Ferrari F12

Date of manufacture

2012 – 2017 (Coupé)

Platform

Manufacturing locations

Maranello, Italy

Designer

Flavio Manzoni

Car body style

Coupé

Date of manufacture

2012 – 2017

Internal designation

F152

Engine size

F12 Berlinetta

F12 tdf

Technical data

Coupé

	F12 Berlinetta	F12 tdf
Date of sale	-	from 2015 to
Engine type	Petrol	Petrol
Number of cylinders/valves	12/48	12/48
Engine displacement [cm³]	6262	6262
Maximum output / speed [kW/min-1]	545/8250	574/8500
Maximum torque [Nm/min-1]	690/6000	705/6250
Bore and stroke [mm x mm]	94,0 x 75,2	94,0 x 75,2
Compression ratio	13,5:1	13,5:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection variable valve timing start&stop system HELE	direct injection variable valve timing start&stop system HELE

Drive axle	Rear	Rear
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	dual-clutch automatic gearbox F1	dual-clutch automatic gearbox F1

Top speed [km/h]	340	340
Acceleration 0–100 km/h [s]	3.1	2.9
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	-	-
Out of town [l]	-	-
Combined [l]	15.0	15.4
CO2 emissions [g/km]	350	360

Emission standard	-	-
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1525	1415
Overall weight [kg]	-	-
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	320	-
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	92	92
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.299	0.299
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	255/35 ZR20	275/35 ZR 20
Tyre dimensions rear	315/35 ZR20	315/35 ZR 20
Wheel size front	9.5 J	10 J
Wheel size rear	11.5 J	11.5 J
Brake dimensions front	398 x 233 x 38	-
Brake dimensions rear	360 x 233 x 32	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4618	4656
Overall width without/including mirrors [mm]	1942/-	1961/-
Overall height [mm]	1273	1273
Wheelbase [mm]	2720	2720
Front wheel track [mm]	1665	1673
Rear wheel track [mm]	1618	1648
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
