Hyundai Santa Fe

Date of manufacture

4/2006 – 2010 (SUV)

Platform

Manufacturing locations

Ulsan, South Korea

Chennai, India

Montgomery, Alabama, USA

Designer

Car body style

SUV

Date of manufacture

4/2006 – 2010

Internal designation

Engine size

Petrol

2.7i DOHC CVVT

2.7i DOHC CVVT 7 seats

Diesel

Euro NCAP

Technical data

SUV

	2.7i DOHC CVVT	2.7i DOHC CVVT 7 seats	2.2 CRDi VGT	2.2 CRDi VGT	2.2 CRDi VGT 7 seats	2.2 CRDi VGT
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	6/24	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2656	2656	2188	2188	2188	2188
Maximum output / speed [kW/min-1]	139,3/6000	139,3/6000	114/4000	114/4000	114/4000	114/4000
Maximum torque [Nm/min-1]	248/4000	248/4000	343/1800-2500	343/1800-2500	343/1800-2500	343/1800-2500
Bore and stroke [mm x mm]	86,7 x 75,0	86,7 x 75,0	87,0 x 92,0	87,0 x 92,0	87,0 x 92,0	87,0 x 92,0
Compression ratio	10,4:1	10,4:1	17,3:1	17,3:1	17,3:1	17,3:1
Oil volume [l]	4.5	4.5	5.4	5.4	5.4	5.4
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves CVVT	variable timing of intake valves CVVT	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4	Front	4x4	4x4	4x4
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	5 gear manual	5 gear automatic
Drive specifications	all-wheel drive 4WD	all-wheel drive 4WD	-	all-wheel drive 4WD	all-wheel drive 4WD	all-wheel drive 4WD automatic gearbox

Top speed [km/h]	190	190	180	179	179	179
Acceleration 0–100 km/h [s]	10.3	10.3	11.3	11.6	11.6	12.6
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	14.2	14.2	9.5	9.4	9.4	10.4
Out of town [l]	8.3	8.3	5.9	6.0	6.0	6.7
Combined [l]	10.4	10.4	7.1	7.3	7.3	8.1
CO2 emissions [g/km]	248	248	187	191	191	212

Emission standard	EU4	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	80	80	76	76	76	78
Driving noise [dB]	71	70	72	72	72	71

Standby weight [kg]	1825-1918	1865	1818-1911	1898-1991	1938-2039	1928-2021
Overall weight [kg]	2325	2450	2520	2520	2550	2550
Maximum trailer weight unbraked/braked [kg]	750/	750/	750/2200	750/2200	750/2200	750/2000
Maximum front/rear axle load [kg]	1350/1450	1350/1450	1350/1450	1350/1450	1350/1450	1350/1450
Maximum vertical load on the tow bar [kg]	80	80	88	88	88	80
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	774	774	774	774	774	774
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1582	-/1582	-/1582	-/1582	-/1582	-/1582
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	7	5	5	7	5
Fuel tank volume [l]	75	75	75	75	75	75
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.38	0.38	0.38	0.38	0.38	0.38
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	235/60 R18	235/60 R18	235/65 R17	235/65 R17	235/65 R17	235/60 R18
Tyre dimensions rear	235/60 R18	235/60 R18	235/65 R17	235/65 R17	235/65 R17	235/60 R18
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	321	321	321	321	321	321
Brake dimensions rear	302	302	302	302	302	302
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.9/-	10.9/-	10.9/-	10.9/-	10.9/-	10.9/-

Overall length [mm]	4675	4675	4675	4675	4675	4675
Overall width without/including mirrors [mm]	1890/-	1890/-	1890/-	1890/-	1890/-	1890/-
Overall height [mm]	1725	1725	1725	1725	1725	1725
Wheelbase [mm]	2700	2700	2700	2700	2700	2700
Front wheel track [mm]	1615	1615	1615	1615	1615	1615
Rear wheel track [mm]	1620	1620	1620	1620	1620	1620
Forward overhang [mm]	915	915	915	915	915	915
Rear overhang [mm]	1036	1036	1036	1036	1036	1036
Clearance [mm]	203	203	203	203	203	203
Wading depth [mm]	500	500	500	500	500	500
Approach angle front [°]	25.6	25.6	25.6	25.6	25.6	25.6
Approach angle rear [°]	22.9	22.9	22.9	22.9	22.9	22.9
Transition angle [°]	18.4	18.4	18.4	18.4	18.4	18.4
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.2 CRDi VGT 7 seats
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	2188
Maximum output / speed [kW/min-1]	114/4000
Maximum torque [Nm/min-1]	343/1800-2500
Bore and stroke [mm x mm]	87,0 x 92,0
Compression ratio	17,3:1
Oil volume [l]	5.4
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4
Gearbox	5 gear automatic
Drive specifications	all-wheel drive 4WD automatic gearbox

Top speed [km/h]	179
Acceleration 0–100 km/h [s]	12.6
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	10.4
Out of town [l]	6.7
Combined [l]	8.1
CO2 emissions [g/km]	212

Emission standard	EU4
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	78
Driving noise [dB]	71

Standby weight [kg]	1968-2069
Overall weight [kg]	2550
Maximum trailer weight unbraked/braked [kg]	750/2000
Maximum front/rear axle load [kg]	1350/1450
Maximum vertical load on the tow bar [kg]	80
Maximum load on roof/carrier [kg]	100/-

Boot volume [l]	774
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1582
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	7
Fuel tank volume [l]	75
AdBlue tank volume [l]	-
Air resistance [Cd]	0.38
Front suspension	MacPherson, torsion stabiliser
Rear suspension	twist beam axle with trailing arms
Tyre dimensions front	235/60 R18
Tyre dimensions rear	235/60 R18
Wheel size front	-
Wheel size rear	-
Brake dimensions front	321
Brake dimensions rear	302
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.9/-

Overall length [mm]	4675
Overall width without/including mirrors [mm]	1890/-
Overall height [mm]	1725
Wheelbase [mm]	2700
Front wheel track [mm]	1615
Rear wheel track [mm]	1620
Forward overhang [mm]	915
Rear overhang [mm]	1036
Clearance [mm]	203
Wading depth [mm]	500
Approach angle front [°]	25.6
Approach angle rear [°]	22.9
Transition angle [°]	18.4
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Hyundai Santa FE 2007 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
