Basic information Technical Specifications Gallery

Ford EcoSport

Date of manufacture

2014 – 2017 (Small SUV)

Platform

Ford global B-car

Manufacturing locations

Craiova, Romania

Designer

Car body style

Small SUV

Date of manufacture

2014 – 2017

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Small SUV

	1.5 Ti-VCT	1.5 Ti-VCT	1.0 EcoBoost 125	1.0 EcoBoost 140	1.5 Duratorq TDCi
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	3/12	3/12	4/8
Engine displacement [cm³]	1499	1499	999	999	1498
Maximum output / speed [kW/min-1]	82/6300	82/6300	92/6000	103/6000	70/3750
Maximum torque [Nm/min-1]	140/4300	140/4300	170/1400-4000	180/1400-5000	215/1750-3000
Bore and stroke [mm x mm]	79.0 x 76.4	79.0 x 76.4	71,9 x 82,0	71,9 x 82,0	73,5 x 88,3
Compression ratio	11.0:1	11.0:1	10,0:1	10,0:1	16,0:1
Oil volume [l]	4.4	4.4	4.1	4.1	3.8
Coolant volume [l]	-	-	5.5	5.5	5.8
Technical specifications	variable valve timing Ti‐VCT	variable valve timing Ti‐VCT	direct injection turbo-supercharged variable valve timing Ti‐VCT	direct injection turbo-supercharged variable valve timing Ti‐VCT	direct injection Common Rail turbo-supercharged particulate filter cDPF

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear automatic	5 gear manual	5 gear manual	5 gear manual
Drive specifications	-	six-speed dual-clutch automatic gearbox PowerShift	-	-	-

Top speed [km/h]	172	172	180	185	160
Acceleration 0–100 km/h [s]	13.3	14.1	12.7	11.8	14.0
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	8.1	7.9	6.6	6.6	4.8
Out of town [l]	5.2	5.3	4.7	4.7	4.3
Combined [l]	6.3	6.3	5.4	5.4	4.4
CO2 emissions [g/km]	149	149	125	125	115

Emission standard	EU6	EU6	EU6	EU6	-
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1314	1350	1337	1337	1372
Overall weight [kg]	1705	1740	1730	1730	1760
Maximum trailer weight unbraked/braked [kg]	675/750	400/400	675/750	-	690/700
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	40/-	40/-	40/-	40/-	-

Boot volume [l]	310-375	310-375	310-375	310-375	310-375
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1238	-/1238	-/1238	-/1238	-/1238
Boot length [mm]	691	691	691	691	691
Boot length with rear seats folded [mm]	1369	1369	1369	1369	1369
Boot width between wheels/max [mm]	950/-	950/-	950/-	950/-	950/-
Boot height to headliner/ceiling [mm]	605/1010	605/1010	605/1010	605/1010	605/1010
Loading edge height [mm]	627	627	627	627	627
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	881	881	881	881	881
Boot opening width min/max [mm]	-/1022	-/1022	-/1022	-/1022	-/1022

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	52	52	52	52	52
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H
Tyre dimensions rear	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H
Wheel size front	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Wheel size rear	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Brake dimensions front	278 x 23	278 x 23	278 x 23	278 x 23	278 x 23
Brake dimensions rear	-	-	-	-	-
Steering	Electro-mechanical power steering EPAS	Electro-mechanical power steering EPAS	Electro-mechanical power steering EPAS	Electro-mechanical power steering EPAS	Electro-mechanical power steering EPAS
Number of steering wheel turns	2.65	2.65	2.65	2.65	2.65
Turning diameter track/circumference [m]	10.6/-	10.6/-	10.6/-	10.6/-	10.6/-

Overall length [mm]	4017	4017	4017	4017	4017
Overall width without/including mirrors [mm]	1765/2057	1765/2057	1765/2057	1765/2057	1765/2057
Overall height [mm]	1633	1633	1633	1633	1633
Wheelbase [mm]	2519	2519	2519	2519	2519
Front wheel track [mm]	1530	1530	1530	1530	1530
Rear wheel track [mm]	1522	1522	1522	1522	1522
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	21.0	21.0	21.0	21.0	21.0
Approach angle rear [°]	33.3	33.3	33.3	33.3	33.3
Transition angle [°]	23.3	23.3	23.3	23.3	23.3
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1008	1008	1008	1008	1008
Headroom rear [mm]	971	971	971	971	971
Front elbow/shoulder width [mm]	-/1355	-/1355	-/1355	-/1355	-/1355
Rear elbow/shoulder width [mm]	-/1302	-/1302	-/1302	-/1302	-/1302
Legroom front knees/total [mm]	-/1086	-/1086	-/1086	-/1086	-/1086
Legroom rear knees/total [mm]	-/956	-/956	-/956	-/956	-/956

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
