Fiat Linea

Date of manufacture

6/2007 – 2012 (Sedan)

Platform

GM Fiat Small platform

Manufacturing locations

Bursa, Turkey

Designer

Centro Stile Fiat

Car body style

Sedan

Date of manufacture

6/2007 – 2012

Internal designation

323

Engine size

Petrol

Diesel

Technical data

Sedan

	1.4	1.4 T-Jet 16V	1.3 Multijet 16V	1.3 Multijet 16V	1.6 Multijet 16v
Date of sale	-	-	-	-	-
Engine type	Petrol	Ignition supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/8	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1368	1368	1248	1248	1598
Maximum output / speed [kW/min-1]	57/6000	88/5000	66/4000	66/4000	77/4000
Maximum torque [Nm/min-1]	115/3000	206/2500	200/1750	200/1750	290/1500
Bore and stroke [mm x mm]	72,0 x 84,0	72,0 x 84,0	69,6 x 82,0	69,6 x 82,0	79,5 x 80,5
Compression ratio	11,1:1	9,8:1	17,6:1	17,6:1	16,5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	-	turbo-supercharged	direct injection Multijet with Common Rail turbocharger with variable blade geometry	direct injection Multijet with Common Rail turbocharger with variable blade geometry	direct injection Multijet with Common Rail turbocharger with variable blade geometry

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	6 gear robotic manual	6 gear manual
Drive specifications	-	-	-	robotic gearbox Dualogic	-

Top speed [km/h]	165	200	170	170	190
Acceleration 0–100 km/h [s]	14.6	9.0	13.8	13.8	11.0
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	8.2	9.2	6.5	6.1	6.4
Out of town [l]	5.1	5.2	4.0	3.9	4.2
Combined [l]	6.3	6.7	4.9	4.7	5.0
CO2 emissions [g/km]	148	157	129	123	131

Emission standard	EU4/EU5	EU4	EU4	EU4	EU4/EU5
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1235	1255	1260	1320	1290
Overall weight [kg]	-	-	-	-	-
Maximum trailer weight unbraked/braked [kg]	500/1200	500/1200	500/1200	500/1200	500/1200
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	500	500	500	500	500
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/870	-/870	-/870	-/870	-/870
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	4	4	4	4	4
Number of seats	5	5	5	5	5
Fuel tank volume [l]	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	185/65 R15 T	185/65 R15 H	185/65 R15 T	185/65 R15 T	185/65 R15 T
Tyre dimensions rear	185/65 R15 T	185/65 R15 H	185/65 R15 T	185/65 R15 T	185/65 R15 T
Wheel size front	-	-	-	-	-
Wheel size rear	-	-	-	-	-
Brake dimensions front	257	284	257	257	284
Brake dimensions rear	228	251	228	228	251
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	10.5/-	10.5/-	10.5/-	10.5/-	10.5/-

Overall length [mm]	4560	4560	4560	4560	4560
Overall width without/including mirrors [mm]	1730/-	1730/-	1730/-	1730/-	1730/-
Overall height [mm]	1494	1494	1494	1494	1494
Wheelbase [mm]	2603	2603	2603	2603	2603
Front wheel track [mm]	1471	1471	1471	1471	1471
Rear wheel track [mm]	1483	1483	1483	1483	1483
Forward overhang [mm]	928	928	928	928	928
Rear overhang [mm]	1029	1029	1029	1029	1029
Clearance [mm]	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
