Hyundai Kona
Date of manufacture
2017 – 2020 (Small SUV)
Platform
B-SUV platform
Manufacturing locations
Nošovice, Czechia
Beijing, People's Republic of China
Ulsan, South Korea
Chennai, India
Designer
Luc Donckerwolke
Tags
Small SUV
Korean cars
The Hyundai Kona is a small SUV that has been manufactured since 2017. The vehicle is built on the B-SUV platform and offers petrol, diesel, hybrid and electric powertrains. The most powerful of them - the Kona Elektro 150 kW - has a power output of 150 kW. The highest speed of 210 km/h is achieved by the 1.6 T-GDI 177 model and the best acceleration from 0-100 km/h in 7.7 seconds is also this model. The lowest fuel consumption of 3.9 l/100 km is provided by the Kona Hybrid hybrid variant with CO2 emissions of 90 g/km. The luggage compartment of the car is 361 l and in 2017 the Hyundai Kona earned a 5 out of 5 EURONCAP safety rating.
Car body style
Small SUV
Date of manufacture
2017 – 2020Internal designation
-Engine size
PetrolPetrol + ElectricElectric
Technical data
Small SUV
| 1,0 T-GDI 120 | 1.6 T-GDI 177 | 1.6 T-GDI 177 | Kona Hybrid | Kona Elektro 100 kW | Kona Elektro 150 kW | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | from 2020 to | from 2018 to | from 2018 to |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Electric | Electric |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | - | - |
| Engine displacement [cm³] | 998 | 1591 | 1591 | 1580 | - | - |
| Maximum output / speed [kW/min-1] | 88.3/6000 | 130/5500 | 130/5500 | 77.2/5700 combustion 32 el. 104 total | 100 | 150 |
| Maximum torque [Nm/min-1] | 172/1500-4000 | 265/1500-4500 | 265/1500-4500 | 147/4000 combustion 170 el. 265 total | 395 | 395 |
| Bore and stroke [mm x mm] | 71.0 x 84.0 | 77.0 x 85.44 | 77.0 x 85.44 | 72.0 x 97.0 | - | - |
| Compression ratio | 10.0:1 | 10.0:1 | 10.0:1 | 13.0:1 | - | - |
| Oil volume [l] | 3.6 | 4.5 | 4.5 | 4.1 | - | - |
| Coolant volume [l] | 6.8 | 7.1 | 7.1 | 2.7 | - | - |
| Technical specifications |
|
|
|
| - | - |
| Drive axle | Front | Front | 4x4 | Front | Front | Front |
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 1 gear automatic | 1 gear automatic |
| Drive specifications | - |
|
|
|
|
|
| Top speed [km/h] | 181 | 210 | 205 | 160 | 155 | 167 |
| Acceleration 0–100 km/h [s] | 12,0 | 7,7 | 7,9 | 11.2 | 9.7 | 7.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | 7.3 | 4.8 |
| City [l] | 6,5-6,7 | 6,8-6,9 | 8,2-8,4 | 4.0-3.6 | - | - |
| Out of town [l] | 4,9-5,0 | 5,6-5,9 | 6,0-6,2 | 4.5-3.9 | - | - |
| Combined [l] | 5,5-5,7 | 6,1-6,3 | 6,8-7,1 | 4.3-3.9 | - | - |
| CO2 emissions [g/km] | 125-129 | 139-144 | 155-160 | 99-90 | - | - |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | - | - | - | 15.0 kWh | 14.7 kWh |
| CO2 emissions [g/km] | - | - | - | - | - | - |
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | Euro 6d-TEMP | - | - |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | 68 | 68 |
| System voltage [V] | - | - | - | 240 | 327 | 356 |
| Battery type and capacity | - | - | - | Lithium polymer, 1.56 kWh | Lithium polymer, 39.2 kWh | Lithium polymer, 64 kWh |
| Range with fully charged battery [km] | - | - | - | - | 289 | 484 |
| Charging time | - | - | - | - |
|
|
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1298-1420 | 1387-1496 | 1467-1574 | 1451-1528 | 1610-1668 | 1760-1818 |
| Overall weight [kg] | 1775 | 1835 | 1910 | 1880 | 2020 | 2170 |
| Maximum trailer weight unbraked/braked [kg] | 600/1200 | 600/1250 | 600/1250 | 600/1300 | - | - |
| Maximum front/rear axle load [kg] | 1030/1055 | 1030/1055 | 1030/1055 | 1055/960 | 1100/1120 | 1100/1120 |
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | 80 | - | 100 |
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | 80/- | 80/- |
| Boot volume [l] | 361 | 361 | 361 | 361 | 332 | 332 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1143 | -/1143 | -/1143 | -/1143 | -/1114 | -/1114 |
| Boot length [mm] | 695 | 695 | 695 | 695 | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1016/- | 1016/- | 1016/- | 1016/- | - | - |
| Boot height to headliner/ceiling [mm] | -/531 | -/531 | -/531 | -/531 | - | - |
| Loading edge height [mm] | 695 | 695 | 695 | 695 | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 38 | - | - |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | 0.33 | 0.29 | 0.29 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 205/16 R16 | 205/16 R16 | 205/16 R16 | 205/16 R16 | 215/55 R17 | 215/55 R17 |
| Tyre dimensions rear | 205/16 R16 | 205/16 R16 | 205/16 R16 | 205/16 R16 | 215/55 R17 | 215/55 R17 |
| Wheel size front | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 7.0J x 17 | 7.0J x 17 |
| Wheel size rear | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 7.0J x 17 | 7.0J x 17 |
| Brake dimensions front | 280 | 320 | 320 | 305 | 305 | 305 |
| Brake dimensions rear | 262 | 284 | 284 | 284 | 300 | 300 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 2.5 | 2.5 | 2.5 | 2.5 | - | - |
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- |
| Overall length [mm] | 4165 | 4165 | 4165 | 4165 | 4180 | 4180 |
| Overall width without/including mirrors [mm] | 1800/2040 | 1800/2040 | 1800/2040 | 1800/2040 | 1800/2040 | 1800/2040 |
| Overall height [mm] | 1550 | 1550 | 1550 | 1550 | 1570 | 1570 |
| Wheelbase [mm] | 2600 | 2600 | 2600 | 2600 | 2600 | 2600 |
| Front wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1564 | 1564 |
| Rear wheel track [mm] | 1584 | 1584 | 1584 | 1584 | 1575 | 1575 |
| Forward overhang [mm] | 845 | 845 | 845 | 845 | 860 | 860 |
| Rear overhang [mm] | 720 | 720 | 720 | 720 | 720 | 720 |
| Clearance [mm] | 171 | 171 | 177.5 | 171 | 158 | 158 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | - | - |
| Approach angle front [°] | 15.7 | 15.7 | 15.7 | 17,0 | - | - |
| Approach angle rear [°] | 29.0 | 29.0 | 29.6 | 29.0 | - | - |
| Transition angle [°] | 16.0 | 16.0 | 16.7 | 16.0 | - | - |
| Climbing rate [°] | 48 | 48 | 68.1 | 33 | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1005 | 1005 | 1005 | 1005 | 1006 | 1006 |
| Headroom rear [mm] | 961 | 961 | 961 | 961 | 948 | 948 |
| Front elbow/shoulder width [mm] | -/1410 | -/1410 | -/1410 | -/1410 | -/1410 | -/1410 |
| Rear elbow/shoulder width [mm] | -/1385 | -/1385 | -/1385 | -/1385 | -/1380 | -/1380 |
| Legroom front knees/total [mm] | -/1054 | -/1054 | -/1054 | -/1054 | -/1054 | -/1054 |
| Legroom rear knees/total [mm] | -/880 | -/880 | -/880 | -/880 | -/850 | -/850 |
| 1.6 CRDi 116 | 1.6 CRDi 136 | 1.6 CRDi 136 | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1598 | 1598 | 1598 | |||
| Maximum output / speed [kW/min-1] | 85/4000 | 100/4000 | 100/4000 | |||
| Maximum torque [Nm/min-1] | 280/1500-2750 | 320/1750-2250 | 320/1750-2250 | |||
| Bore and stroke [mm x mm] | 77.0 x 85.8 | 77.0 x 85.8 | 77.0 x 85.8 | |||
| Compression ratio | 15.9:1 | 15.9:1 | 15.9:1 | |||
| Oil volume [l] | 4.5 | 4.5 | 4.5 | |||
| Coolant volume [l] | 7.8 | 7.8 | 7.8 | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | 4x4 | |||
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | |||
| Drive specifications | - |
|
| |||
| Top speed [km/h] | 183 | 191 | 186 | |||
| Acceleration 0–100 km/h [s] | 10,7 | 10,2 | 11,2 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 4,8-5,0 | 4,5-4,8 | 5,0-5,3 | |||
| Out of town [l] | 3,9-3,9 | 4,1-4,3 | 4,5-4,8 | |||
| Combined [l] | 4,1-4,3 | 4,2-4,5 | 4,6-4,9 | |||
| CO2 emissions [g/km] | 109-113 | 112-115 | 119-127 | |||
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1393-1510 | 1418-1535 | 1496-1612 | |||
| Overall weight [kg] | 1850 | 1880 | 1950 | |||
| Maximum trailer weight unbraked/braked [kg] | 600/1200 | 600/1250 | 600/1250 | |||
| Maximum front/rear axle load [kg] | 1030/1055 | 1030/1055 | 1030/1055 | |||
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | |||
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | |||
| Boot volume [l] | 361 | 361 | 361 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1143 | -/1143 | -/1143 | |||
| Boot length [mm] | 695 | 695 | 695 | |||
| Boot length with rear seats folded [mm] | - | - | - | |||
| Boot width between wheels/max [mm] | 1016/- | 1016/- | 1016/- | |||
| Boot height to headliner/ceiling [mm] | -/531 | -/531 | -/531 | |||
| Loading edge height [mm] | 695 | 695 | 695 | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 50 | 50 | 50 | |||
| AdBlue tank volume [l] | 12 | 12 | 12 | |||
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | multilink | |||
| Tyre dimensions front | 205/16 R16 | 205/16 R16 | 205/16 R16 | |||
| Tyre dimensions rear | 205/16 R16 | 205/16 R16 | 205/16 R16 | |||
| Wheel size front | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | |||
| Wheel size rear | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | |||
| Brake dimensions front | 320 | 320 | 320 | |||
| Brake dimensions rear | 284 | 284 | 284 | |||
| Steering | - | - | - | |||
| Number of steering wheel turns | 2.5 | 2.5 | 2.5 | |||
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | |||
| Overall length [mm] | 4165 | 4165 | 4165 | |||
| Overall width without/including mirrors [mm] | 1800/2040 | 1800/2040 | 1800/2040 | |||
| Overall height [mm] | 1550 | 1550 | 1550 | |||
| Wheelbase [mm] | 2600 | 2600 | 2600 | |||
| Front wheel track [mm] | 1575 | 1575 | 1575 | |||
| Rear wheel track [mm] | 1584 | 1584 | 1584 | |||
| Forward overhang [mm] | 845 | 845 | 845 | |||
| Rear overhang [mm] | 720 | 720 | 720 | |||
| Clearance [mm] | 171 | 171 | 177.5 | |||
| Wading depth [mm] | 500 | 500 | 500 | |||
| Approach angle front [°] | 15.7 | 15.7 | 15.7 | |||
| Approach angle rear [°] | 29.0 | 29.0 | 29.6 | |||
| Transition angle [°] | 16.0 | 16.0 | 16.7 | |||
| Climbing rate [°] | 48 | 48 | 68.1 | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 1005 | 1005 | 1005 | |||
| Headroom rear [mm] | 961 | 961 | 961 | |||
| Front elbow/shoulder width [mm] | -/1410 | -/1410 | -/1410 | |||
| Rear elbow/shoulder width [mm] | -/1385 | -/1385 | -/1385 | |||
| Legroom front knees/total [mm] | -/1054 | -/1054 | -/1054 | |||
| Legroom rear knees/total [mm] | -/880 | -/880 | -/880 |
