Ford EcoSport
Date of manufacture
2017 – to this day (Small SUV)
Platform
Ford global B-car
Manufacturing locations
Craiova, Romania
Designer
-
Tags
Small SUV
German cars
The Ford EcoSport, a small SUV produced in Romania on the Ford Global B-car platform since 2017, offers a wide range of engines - from petrol to diesel. The most powerful model, the 1.0 EcoBoost 140, has a power output of 103 kW and a top speed of 186 km/h. The most economical version, the 1.5 Duratorq TDCi 100, has a fuel consumption of 4.1 l/100 km and emissions of 107 g/km. The boot capacity is 325-385 l. In the EURONCAP safety tests, the car scored 4 out of 5 according to the 2013 methodology.
Car body style
Small SUV
Date of manufacture
2017 – to this dayInternal designation
-
Technical data
Small SUV
| 1.0 EcoBoost 100 | 1.0 EcoBoost 125 | 1.0 EcoBoost 125 | 1.0 EcoBoost 140 | 1.5 Duratorq TDCi 100 | 1.5 EcoBlue 100 | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | - | from to 2020 | - | from to 2018 | from 2018 to 2020 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 4/8 | 4/16 |
| Engine displacement [cm³] | 998 | 998 | 998 | 998 | 1498 | 1499 |
| Maximum output / speed [kW/min-1] | 74/4500 | 92/6000 | 92/6000 | 103/6000 | 74/3750 | 74/3600 |
| Maximum torque [Nm/min-1] | 170/1400-4000 | 170/1500-4500 | 170/1500-4500 | 180/4400 | 215/1750-3000 | 215/1750-3000 |
| Bore and stroke [mm x mm] | 71,9 x 82,0 | 71,9 x 82,0 | 71,9 x 82,0 | 71,9 x 82,0 | 73,5 x 88,3 | 75.0 x 88.3 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,0:1 | 10,0:1 | 16,0:1 | 16.0:1 |
| Oil volume [l] | 4.1 | 4.1 | 4.1 | 4.1 | 3.8 | 3.8 |
| Coolant volume [l] | 5.8 | 5.8 | 5.8 | 5.8 | 5.8 | 5.5 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual |
| Drive specifications | - | - |
| - | - | - |
| Top speed [km/h] | 170 | 180 | 180 | 186 | 160 | 160 |
| Acceleration 0–100 km/h [s] | 11.9 | 11.0 | 11.6 | 10.2 | 14.0 | 13.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.4-6.0 | 6.4-5.9 | 7.8-7.6 | 6.3-5.8 | 4.5 | 4.8-4.6 |
| Out of town [l] | 8.0-4.6 | 5.0-4.5 | 5.7-5.2 | 4.9-4.5 | 4.8 | 4.3-4.0 |
| Combined [l] | 5.5-5.1 | 5.5-5.0 | 6.4-6.2 | 5.4-5.0 | 4.1 | 4.5-4.2 |
| CO2 emissions [g/km] | 125-116 | 125-114 | 145-140 | 125-113 | 107 | 118-111 |
| Emission standard | Euro 6d-Temp - Euro 6d | Euro 6 - Euro 6d-Temp - Euro 6d | Euro 6 - Euro 6d-Temp | Euro 6 - Euro 6d-Temp - Euro 6d | Euro 6 | Euro 6 - Euro 6d-Temp |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1414 | 1414 | 1391 | 1414 | 1288 | 1395 |
| Overall weight [kg] | 1730 | 1730 | 1770 | 1730 | 1735 | 1775 |
| Maximum trailer weight unbraked/braked [kg] | 675/900 | 675/900 | 675/900 | 680/1100 | -/900 | 695/900 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 40/- | 40/- | 40/- | 40/- | 40/- | 40/- |
| Boot volume [l] | 325-385 | 325-385 | 325-385 | 325-385 | 325-385 | 325-385 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1238 | -/1238 | -/1238 | -/1238 | -/1238 | -/1238 |
| Boot length [mm] | 691 | 691 | 691 | 691 | 691 | 691 |
| Boot length with rear seats folded [mm] | 1369 | 1369 | 1369 | 1369 | 1369 | 1369 |
| Boot width between wheels/max [mm] | 950/- | 950/- | 950/- | 950/- | 950/- | 950/- |
| Boot height to headliner/ceiling [mm] | 605/1010 | 605/1010 | 605/1010 | 605/1010 | 605/1010 | 605/1010 |
| Loading edge height [mm] | 627 | 627 | 627 | 627 | 627 | 627 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 881 | 881 | 881 | 881 | 881 | 881 |
| Boot opening width min/max [mm] | -/1022 | -/1022 | -/1022 | -/1022 | -/1022 | -/1022 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | 10.5 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H |
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | 278 x 23 | 278 x 23 | 278 x 23 | 278 x 23 | 278 x 23 | 278 x 23 |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Electro-mechanical power steering EPAS | Rack & pinion with electric power steering (EPAS) |
| Number of steering wheel turns | 2.65 | 2.65 | 2.65 | 2.65 | 2.65 | 2.65 |
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- |
| Overall length [mm] | 4096 | 4096 | 4096 | 4096 | 4096 | 4096 |
| Overall width without/including mirrors [mm] | 1765/2057 | 1765/2057 | 1765/2057 | 1765/2057 | 1765/2057 | 1765/2057 |
| Overall height [mm] | 1653 | 1653 | 1653 | 1653 | 1653 | 1653 |
| Wheelbase [mm] | 2519 | 2519 | 2519 | 2519 | 2519 | 2519 |
| Front wheel track [mm] | 1530 | 1530 | 1530 | 1530 | 1530 | 1530 |
| Rear wheel track [mm] | 1522 | 1522 | 1522 | 1522 | 1522 | 1522 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 190 | 190 | 190 | 190 | 160 | 160 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 21.0 | 21.0 | 21.0 | 21.0 | 21.0 | 21.0 |
| Approach angle rear [°] | 33.3 | 33.3 | 33.3 | 33.3 | 33.3 | 33.3 |
| Transition angle [°] | 23.3 | 23.3 | 23.3 | 23.3 | 23.3 | 23.3 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1008 | 1008 | 1008 | 1008 | 1008 | 1008 |
| Headroom rear [mm] | 971 | 971 | 971 | 971 | 971 | 971 |
| Front elbow/shoulder width [mm] | -/1355 | -/1355 | -/1355 | -/1355 | -/1355 | -/1355 |
| Rear elbow/shoulder width [mm] | -/1302 | -/1302 | -/1302 | -/1302 | -/1302 | -/1302 |
| Legroom front knees/total [mm] | -/1086 | -/1086 | -/1086 | -/1086 | -/1086 | -/1086 |
| Legroom rear knees/total [mm] | -/956 | -/956 | -/956 | -/956 | -/956 | -/956 |
| 1.5 EcoBlue 125 | 1.5 EcoBlue 125 AWD | |||||
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to 2020 | from to 2020 | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1499 | 1499 | ||||
| Maximum output / speed [kW/min-1] | 92/3600 | 92/3600 | ||||
| Maximum torque [Nm/min-1] | 300/1750-2000 | 300/1750-2000 | ||||
| Bore and stroke [mm x mm] | 75.0 x 88.3 | 75.0 x 88.3 | ||||
| Compression ratio | 16.0:1 | 16.0:1 | ||||
| Oil volume [l] | 3.8 | 3.8 | ||||
| Coolant volume [l] | 5.5 | 5.5 | ||||
| Technical specifications |
|
| ||||
| Drive axle | Front | 4x4 | ||||
| Gearbox | 6 gear manual | 6 gear manual | ||||
| Drive specifications | - |
| ||||
| Top speed [km/h] | 183 | 181 | ||||
| Acceleration 0–100 km/h [s] | 10.7 | 11.3 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 5.0-4.7 | 5.8-5.1 | ||||
| Out of town [l] | 4.5-4.2 | 5.2-4.6 | ||||
| Combined [l] | 4.7-4.4 | 5.4-4.8 | ||||
| CO2 emissions [g/km] | 123-113 | 140-125 | ||||
| Emission standard | Euro 6 - Euro 6d-Temp | Euro 6 - Euro 6d-Temp | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1423 | 1520 | ||||
| Overall weight [kg] | 1805 | 1895 | ||||
| Maximum trailer weight unbraked/braked [kg] | 710/900 | 750/1100 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | ||||
| Maximum load on roof/carrier [kg] | 40/- | 40/- | ||||
| Boot volume [l] | 325-385 | 325-385 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1238 | -/1238 | ||||
| Boot length [mm] | 691 | 691 | ||||
| Boot length with rear seats folded [mm] | 1369 | 1369 | ||||
| Boot width between wheels/max [mm] | 950/- | 950/- | ||||
| Boot height to headliner/ceiling [mm] | 605/1010 | 605/1010 | ||||
| Loading edge height [mm] | 627 | 627 | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | 881 | 881 | ||||
| Boot opening width min/max [mm] | -/1022 | -/1022 | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 52 | 52 | ||||
| AdBlue tank volume [l] | 10.5 | 10.5 | ||||
| Air resistance [Cd] | - | - | ||||
| Front suspension | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | ||||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | ||||
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | ||||
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | ||||
| Wheel size front | 6.0J x 16 | 6.0J x 16 | ||||
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | ||||
| Brake dimensions front | 278 x 23 | 278 x 23 | ||||
| Brake dimensions rear | - | - | ||||
| Steering | Rack & pinion with electric power steering (EPAS) | Rack & pinion with electric power steering (EPAS) | ||||
| Number of steering wheel turns | 2.65 | 2.65 | ||||
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | ||||
| Overall length [mm] | 4096 | 4096 | ||||
| Overall width without/including mirrors [mm] | 1765/2057 | 1765/2057 | ||||
| Overall height [mm] | 1653 | 1653 | ||||
| Wheelbase [mm] | 2519 | 2519 | ||||
| Front wheel track [mm] | 1530 | 1530 | ||||
| Rear wheel track [mm] | 1522 | 1522 | ||||
| Forward overhang [mm] | - | - | ||||
| Rear overhang [mm] | - | - | ||||
| Clearance [mm] | 160 | 160 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | 21.0 | 21.0 | ||||
| Approach angle rear [°] | 33.3 | 33.3 | ||||
| Transition angle [°] | 23.3 | 23.3 | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1008 | 1008 | ||||
| Headroom rear [mm] | 971 | 971 | ||||
| Front elbow/shoulder width [mm] | -/1355 | -/1355 | ||||
| Rear elbow/shoulder width [mm] | -/1302 | -/1302 | ||||
| Legroom front knees/total [mm] | -/1086 | -/1086 | ||||
| Legroom rear knees/total [mm] | -/956 | -/956 |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
