Honda NSX

Date of manufacture

5/2016 – to this day (Coupé)

Platform

Manufacturing locations

Marysville, Michigan, USA

Designer

Michelle Christensen

Jun Goto

Toshinobu Minami

Car body style

Coupé

Date of manufacture

5/2016 – to this day

Internal designation

NC1

Engine size

NSX

Technical data

Coupé

	NSX
Date of sale	-
Engine type	Petrol supercharged + Electric
Number of cylinders/valves	6/24
Engine displacement [cm³]	3493
Maximum output / speed [kW/min-1]	373/6500-7500 35/3000 el. 2 x 27/4000 el. 427 total
Maximum torque [Nm/min-1]	550/2000-6000 147/500-2000 el. 2 x 73/0-2000 el. 646 total
Bore and stroke [mm x mm]	91,0 x 89,5
Compression ratio	10,0:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	Full Hybrid Two electric motors at the front, one petrol engine and one electric motor at the rear direct and indirect injection system variable timing of intake and exhaust valves Dual-VTC supercharging by twin turbochargers

Drive axle	4x4
Gearbox	9 gear automatic
Drive specifications	nine-speed dual-clutch automatic gearbox

Top speed [km/h]	308
Acceleration 0–100 km/h [s]	-
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	10,3
Out of town [l]	9,9
Combined [l]	10,0
CO2 emissions [g/km]	228

Emission standard	-
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1776-1814
Overall weight [kg]	-
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	42%/58%
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	110
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	2
Number of seats	2
Fuel tank volume [l]	59
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	double wishbone with stabiliser
Rear suspension	multilink
Tyre dimensions front	245 / 35 ZR 19 93Y
Tyre dimensions rear	305 / 30 ZR 20 103Y
Wheel size front	8,0J x 19
Wheel size rear	11,0J x 20
Brake dimensions front	370 x 33
Brake dimensions rear	361 x 33
Steering	-
Number of steering wheel turns	1,91
Turning diameter track/circumference [m]	12,1/-

Overall length [mm]	4487
Overall width without/including mirrors [mm]	1939/2217
Overall height [mm]	1204
Wheelbase [mm]	2630
Front wheel track [mm]	1659
Rear wheel track [mm]	1620
Forward overhang [mm]	-
Rear overhang [mm]	-
Clearance [mm]	104
Wading depth [mm]	-
Approach angle front [°]	9,2
Approach angle rear [°]	12,9
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	973
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	1384/1463
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	1384/-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
