Ford Ka+

Date of manufacture

2/2015 – 2018 (Five-door hatchback)

Platform

Ford global B-car

Manufacturing locations

Sanand, India

Designer

Car body style

Five-door hatchback

Date of manufacture

2/2015 – 2018

Internal designation

Engine size

1.2 Ti-VCT

Euro NCAP

Technical data

Five-door hatchback

	1.2 Ti-VCT	1.2 Ti-VCT
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	1196	1196
Maximum output / speed [kW/min-1]	51/6000	63/6300
Maximum torque [Nm/min-1]	105/4000	112/4000
Bore and stroke [mm x mm]	-	-
Compression ratio	-	-
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake and exhaust valves Ti‐VCT	variable timing of intake and exhaust valves Ti‐VCT

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear manual
Drive specifications	-	-

Top speed [km/h]	159	169
Acceleration 0–100 km/h [s]	15.3	13.3
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	6.6	6.6
Out of town [l]	4.0	4.0
Combined [l]	5.0	5.0
CO2 emissions [g/km]	114	114

Emission standard	EU6	EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1055	1055
Overall weight [kg]	1500	1500
Maximum trailer weight unbraked/braked [kg]	-	500/500
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	270	270
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/849	-/849
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	5	5
Fuel tank volume [l]	42	42
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	195/55 R15	195/55 R15
Tyre dimensions rear	195/55 R15	195/55 R15
Wheel size front	6.0J x 15	6.0J x 15
Wheel size rear	6.0J x 15	6.0J x 15
Brake dimensions front	258 x 23	258 x 23
Brake dimensions rear	-	-
Steering	Electric power steering	Electric power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.1/-	10.1/-

Overall length [mm]	3929	3929
Overall width without/including mirrors [mm]	1695/1911	1695/1911
Overall height [mm]	1524	1524
Wheelbase [mm]	2489	2489
Front wheel track [mm]	-	-
Rear wheel track [mm]	-	-
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	1002	1002
Headroom rear [mm]	960	960
Front elbow/shoulder width [mm]	-/1361	-/1361
Rear elbow/shoulder width [mm]	-/1338	-/1338
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
