Hyundai i10

Date of manufacture

9/2010 – 2013 (Five-door hatchback)

Platform

Manufacturing locations

Chennai, India

Designer

Thomas Bürkle

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

9/2010 – 2013

Internal designation

Engine size

1.1 SOHC

1.25 DOHC D-CVVT

1,25 DOHC D-CVVT

Euro NCAP

Pre-2009 Rating

pre-facelift version (2008)

Adults

Children

Pedestrians

Technical data

Five-door hatchback

	1.1 SOHC	1.1 SOHC	1.25 DOHC D-CVVT	1,25 DOHC D-CVVT
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/12	4/12	4/16	4/16
Engine displacement [cm³]	1086	1086	1248	1248
Maximum output / speed [kW/min-1]	50,8/5500	50,8/5500	62,5/6000	62,5/6000
Maximum torque [Nm/min-1]	99/4500	99/4500	120,6/4000	120,6/4000
Bore and stroke [mm x mm]	67,0 x 77,0	67,0 x 77,0	71,0 x 78,8	-
Compression ratio	10,1:1	10,1:1	10,5:1	10,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	-	-	variable timing of intake and exhaust valves D‐CVVT	variable timing of intake and exhaust valves D‐CVVT

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	4 gear automatic	5 gear manual	4 gear automatic
Drive specifications	-	automatic gearbox	-	automatic gearbox

Top speed [km/h]	156	149	169	160
Acceleration 0–100 km/h [s]	15.0	17.1	12.2	13.8
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5.8	7.2	5.6	6.8
Out of town [l]	4.1	4.9	4.1	4.7
Combined [l]	4.7	5.8	4.6	5.5
CO2 emissions [g/km]	110	134	108	129

Emission standard	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	985	1010	985	1015
Overall weight [kg]	1405	1425	1410	1430
Maximum trailer weight unbraked/braked [kg]	400/700	400/700	450/800	450/700
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-

Boot volume [l]	225	225	225	225
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/925	-/925	-/925	-/925
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	35	35	35	35
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.32	0.32	0.32	0.32
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	rigid with torsion bar	rigid with torsion bar	rigid with torsion bar	rigid with torsion bar
Tyre dimensions front	155/70 R13	175/60 R14	155/70 R13	175/60 R14
Tyre dimensions rear	155/70 R13	175/60 R14	155/70 R13	175/60 R14
Wheel size front	-	5.0J x 14	-	-
Wheel size rear	-	5.0J x 14	-	-
Brake dimensions front	241	241	241	241
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	9.5/-	9.5/-	9.5/-	9.5/-

Overall length [mm]	3585	3585	3585	3585
Overall width without/including mirrors [mm]	1595/-	1595/-	1595/-	1595/-
Overall height [mm]	1540	1540	1540	1540
Wheelbase [mm]	2380	2380	2380	2380
Front wheel track [mm]	1400	1400	1400	1400
Rear wheel track [mm]	1385	1385	1385	1385
Forward overhang [mm]	670	670	670	670
Rear overhang [mm]	535	535	535	535
Clearance [mm]	149	149	149	149
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-
