DS DS7 Crossback
Date of manufacture
2017 – to this day (Medium SUV)
Platform
PSA EMP2
Manufacturing locations
Mulhouse, France
Designer
-
Tags
Compact SUV
French cars
The DS DS7 Crossback is a mid-size SUV produced by the French carmaker since 2017. It is built on the PSA EMP2 platform and offers a wide range of engines - petrol, diesel and hybrid. The most powerful engine is the E-Tense 4x4 300 with 220 kW of power and a maximum speed of 236 km/h. The model E-Tense 225 boasts the lowest combined fuel consumption of 1.6 l/100 km and CO2 emissions of 36 g/km. The luggage compartment offers a capacity of 555 liters. In the EURONCAP safety test of 2017, the car achieved a rating of 5 out of 5.
Car body style
Medium SUV
Date of manufacture
2017 – to this dayInternal designation
-Engine size
Technical data
Medium SUV
| 1.2 Puretech 130 | 1.6 Puretech 180 | 1.6 Puretech 225 | E-Tense 225 | E-Tense 4x4 300 | 1.5 BlueHDI 130 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | from 2020 to | from 2019 to | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Petrol supercharged + Electric | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1199 | 1598 | 1598 | 1598 | 1598 | 1499 |
| Maximum output / speed [kW/min-1] | 96/5500 | 133/5500 | 165/5500 | 133/6000 81/2500 el. 165 total | 147/6000 81/2500 el. 81/14000 el. 220 total | 96/3750 |
| Maximum torque [Nm/min-1] | 230/1750 | 250/1650 | 300/1900 | 300/3000 320 el. 360 total | 300/3000 320 el. 166 el. 520 total | 300/1750 |
| Bore and stroke [mm x mm] | 75 x 90,5 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 75.0 x 84,8 |
| Compression ratio | 10.5:1 | 10.2:1 | 10.2:1 | 10.2:1 | 10.2:1 | 16.4:1 |
| Oil volume [l] | 4.4 | 4.8 | 4.8 | - | - | 4.1 |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | 4x4 | Front |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual |
| Drive specifications |
|
|
|
|
| - |
| Top speed [km/h] | 195 | 220 | 236 | 225 [135 el.] | 240 [135 el.] | 194 |
| Acceleration 0–100 km/h [s] | 11.0 | 9,6 | 8,3 | 8.9 | 5.9 | 10,8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 5.9-5.7 | 7.5-6.4 | 7.4-6.7 | - | - | 4.6 |
| Out of town [l] | 4.7-4.5 | 4.9-4.6 | 4.9-4.8 | - | - | 3.8 |
| Combined [l] | 5.1-5.0 | 5.9-5.2 | 5.8-5.5 | 1.6 | 1.7 | 4.1 |
| CO2 emissions [g/km] | 118-114 | 134-119 | 134-125 | 36 | 38 | 107 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | 7.0-6.9 | 7.1-7.0 | - | - | 5.4 |
| CO2 emissions [g/km] | - | 158-157 | 163-162 | - | - | 142 |
| Emission standard | Euro 6d-ISC | Euro 6d-TEMP - Euro 6d-ISC | Euro 6d-TEMP - Euro 6d-ISC | Euro 6d | Euro 6d | Euro 6d-TEMP-EVAP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | - | - | - | Lithium-Ionen-Akkumulator, 13.2 kWh | Lithium-Ionen-Akkumulator, 13.2 kWh | - |
| Range with fully charged battery [km] | - | - | - | - | 58 | - |
| Charging time | - | - | - |
|
| - |
| Number of modules/cells | - | - | - | -/96 | -/96 | - |
| Battery weight [kg] | - | - | - | 130 | 130 | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1505-1706 | 1500-1690 | 1500-1690 | 1760-1821 | 1900-2061 | 1495 |
| Overall weight [kg] | 2010 | 2050 | 2050 | 2350 | 2400 | 2030 |
| Maximum trailer weight unbraked/braked [kg] | 695/1290 | 750/1550 | 750/1550 | 750/1250 | 750/1200 | 745/1500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 59 | 68 | 68 | 55 | 55 | 64 |
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | 80/- | 80/- |
| Boot volume [l] | 555 | 555 | 555 | 555 | 555 | 555 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1752 | -/1752 | -/1752 | -/1752 | -/1752 | -/1752 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 764 | 764 | 764 | 764 | 764 | 764 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 62 | 62 | 62 | 43 | 43 | 55 |
| AdBlue tank volume [l] | - | - | - | - | - | 18 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 215/65 R17 | 235/50 R19 | 235/50 R19 | 205/55 R19 | 205/55 R19 | 215/65 R17 |
| Tyre dimensions rear | 215/65 R17 | 235/50 R19 | 235/50 R19 | 205/55 R19 | 205/55 R19 | 215/65 R17 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 304 | 304 | 304 | - | - | 304 |
| Brake dimensions rear | 290 | 290 | 290 | - | - | 290 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 3 | 3 | 3 | 3 | 3 | 3 |
| Turning diameter track/circumference [m] | 10.45/- | 10.45/- | 10.45/- | 10.45/- | 10.45/- | 10.45/- |
| Overall length [mm] | 4573 | 4573 | 4573 | 4573 | 4573 | 4573 |
| Overall width without/including mirrors [mm] | 1906/2098 | 1906/2098 | 1906/2098 | 1906/2098 | 1906/2098 | 1906/2098 |
| Overall height [mm] | 1625 | 1625 | 1625 | 1625 | 1625 | 1625 |
| Wheelbase [mm] | 2738 | 2738 | 2738 | 2738 | 2738 | 2738 |
| Front wheel track [mm] | 1621-1637 | 1621-1637 | 1621-1637 | 1621-1637 | 1621-1637 | 1621-1637 |
| Rear wheel track [mm] | 1600-1616 | 1600-1616 | 1600-1616 | 1600-1616 | 1600-1616 | 1600-1616 |
| Forward overhang [mm] | 925 | 925 | 925 | 925 | 925 | 925 |
| Rear overhang [mm] | 910 | 910 | 910 | 910 | 910 | 910 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.5 BlueHDI 130 | 2.0 BlueHDi 180 | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1499 | 1997 | ||||
| Maximum output / speed [kW/min-1] | 96/3750 | 130/3750 | ||||
| Maximum torque [Nm/min-1] | 300/1750 | 400/2000 | ||||
| Bore and stroke [mm x mm] | 75.0 x 84,8 | 85,0 x 88,0 | ||||
| Compression ratio | 16.4:1 | 16.7:1 | ||||
| Oil volume [l] | 4.1 | 5.1 | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | Front | Front | ||||
| Gearbox | 8 gear automatic | 8 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 194 | 218 | ||||
| Acceleration 0–100 km/h [s] | 10,8 | 9,4 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 4.6-4.1 | 5.6 | ||||
| Out of town [l] | 3.8-3.6 | 4.4 | ||||
| Combined [l] | 4.1-3.8 | 4.1 | ||||
| CO2 emissions [g/km] | 107-100 | 107 | ||||
| Low speed [l] | - | - | ||||
| Medium speed [l] | - | - | ||||
| High speed [l] | - | - | ||||
| Extra high speed [l] | - | - | ||||
| Combined speed [l] | 5.2 | 6.2-6.1 | ||||
| CO2 emissions [g/km] | 136 | 162-161 | ||||
| Emission standard | Euro 6d-TEMP-EVAP - Euro 6d-ISC | Euro 6d-TEMP-EVAP - Euro 6d-ISC | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1503-1704 | 1610-1794 | ||||
| Overall weight [kg] | 2050 | 2115-2135 | ||||
| Maximum trailer weight unbraked/braked [kg] | 745/1430 | 750/1550-1850 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | 64 | 68-80 | ||||
| Maximum load on roof/carrier [kg] | 80/- | 80/- | ||||
| Boot volume [l] | 555 | 555 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1752 | -/1752 | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | 764 | 764 | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 55 | 55 | ||||
| AdBlue tank volume [l] | 18 | 18 | ||||
| Air resistance [Cd] | - | - | ||||
| Front suspension | MacPherson | MacPherson | ||||
| Rear suspension | multilink | multilink | ||||
| Tyre dimensions front | 215/65 R17 | 215/65 R17 | ||||
| Tyre dimensions rear | 215/65 R17 | 215/65 R17 | ||||
| Wheel size front | - | - | ||||
| Wheel size rear | - | - | ||||
| Brake dimensions front | 304 | 304 | ||||
| Brake dimensions rear | 290 | 290 | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | 3 | 3 | ||||
| Turning diameter track/circumference [m] | 10.45/- | 10.45/- | ||||
| Overall length [mm] | 4573 | 4573 | ||||
| Overall width without/including mirrors [mm] | 1906/2098 | 1906/2098 | ||||
| Overall height [mm] | 1625 | 1625 | ||||
| Wheelbase [mm] | 2738 | 2738 | ||||
| Front wheel track [mm] | 1621-1637 | 1621-1637 | ||||
| Rear wheel track [mm] | 1600-1616 | 1600-1616 | ||||
| Forward overhang [mm] | 925 | 925 | ||||
| Rear overhang [mm] | 910 | 910 | ||||
| Clearance [mm] | - | - | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | - | - | ||||
| Headroom rear [mm] | - | - | ||||
| Front elbow/shoulder width [mm] | - | - | ||||
| Rear elbow/shoulder width [mm] | - | - | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
