Honda Civic

Date of manufacture

1/2007 – 10/2010 (Three-door hatchback)

10/2005 – 2011 (Five-door hatchback)

Platform

Manufacturing locations

Swindon, United Kingdom

Designer

Toshiyuki Okumoto

Car body style

Three-door hatchback

Date of manufacture

1/2007 – 10/2010

Internal designation

Engine size

Petrol

1.8 i-VTEC Type S

2.0 i-VTEC Type R

Diesel

2.2 i-CTDi Type S

Five-door hatchback

Date of manufacture

10/2005 – 2011

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Three-door hatchback

	1.8 i-VTEC Type S	1.8 i-VTEC Type S	2.0 i-VTEC Type R	2.2 i-CTDi Type S
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1799	1799	1998	2204
Maximum output / speed [kW/min-1]	103/6300	103/6300	148/7800	103/4000
Maximum torque [Nm/min-1]	174/4300	174/4300	193/5600	340/2000
Bore and stroke [mm x mm]	81,0 x 87,3	81,0 x 87,3	86,0 x 86,0	85,0 x 97,1
Compression ratio	10,5:1	10,5:1	11,0:1	16,7:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC	variable valve timing and lift i‐VTEC	direct injection Common Rail turbocharger with variable blade geometry

Drive axle	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear robotic manual	6 gear manual	6 gear manual
Drive specifications	-	robotic gearbox i‐SHIFT	-	-

Top speed [km/h]	205	205	235	205
Acceleration 0–100 km/h [s]	8.9	10.9	6.6	8.7
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.8	8.4	12.7	6.6
Out of town [l]	5.5	5.2	7.0	4.3
Combined [l]	6.7	6.4	9.1	5.1
CO2 emissions [g/km]	155	152	215	136

Emission standard	EU4-EU5	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1269	1266	1388	1383
Overall weight [kg]	1750	1750	1700	1890
Maximum trailer weight unbraked/braked [kg]	500/1400	500/1400	-	500/1500
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	45/-	80/-

Boot volume [l]	415	415	415	415
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1352	-/1352	-/1352	-/1352
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	3	3	3	3
Number of seats	5	5	4	5
Fuel tank volume [l]	50	50	50	50
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	225/45 R17 89V	225/45 R17 89V	225/40 R18 85W	225/45 R17 89V
Tyre dimensions rear	225/45 R17 89V	225/45 R17 89V	225/40 R18 85W	225/45 R17 89V
Wheel size front	7J x 17	7J x 17	7.5JJ x 18	7J x 17
Wheel size rear	7J x 17	7J x 17	7.5JJ x 18	7J x 17
Brake dimensions front	282	282	300	282
Brake dimensions rear	260	260	260	260
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	11.08/11.72	11.08/11.72	11.18/11.82	11.08/11.72

Overall length [mm]	4270	4270	4270	4270
Overall width without/including mirrors [mm]	1785/-	1785/-	1785/-	1785/-
Overall height [mm]	1460	1460	1445	1460
Wheelbase [mm]	2620	2620	2620	2620
Front wheel track [mm]	1505	1505	1505	1505
Rear wheel track [mm]	1530	1530	1530	1530
Forward overhang [mm]	850	850	850	850
Rear overhang [mm]	775	775	775	775
Clearance [mm]	150	150	134	150
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Five-door hatchback

	1.4	1.4 i-VTEC	1.4 i-VTEC	1.8 i-VTEC	1.8 i-VTEC	1.8 i-VTEC
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/8	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1339	1339	1339	1799	1799	1799
Maximum output / speed [kW/min-1]	61/5700	73/6000	73/6000	103/6300	103/6300	103/6300
Maximum torque [Nm/min-1]	119/2800	127/4800	127/4800	174/4300	174/4300	174/4300
Bore and stroke [mm x mm]	73,0 x 80,0	73,0 x 80,0	73,0 x 80,0	81,0 x 87,3	81,0 x 87,3	81,0 x 87,3
Compression ratio	10,8:1	10,5:1	10,5:1	10,5:1	10,5:1	10,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	system i‐DSI (two spark plugs per cylinder)	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear manual	6 gear robotic manual	6 gear manual	6 gear robotic manual	5 gear automatic
Drive specifications	-	-	robotic gearbox i‐SHIFT	-	robotic gearbox i‐SHIFT	automatic gearbox

Top speed [km/h]	170	177	177	205	205	197
Acceleration 0–100 km/h [s]	14.6	13.0	15.0	8.9	10.9	11.0
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	7.6	7.3	6.9	8.6	9.0	9.8
Out of town [l]	4.9	5.0	5.1	5.5	5.4	5.6
Combined [l]	5.9	5.9	5.7	6.6	6.7	7.1
CO2 emissions [g/km]	139	135	132	152	158	165

Emission standard	EU4-EU5	EU5	EU5	EU4-EU5	EU4	EU4-EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1240	1257	1260	1265	1265	1324
Overall weight [kg]	1650	1690	1690	1750	1750	1800
Maximum trailer weight unbraked/braked [kg]	500/1200	500/1200	500/1200	500/1400	500/1400	500/1000
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-	80/-	80/-

Boot volume [l]	415	415	415	415	415	415
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1352	-/1352	-/1352	-/1352	-/1352	-/1352
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	50	50	50	50	50	50
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	205/55 R16 85H	205/55 R16 85H	205/55 R16 85H	205/55 R16 89V	205/55 R16 89V	205/55 R16 89V
Tyre dimensions rear	205/55 R16 85H	205/55 R16 85H	205/55 R16 85H	205/55 R16 89V	205/55 R16 89V	205/55 R16 89V
Wheel size front	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Wheel size rear	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Brake dimensions front	282	282	282	282	282	282
Brake dimensions rear	260	260	260	260	260	260
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.26/10.92	10.26/10.92	10.26/10.92	10.26/10.92	10.26/10.92	10.26/10.92

Overall length [mm]	4245	4245	4245	4245	4245	4245
Overall width without/including mirrors [mm]	1765/-	1765/-	1765/-	1765/-	1765/-	1765/-
Overall height [mm]	1460	1460	1460	1460	1460	1460
Wheelbase [mm]	2620	2620	2620	2620	2620	2620
Front wheel track [mm]	1504	1504	1504	1504	1504	1504
Rear wheel track [mm]	1510	1510	1510	1510	1510	1510
Forward overhang [mm]	850	850	850	850	850	850
Rear overhang [mm]	775	775	775	775	775	775
Clearance [mm]	150	150	150	150	150	150
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.2 i-CTDi
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	2204
Maximum output / speed [kW/min-1]	103/4000
Maximum torque [Nm/min-1]	340/2000
Bore and stroke [mm x mm]	85,0 x 97,1
Compression ratio	16,7:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry

Drive axle	Front
Gearbox	6 gear manual
Drive specifications	-

Top speed [km/h]	205
Acceleration 0–100 km/h [s]	8.7
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	6.5
Out of town [l]	4.3
Combined [l]	5.1
CO2 emissions [g/km]	134

Emission standard	EU4
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1422
Overall weight [kg]	1890
Maximum trailer weight unbraked/braked [kg]	500/1500
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	80/-

Boot volume [l]	415
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1352
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	50
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson, torsion stabiliser
Rear suspension	torsion bar
Tyre dimensions front	205/55 R16 89V
Tyre dimensions rear	205/55 R16 89V
Wheel size front	6.5J x 16
Wheel size rear	6.5J x 16
Brake dimensions front	282
Brake dimensions rear	260
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.66/11.32

Overall length [mm]	4245
Overall width without/including mirrors [mm]	1765/-
Overall height [mm]	1460
Wheelbase [mm]	2620
Front wheel track [mm]	1504
Rear wheel track [mm]	1510
Forward overhang [mm]	850
Rear overhang [mm]	775
Clearance [mm]	150
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
