Hyundai i10

Date of manufacture

1/2020 – to this day (Five-door hatchback)

Platform

Manufacturing locations

İzmit, Turkey

Designer

Car body style

Five-door hatchback

Date of manufacture

1/2020 – to this day

Internal designation

Engine size

1.0i

1.2i

1.0 T-GDI N-Line

Euro NCAP

Technical data

Five-door hatchback

	1.0i	1.0i	1.2i	1.2i	1.0 T-GDI N-Line
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Ignition supercharged
Number of cylinders/valves	3/12	3/12	4/16	4/16	3/12
Engine displacement [cm³]	998	998	1197	1197	998
Maximum output / speed [kW/min-1]	49,3/5500	49,3/5500	61,7/6000	61,7/6000	74/4500
Maximum torque [Nm/min-1]	96/3750	96/3750	118/4200	118/4200	172/1500
Bore and stroke [mm x mm]	71,0 x 84,0	71,0 x 84,0	71,0 x 75,6	71,0 x 75,6	71,0 x 84,0
Compression ratio	11,0:1	11,0:1	11,0:1	11,0:1	10.5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves D-CVVT start&stop system ISG	variable timing of intake and exhaust valves D-CVVT start&stop system ISG	variable timing of intake and exhaust valves D-CVVT start&stop system ISG	variable timing of intake and exhaust valves D-CVVT start&stop system ISG	direct injection GDI turbo-supercharged variable timing of intake and exhaust valves D-CVVT Gasoline Particulate Filter start&stop system ISG

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear robotic manual	5 gear manual	5 gear robotic manual	5 gear manual
Drive specifications	-	five-speed robotic gearbox	-	five-speed robotic gearbox	-

Top speed [km/h]	156	156	171	171	185
Acceleration 0–100 km/h [s]	14,6	17,3	12,6	15,8	10.5
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	5,3-5,2	5,3-5,0	6,0-5,8	5,5-5,3	5.8
Out of town [l]	4,1-3,7	4,5-4,1	4,3-3,9	4,5-4,0	4,2
Combined [l]	4,5-4,2	4,8-4,4	4,9-4,6	4,8-4,5	4,8
CO2 emissions [g/km]	104-97	109-101	113-105	103-92	105

Low speed [l]	7,2-6,9	8,3-8,0	8,0-7,7	9,5-9,2	6.8
Medium speed [l]	5,4-5,1	5,9-5,7	6,0-5,8	6,6-6,5	5.2
High speed [l]	5,1-4,9	5,6-5,4	5,4-5,2	6,0-5,8	4.6
Extra high speed [l]	6,3-6,1	7,0-6,8	6,5-6,3	7,2-6,9	5.8
Combined speed [l]	5,9-5,4	6,5-6,3	6,3-6,0	7,0-6,8	5.4
CO2 emissions [g/km]	133-138	148-143	142-137	159-154	123

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	996-1068	999-1070	1007-1082	1010-1081	1099-1120
Overall weight [kg]	1410	1410	1430	1430	1470
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	60/-	60/-	60/-	60/-	60/-

Boot volume [l]	252	252	252	252	252
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1050	-/1050	-/1050	-/1050	-/1050
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	4/5	4/5	4/5	4/5	4/5
Fuel tank volume [l]	36	36	36	36	36
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	twist beam axle with trailing arms and torsion bar	twist beam axle with trailing arms and torsion bar	twist beam axle with trailing arms and torsion bar	twist beam axle with trailing arms and torsion bar	twist beam axle with trailing arms and torsion bar
Tyre dimensions front	175/65 R14	185/55 R15	185/55 R15	185/55 R15	175/65 R14
Tyre dimensions rear	175/65 R14	185/55 R15	185/55 R15	185/55 R15	175/65 R14
Wheel size front	5,5J x 14	6,0J x 15	6,0J x 15	6,0J x 15	5,5J x 14
Wheel size rear	5,5J x 14	6,0J x 15	6,0J x 15	6,0J x 15	5,5J x 14
Brake dimensions front	252	252	252	252	252
Brake dimensions rear	234	234	234	234	234
Steering	-	-	-	-	-
Number of steering wheel turns	2.64	2.64	2.64	2.64	2.64
Turning diameter track/circumference [m]	10,0/-	10,0/-	10,0/-	10,0/-	10,0/-

Overall length [mm]	3670	3670	3670	3670	3675
Overall width without/including mirrors [mm]	1680/-	1680/-	1680/-	1680/-	1680/-
Overall height [mm]	1480	1480	1480	1480	1483
Wheelbase [mm]	2425	2425	2425	2425	2425
Front wheel track [mm]	1467	1467	1467	1467	1467
Rear wheel track [mm]	1478	1478	1478	1478	1478
Forward overhang [mm]	705	705	705	705	710
Rear overhang [mm]	540	540	540	540	540
Clearance [mm]	149	149	149	149	152
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	996	996	996	996	996
Headroom rear [mm]	956	956	956	956	956
Front elbow/shoulder width [mm]	1260/1326	1260/1326	1260/1326	1260/1326	1260/1326
Rear elbow/shoulder width [mm]	1230/1328	1230/1328	1230/1328	1230/1328	1230/1328
Legroom front knees/total [mm]	-/1070	-/1070	-/1070	-/1070	-/1070
Legroom rear knees/total [mm]	-/865	-/865	-/865	-/865	-/865

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
