Hyundai IONIQ 5
Date of manufacture
3/2021 – to this day (Medium SUV)
Platform
E-GMP
Manufacturing locations
Ulsan, South Korea
Designer
-
Tags
Compact SUV
Korean cars
Electric car
The Hyundai IONIQ 5 is a new mid-size SUV released in 2021 from South Korea on the E-GMP platform. It offers only electric motors with a maximum power of 225 kW and a top speed of 185 km/h. The best acceleration 0-100 km/h in 5.2 seconds is for the 72.6 kWh 225 kW AWD model and the lowest combined consumption of 16.7 kWh/100 km is for the 58 kWh 125 kW model. The trunk offers a capacity of 527 l, providing enough space for your needs. It performs well in terms of safety, receiving a 5 out of 5 rating from EURONCAP in 2021.
Car body style
Medium SUV
Date of manufacture
3/2021 – to this dayInternal designation
NE
Technical data
Medium SUV
| 58 kWh 125 kW | 58 kWh 173 kW AWD | 72.6 kWh 160 kW | 72.6 kWh 225 kW AWD | |||
|---|---|---|---|---|---|---|
| Date of sale | electric synchronous motor with permanent magnet | two electric synchronous motors with permanent magnet | electric synchronous motor with permanent magnet | two electric synchronous motors with permanent magnet | ||
| Engine type | Electric | Electric | Electric | Electric | ||
| Number of cylinders/valves | - | - | - | - | ||
| Engine displacement [cm³] | - | - | - | - | ||
| Maximum output / speed [kW/min-1] | 125 | 173 | 160 | 225 | ||
| Maximum torque [Nm/min-1] | 350 | 605 | 350 | 605 | ||
| Bore and stroke [mm x mm] | - | - | - | - | ||
| Compression ratio | - | - | - | - | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications | - | - | - | - | ||
| Drive axle | Rear | 4x4 | Rear | 4x4 | ||
| Gearbox | 1 gear manual | 1 gear manual | 1 gear manual | 1 gear manual | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 185 | 185 | 185 | 185 | ||
| Acceleration 0–100 km/h [s] | 8.5 | 6.1 | 7.4 | 5.2 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | - | - | - | - | ||
| Out of town [l] | - | - | - | - | ||
| Combined [l] | - | - | - | - | ||
| CO2 emissions [g/km] | - | - | - | - | ||
| Low speed [l] | - | - | - | - | ||
| Medium speed [l] | - | - | - | - | ||
| High speed [l] | - | - | - | - | ||
| Extra high speed [l] | - | - | - | - | ||
| Combined speed [l] | 16.7 kWh | 18.1 kWh | 17.9-16.8 kWh | 19.0-17.7 kWh | ||
| CO2 emissions [g/km] | - | - | - | - | ||
| Emission standard | - | - | - | - | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| System voltage [V] | 400 or 800 | 400 or 800 | 400 or 800 | 400 or 800 | ||
| Battery type and capacity | Lithium polymer, 58 kWh | Lithium polymer, 58 kWh | Lithium polymer, 72.6 kWh | Lithium polymer, 72.6 kWh | ||
| Range with fully charged battery [km] | 384 | 360 | 451-481 | 430-460 | ||
| Charging time |
|
|
|
| ||
| Number of modules/cells | - | - | - | - | ||
| Battery weight [kg] | - | - | - | - | ||
| Charger | - | - | - | - | ||
| Standby weight [kg] | 1905-1985 | 2015-2095 | 1985-2065 | 2095-2175 | ||
| Overall weight [kg] | 2370 | 2480 | 2430 | 2540 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/750 | 750/750 | 750/1600 | 750/1600 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | ||
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | ||
| Boot volume [l] | 527 | 527 | 527 | 527 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1587 | -/1587 | -/1587 | -/1587 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | - | - | - | - | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 235/55 R19 | 235/55 R19 | 235/55 R19 | 235/55 R19 | ||
| Tyre dimensions rear | 235/55 R19 | 235/55 R19 | 235/55 R19 | 235/55 R19 | ||
| Wheel size front | 7.5J x 19 | 7.5J x 19 | 7.5J x 19 | 7.5J x 19 | ||
| Wheel size rear | 7.5J x 19 | 7.5J x 19 | 7.5J x 19 | 7.5J x 19 | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 11.98/- | 11.98/- | 11.98/- | 11.98/- | ||
| Overall length [mm] | 4635 | 4635 | 4635 | 4635 | ||
| Overall width without/including mirrors [mm] | 1890/- | 1890/- | 1890/- | 1890/- | ||
| Overall height [mm] | 1605 | 1605 | 1605 | 1605 | ||
| Wheelbase [mm] | 3000 | 3000 | 3000 | 3000 | ||
| Front wheel track [mm] | 1638 | 1638 | 1638 | 1638 | ||
| Rear wheel track [mm] | 1647 | 1647 | 1647 | 1647 | ||
| Forward overhang [mm] | - | - | - | - | ||
| Rear overhang [mm] | - | - | - | - | ||
| Clearance [mm] | 160 | 160 | 160 | 160 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | - | - | - | - | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | - | - | - | - | ||
| Rear elbow/shoulder width [mm] | - | - | - | - | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - | ||
| Rating |   | - | - | - | ||
| Clean Air Index | 10.0/10 | - | - | - | ||
| Energy Efficiency Index | 9.1/10 | - | - | - | ||
| GHG index | 9.3/10 | - | - | - |
