Ferrari Monza

Date of manufacture

2019 – to this day (Roadster)

Platform

Manufacturing locations

Maranello, Italy

Designer

Ferrari Styling Centre

Car body style

Roadster

Date of manufacture

2019 – to this day

Internal designation

Engine size

Monza SP1

Monza SP2

Technical data

Roadster

	Monza SP1	Monza SP2
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	12/48	12/48
Engine displacement [cm³]	6496	6496
Maximum output / speed [kW/min-1]	596/8500	596/8500
Maximum torque [Nm/min-1]	719/7000	719/7000
Bore and stroke [mm x mm]	94.0 x 78.0	94.0 x 78.0
Compression ratio	13.6:1	13.6:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	-	-

Drive axle	Rear	Rear
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	seven-speed dual-clutch automatic gearbox	seven-speed dual-clutch automatic gearbox

Top speed [km/h]	>300	>300
Acceleration 0–100 km/h [s]	2.9	2.9
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	-	-
Out of town [l]	-	-
Combined [l]	-	-
CO2 emissions [g/km]	-	-

Low speed [l]	25.5	25.5
Medium speed [l]	15.6	15.6
High speed [l]	13.8	13.8
Extra high speed [l]	15.0	15.0
Combined speed [l]	16.1	16.1
CO2 emissions [g/km]	366	366

Emission standard	-	-
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1500 net weight	1520 net weight
Overall weight [kg]	-	-
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	-	-
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	1	2
Number of seats	1	2
Fuel tank volume [l]	90	90
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	275/30 ZR 21	275/30 ZR 21
Tyre dimensions rear	315/30 ZR 21	315/30 ZR 21
Wheel size front	10,0J x 21	10,0J x 21
Wheel size rear	11.5J x 21	11.5J x 21
Brake dimensions front	398 x 38	398 x 38
Brake dimensions rear	360 x 32	360 x 32
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4657	4657
Overall width without/including mirrors [mm]	1996/-	1996/-
Overall height [mm]	1155	1155
Wheelbase [mm]	2720	2720
Front wheel track [mm]	1688	1688
Rear wheel track [mm]	1678	1678
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
