Hyundai Bayon
Date of manufacture
2021 – to this day (Small SUV)
Platform
-
Manufacturing locations
İzmit, Turkey
Designer
-
Tags
Small SUV
Korean cars
The Hyundai Bayon is a new small SUV, manufactured since 2021. The car is made in Turkey and offers petrol engines. The highest power is achieved by the 1.0 T-GDI Mild Hybrid (88.3 kW), which is the fastest version with a maximum speed of 185 km/h. Fuel consumption for this model is very low - 5.5 l/100 km and CO2 emissions 124 g/km. The luggage compartment has a volume of 411 liters and the Hyundai Bayon has passed EURONCAP safety tests, resulting in a rating of 4 out of 5.
Car body style
Small SUV
Date of manufacture
2021 – to this dayInternal designation
-
Technical data
Small SUV
| 1.2i | 1.0 T-GDI | 1.0 T-GDI | 1.0 T-GDI Mild Hybrid | 1.0 T-GDI Mild Hybrid | 1.0 T-GDI Mild Hybrid | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 3/12 | 3/12 | 3/12 | 3/12 | 3/12 |
| Engine displacement [cm³] | 1197 | 998 | 998 | 998 | 998 | 998 |
| Maximum output / speed [kW/min-1] | 62/6000 | 73,6/4500 | 73,6/4500 | 74/4500-6000 | 74/4500-6000 | 88,3/6000 |
| Maximum torque [Nm/min-1] | 117,7/4200 | 171,6/1500-4000 | 171,6/1500-4000 | 172/1500-4000 | 172/1500-4000 | 200,1/2000-3500 |
| Bore and stroke [mm x mm] | 71.0 x 76.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 |
| Compression ratio | 11.0:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 165 | 183 | 180 | 183 | 180 | 185 |
| Acceleration 0–100 km/h [s] | 13,5 | 10,7 | 11,7 | 10.7 | 11.7 | 10,4 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | - | - | - | - | - |
| Out of town [l] | - | - | - | - | - | - |
| Combined [l] | - | - | - | - | - | - |
| CO2 emissions [g/km] | - | - | - | - | - | - |
| Low speed [l] | 6,3-6,8 | 7,1-7,4 | 6,9-7,3 | 6.8 | 6.8 | 6,7 |
| Medium speed [l] | 5,2-5,4 | 5,1-5,4 | 5,1-5,4 | 5.3 | 5.3 | 4,9-5,2 |
| High speed [l] | 4,8-5,0 | 4,5-4,8 | 4,5-4,8 | 4.7 | 4.7 | 4,5-4,8 |
| Extra high speed [l] | 6,0-6,1 | 5,6-6,0 | 5,7-5,9 | 5.9 | 5.9 | 5,4-5,9 |
| Combined speed [l] | 5,5-5,7 | 5,4-5,7 | 5,4-5,6 | 5.5 | 5.5 | 5,2-5,5 |
| CO2 emissions [g/km] | 124-129 | 122-129 | 122-128 | 125 | 124 | 118-125 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | 48 | 48 | 48 |
| Battery type and capacity | - | - | - | Lithium polymer, 0.46 kWh | Lithium polymer, 0.46 kWh | Lithium polymer, 0.46 kWh |
| Range with fully charged battery [km] | - | - | - | - | - | - |
| Charging time | - | - | - | - | - | - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1045-1155 | 1095-1205 | 1120-1230 | 1120-1230 | 1145-1255 | 1120-1230 |
| Overall weight [kg] | 1580 | 1630 | 1660 | 1770 | 1790 | 1660 |
| Maximum trailer weight unbraked/braked [kg] | 450/910 | 450/1110 | 450/1110 | 450/1110 | 450/1110 | 450/1110 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 70/- | 70/- | 70/- | 70/- | 70/- | 70/- |
| Boot volume [l] | 411 | 411 | 411 | 411 | 411 | 411 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1205 | -/1205 | -/1205 | -/1205 | -/1205 | -/1205 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 40 | 40 | 40 | 40 | 40 | 40 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar |
| Tyre dimensions front | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 |
| Tyre dimensions rear | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 |
| Brake dimensions rear | 262 x 10 | 262 x 10 | 262 x 10 | 262 x 10 | 262 x 10 | 262 x 10 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 2.4 | 2.4 | 2.4 | 2.4 | 2.4 | 2.4 |
| Turning diameter track/circumference [m] | 10.4/- | 10.4/- | 10.4/- | 10.4/- | 10.4/- | 10.4/- |
| Overall length [mm] | 4180 | 4180 | 4180 | 4180 | 4180 | 4180 |
| Overall width without/including mirrors [mm] | 1775/- | 1775/- | 1775/- | 1775/- | 1775/- | 1775/- |
| Overall height [mm] | 1490 | 1490 | 1490 | 1490 | 1490 | 1490 |
| Wheelbase [mm] | 2580 | 2580 | 2580 | 2580 | 2580 | 2580 |
| Front wheel track [mm] | 1551 | 1551 | 1551 | 1551 | 1551 | 1551 |
| Rear wheel track [mm] | 1557 | 1557 | 1557 | 1557 | 1557 | 1557 |
| Forward overhang [mm] | 820 | 820 | 820 | 820 | 820 | 820 |
| Rear overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Clearance [mm] | 165 | 165 | 165 | 165 | 165 | 165 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 977 | 977 | 977 | 977 | 977 | 977 |
| Front elbow/shoulder width [mm] | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 |
| Rear elbow/shoulder width [mm] | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 |
| Legroom front knees/total [mm] | -/1072 | -/1072 | -/1072 | -/1072 | -/1072 | -/1072 |
| Legroom rear knees/total [mm] | -/882 | -/882 | -/882 | -/882 | -/882 | -/882 |
| Rating | - | - | - | - |    | - |
| Clean Air Index | - | - | - | - | 3.4/10 | - |
| Energy Efficiency Index | - | - | - | - | 5.4/10 | - |
| GHG index | - | - | - | - | 4.1/10 | - |
| 1.0 T-GDI Mild Hybrid | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Ignition supercharged | |||||
| Number of cylinders/valves | 3/12 | |||||
| Engine displacement [cm³] | 998 | |||||
| Maximum output / speed [kW/min-1] | 88,3/6000 | |||||
| Maximum torque [Nm/min-1] | 200,1/2000-3500 | |||||
| Bore and stroke [mm x mm] | 71.0 x 84.0 | |||||
| Compression ratio | 10,5:1 | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Front | |||||
| Gearbox | 7 gear automatic | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 185 | |||||
| Acceleration 0–100 km/h [s] | 10,4 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | - | |||||
| Out of town [l] | - | |||||
| Combined [l] | - | |||||
| CO2 emissions [g/km] | - | |||||
| Low speed [l] | 6,5-6,8 | |||||
| Medium speed [l] | 5,1-5,3 | |||||
| High speed [l] | 4,5-4,8 | |||||
| Extra high speed [l] | 5,4-5,7 | |||||
| Combined speed [l] | 5,2-5,5 | |||||
| CO2 emissions [g/km] | 118-124 | |||||
| Emission standard | Euro 6d | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| System voltage [V] | 48 | |||||
| Battery type and capacity | Lithium polymer, 0.46 kWh | |||||
| Range with fully charged battery [km] | - | |||||
| Charging time | - | |||||
| Number of modules/cells | - | |||||
| Battery weight [kg] | - | |||||
| Charger | - | |||||
| Standby weight [kg] | 1145-1255 | |||||
| Overall weight [kg] | 1680 | |||||
| Maximum trailer weight unbraked/braked [kg] | 450/1110 | |||||
| Maximum front/rear axle load [kg] | - | |||||
| Maximum vertical load on the tow bar [kg] | 75 | |||||
| Maximum load on roof/carrier [kg] | 70/- | |||||
| Boot volume [l] | 411 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1205 | |||||
| Boot length [mm] | - | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | - | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 5 | |||||
| Number of seats | 5 | |||||
| Fuel tank volume [l] | 40 | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | - | |||||
| Front suspension | MacPherson, triangular arms, torsion stabiliser | |||||
| Rear suspension | twist beam axle with trailing arms and torsion bar | |||||
| Tyre dimensions front | 185/65 R15 | |||||
| Tyre dimensions rear | 185/65 R15 | |||||
| Wheel size front | - | |||||
| Wheel size rear | - | |||||
| Brake dimensions front | 280 x 22 | |||||
| Brake dimensions rear | 262 x 10 | |||||
| Steering | - | |||||
| Number of steering wheel turns | 2.4 | |||||
| Turning diameter track/circumference [m] | 10.4/- | |||||
| Overall length [mm] | 4180 | |||||
| Overall width without/including mirrors [mm] | 1775/- | |||||
| Overall height [mm] | 1490 | |||||
| Wheelbase [mm] | 2580 | |||||
| Front wheel track [mm] | 1551 | |||||
| Rear wheel track [mm] | 1557 | |||||
| Forward overhang [mm] | 820 | |||||
| Rear overhang [mm] | 780 | |||||
| Clearance [mm] | 165 | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | 993 | |||||
| Headroom rear [mm] | 977 | |||||
| Front elbow/shoulder width [mm] | 1352/1395 | |||||
| Rear elbow/shoulder width [mm] | 1316/1390 | |||||
| Legroom front knees/total [mm] | -/1072 | |||||
| Legroom rear knees/total [mm] | -/882 |
