Ford Edge

Edge 2018

Date of manufacture

2018 – to this day (Large SUV)

Platform

Ford CD4 platform

Manufacturing locations

Oakville, Canada

Designer

-

Tags

Large SUV
German cars
The Ford Edge can be purchased in the large SUV body style. The vehicle has been manufactured since 2018 and is made in Canada. It is built on the Ford CD4 platform. The powertrain lineup consists exclusively of gasoline engines. The maximum power (175 kW) is provided by the 2.0 EcoBlue engine. The 2.0 EcoBlue model has the highest top speed of 216 km/h. The most fuel-efficient model is the 2.0 EcoBlue with a combined fuel consumption of 5.8 l/100 km and CO2 emissions of 153 g/km. The trunk offers a volume of 602 l. During EURONCAP safety tests, the car received a rating of 5 out of 5. Tested according to the 2016 methodology.

Car body style

Large SUV

after upgrade (facelift)
Date of manufacture
2018 – to this day
Internal designation
-

Euro NCAP

Test year 2016
Rating
star iconstar iconstar iconstar iconstar icon
Adults
85 %
Adults
Children
76 %
Children
Pedestrians
67 %
Pedestrians
Assist systems
89 %
Assist systems

Technical data

Large SUV

2.0 EcoBlue 2.0 EcoBlue 2.0 EcoBlue
Date of sale---
Engine typeIgnition superchargedIgnition superchargedIgnition supercharged
Number of cylinders/valves4/164/164/16
Engine displacement [cm³]199619961996
Maximum output / speed [kW/min-1]
110/3500
140/3500
175/4000
Maximum torque [Nm/min-1]
370/2000
400/2000-3000
500/2000
Drive axleFront4x44x4
Gearbox8 gear automatic6 gear manual8 gear automatic
Top speed [km/h]185203216
Acceleration 0–100 km/h [s]11.210.49.6
City [l]7.3-7.27.19.0-8.0
Out of town [l]5.3-5.25.36.1-5.6
Combined [l]5.9-5.86.07.2-6.5
CO2 emissions [g/km]156-153156187-169
Emission standardEuro 6d-TEMPEuro 6d-TEMPEuro 6d-TEMP
Standby weight [kg]200720302116
Overall weight [kg]256525902655
Maximum trailer weight unbraked/braked [kg]750/2000750/2000750/2000
Boot volume [l]602602602
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/1847-/1847-/1847
Number of doors555
Number of seats555
Fuel tank volume [l]646464
AdBlue tank volume [l]---
Overall length [mm]483448344834
Overall width without/including mirrors [mm]1928/21841928/21841928/2184
Overall height [mm]173217421742
Wheelbase [mm]284928492849
Headroom front [mm]102010201020
Headroom rear [mm]102310231023
Front elbow/shoulder width [mm]1420/15311420/15311420/1531
Rear elbow/shoulder width [mm]1461/15361461/15361461/1536

Gallery

Ford Edge facelift 2018 interiorFord Edge facelift 2018 front seatsFord Edge facelift 2018 rear seatsFord Edge facelift 2018 bootFord Edge facelift 2018 rear folding seats
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
