500-/1500-/1500
Rear elbow/shoulder width [mm]-/1480 [--/1480 [--/1480 [--/1480 [--/1480 [-
Third row of seats, headroom [mm]917917917917917
Third row elbow/shoulder width [mm]-/1344-/1344-/1344-/1344-/1344

Gallery

Hyundai Santa Fe TM Facelift 2021 interiorHyundai Santa Fe TM Facelift 2021 front seatsHyundai Santa Fe TM Facelift 2021 interior
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
