Ferrari F488

Date of manufacture

2015 – 2019 (Coupé)

2015 – 2019 (Roadster)

Platform

Manufacturing locations

Maranello, Italy

Designer

Ferrari Styling Centre

Car body style

Coupé

Date of manufacture

2015 – 2019

Internal designation

F142M

Engine size

488 GTB

488 Pista

Roadster (Spider)

Date of manufacture

2015 – 2019

Internal designation

Engine size

488 Spider

488 Spider Pista

Technical data

Coupé

	488 GTB	488 Pista
Date of sale	-	from 2018 to
Engine type	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	8/32	8/32
Engine displacement [cm³]	3902	3902
Maximum output / speed [kW/min-1]	492/8000	530/8000
Maximum torque [Nm/min-1]	760/3000	770/3000
Bore and stroke [mm x mm]	86.5 x 83.0	86.5 x 83.0
Compression ratio	9.4:1	9.6:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection supercharging by twin turbochargers with compressed air intercooler variable timing of intake and exhaust valves	direct injection supercharging by twin turbochargers with compressed air intercooler variable timing of intake and exhaust valves

Drive axle	Rear	Rear
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	seven-speed dual-clutch automatic gearbox F1	seven-speed dual-clutch automatic gearbox F1

Top speed [km/h]	>330	>340
Acceleration 0–100 km/h [s]	3.0	2.85
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	-	-
Out of town [l]	-	-
Combined [l]	11.4	-
CO2 emissions [g/km]	260	-

Low speed [l]	-	19.4
Medium speed [l]	-	11.8
High speed [l]	-	11.0
Extra high speed [l]	-	12.4
Combined speed [l]	-	12.8
CO2 emissions [g/km]	-	289

Emission standard	-	-
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1420 net weight	1280 net weight
Overall weight [kg]	-	-
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	230	170
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	78	78
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	245/35 ZR20	245/35 ZR20
Tyre dimensions rear	305/30 ZR20	305/30 ZR20
Wheel size front	9.0J x 20	9.0J x 20
Wheel size rear	11.0J x 20	11.0J x 20
Brake dimensions front	398 x 223 x 36	398 x 223 x 38
Brake dimensions rear	360 x 233 x 32	360 x 233 x 32
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4568	4605
Overall width without/including mirrors [mm]	1952/-	1975/-
Overall height [mm]	1213	1206
Wheelbase [mm]	2650	2650
Front wheel track [mm]	1679	1679
Rear wheel track [mm]	1647	1647
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Roadster (Spider)

	488 Spider	488 Spider Pista
Date of sale	-	from 2018 to
Engine type	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	8/32	8/32
Engine displacement [cm³]	3902	3902
Maximum output / speed [kW/min-1]	492/8000	530/8000
Maximum torque [Nm/min-1]	760/3000	770/3000
Bore and stroke [mm x mm]	86.5 x 83.0	86.5 x 83.0
Compression ratio	9.4:1	9.6:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection supercharging by twin turbochargers with compressed air intercooler variable timing of intake and exhaust valves	direct injection supercharging by twin turbochargers with compressed air intercooler variable timing of intake and exhaust valves

Drive axle	Rear	Rear
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	seven-speed dual-clutch automatic gearbox F1	seven-speed dual-clutch automatic gearbox F1

Top speed [km/h]	>330	>340
Acceleration 0–100 km/h [s]	3.0	2.85
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	-	-
Out of town [l]	-	-
Combined [l]	11.4	-
CO2 emissions [g/km]	260	-

Low speed [l]	-	19.4
Medium speed [l]	-	11.8
High speed [l]	-	11.0
Extra high speed [l]	-	12.4
Combined speed [l]	-	12.8
CO2 emissions [g/km]	-	289

Emission standard	-	-
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1420 net weight	1380 net weight
Overall weight [kg]	-	-
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	230	170
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	78	78
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	245/35 ZR20	245/35 ZR20
Tyre dimensions rear	305/30 ZR20	305/30 ZR20
Wheel size front	9.0J x 20	9.0J x 20
Wheel size rear	11.0J x 20	11.0J x 20
Brake dimensions front	398 x 223 x 36	398 x 223 x 38
Brake dimensions rear	360 x 233 x 32	360 x 233 x 32
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4568	4605
Overall width without/including mirrors [mm]	1952/-	1975/-
Overall height [mm]	1211	1206
Wheelbase [mm]	2650	2650
Front wheel track [mm]	1679	1679
Rear wheel track [mm]	1647	1647
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
