DS DS5
Date of manufacture
2015 – 2018 (Five-door hatchback)
Platform
PSA PF2
Manufacturing locations
Sochaux, France
Designer
-
Tags
D-segment
French cars
The DS5 is a five-door hatchback that has been manufactured in France since 2015 on the PSA PF2 platform. The engine range includes petrol, diesel and hybrid power units. The most powerful version, the 1.6 THP 210, has 155 kW and can reach speeds of up to 235 km/h. The most economical model is the 2.0 BlueHDI Hybrid4 hybrid with a combined fuel consumption of 3.5 l/100 km and CO2 emissions of 90 g/km. The car's boot has a capacity of 325 l.
Car body style
Five-door hatchback
Date of manufacture
2015 – 2018Internal designation
-Engine size
PetrolDieselDiesel + Electric
Technical data
Five-door hatchback
| 1.6 THP 165 | 1.6 THP 210 | 1.6 BlueHDi 120 | 1.6 BlueHDi 120 | 2.0 BlueHDi 150 | 2.0 BlueHDi 180 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/8 | 4/8 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1560 | 1560 | 1997 | 1997 |
| Maximum output / speed [kW/min-1] | 121/6000 | 155/6000 | 88/3500 | 88/3500 | 110/4000 | 133/3750 |
| Maximum torque [Nm/min-1] | 240/1400 | 285/1750 | 300/1750 | 300/1750 | 370/2000 | 400/2000 |
| Bore and stroke [mm x mm] | 77,0 x 85,8 | 77,0 x 85,8 | 75,0 x 88,3 | 75,0 x 88,3 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | 10.2:1 | 10.2:1 | - | - | - | 16.7:1 |
| Oil volume [l] | - | - | - | - | - | 5.1 |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications |
| - | - |
| - |
|
| Top speed [km/h] | 202 | 235 | 191 | 189 | 210 | 220 |
| Acceleration 0–100 km/h [s] | 9.7 | 8.8 | 11.7 | 11.9 | 10.6 | 9.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.7-7.6 | 8.0 | 4.6-4.5 | 4.8 | 5.2-5.1 | 5.1 |
| Out of town [l] | 4.9 | 5.2 | 3.6-3.4 | 3.7 | 3.8 | 4.1-3.8 |
| Combined [l] | 5.9 | 6.2 | 4.0-3.8 | 4.1 | 4.3 | 4.4-4.3 |
| CO2 emissions [g/km] | 136-135 | 144 | 104-100 | 108-105 | 113-110 | 114-110 |
| Emission standard | Euro 6 | Euro 6 | Euro 6 | Euro 6 | Euro 6 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1504-1678 | 1505-1635 | 1503-1634 | 1509-1640 | 1612-1735 | 1615-1754 |
| Overall weight [kg] | 2017 | 2010 | 2020 | 2025 | 2130 | 2125 |
| Maximum trailer weight unbraked/braked [kg] | 750/1400 | 750/1050 | 745/1400 | 740/1050 | 750/1500 | 750/1500 |
| Maximum front/rear axle load [kg] | 1130/1050 | 1090/960 | 1130/1050 | 1090/970 | 1190/1.050 | 1200/1050 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 468 | 468 | 468 | 468 | 468 | 468 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1288 | -/1288 | -/1288 | -/1288 | -/1288 | -/1288 |
| Boot length [mm] | 820 | 820 | 820 | 820 | 820 | 820 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | -/1202 | -/1202 | -/1202 | -/1202 | -/1202 | -/1202 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | - | - | 17 | 17 | 17 | 17 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/55 R17 | 215/55 R17 | 215/60 R16 | 215/60 R16 | 215/55 R17 | 215/55 R17 |
| Tyre dimensions rear | 215/55 R17 | 215/55 R17 | 215/60 R16 | 215/60 R16 | 215/55 R17 | 215/55 R17 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- |
| Overall length [mm] | 4530 | 4530 | 4530 | 4530 | 4530 | 4530 |
| Overall width without/including mirrors [mm] | 1871/2128 | 1871/2128 | 1871/2128 | 1871/2128 | 1871/2128 | 1871/2128 |
| Overall height [mm] | 1505 | 1505 | 1505 | 1505 | 1505 | 1505 |
| Wheelbase [mm] | 2727 | 2727 | 2727 | 2727 | 2727 | 2727 |
| Front wheel track [mm] | 1575-1582 | 1575-1582 | 1575-1582 | 1575-1582 | 1575-1582 | 1575-1582 |
| Rear wheel track [mm] | 1599-1609 | 1599-1609 | 1599-1609 | 1599-1609 | 1599-1609 | 1599-1609 |
| Forward overhang [mm] | 996 | 996 | 996 | 996 | 996 | 996 |
| Rear overhang [mm] | 807 | 807 | 807 | 807 | 807 | 807 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.0 BlueHDI Hybrid4 | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Diesel supercharged + Electric | |||||
| Number of cylinders/valves | 4/16 | |||||
| Engine displacement [cm³] | 1997 | |||||
| Maximum output / speed [kW/min-1] | 120/3850 27 el. 147 total | |||||
| Maximum torque [Nm/min-1] | 300/1750 200 el. | |||||
| Bore and stroke [mm x mm] | 85,0 x 88,0 | |||||
| Compression ratio | - | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | 4x4 | |||||
| Gearbox | 6 gear robotic manual | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 211 | |||||
| Acceleration 0–100 km/h [s] | 8.6 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | 3.2-3.0 | |||||
| Out of town [l] | 4.3-3.7 | |||||
| Combined [l] | 3.9-3.5 | |||||
| CO2 emissions [g/km] | 103-90 | |||||
| Emission standard | Euro 6 | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| Standby weight [kg] | 1735 | |||||
| Overall weight [kg] | 2265 | |||||
| Maximum trailer weight unbraked/braked [kg] | 500/800 | |||||
| Maximum front/rear axle load [kg] | 1200/1190 | |||||
| Maximum vertical load on the tow bar [kg] | - | |||||
| Maximum load on roof/carrier [kg] | 75/- | |||||
| Boot volume [l] | 325 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1145 | |||||
| Boot length [mm] | 820 | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | -/1202 | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 5 | |||||
| Number of seats | 5 | |||||
| Fuel tank volume [l] | 60 | |||||
| AdBlue tank volume [l] | 17 | |||||
| Air resistance [Cd] | - | |||||
| Front suspension | MacPherson | |||||
| Rear suspension | twist beam axle with trailing arms | |||||
| Tyre dimensions front | 215/55 R17 | |||||
| Tyre dimensions rear | 215/55 R17 | |||||
| Wheel size front | - | |||||
| Wheel size rear | - | |||||
| Brake dimensions front | - | |||||
| Brake dimensions rear | - | |||||
| Steering | - | |||||
| Number of steering wheel turns | - | |||||
| Turning diameter track/circumference [m] | 11.2/- | |||||
| Overall length [mm] | 4530 | |||||
| Overall width without/including mirrors [mm] | 1871/2128 | |||||
| Overall height [mm] | 1505 | |||||
| Wheelbase [mm] | 2727 | |||||
| Front wheel track [mm] | 1575-1582 | |||||
| Rear wheel track [mm] | 1599-1609 | |||||
| Forward overhang [mm] | 996 | |||||
| Rear overhang [mm] | 807 | |||||
| Clearance [mm] | - | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | - | |||||
| Headroom rear [mm] | - | |||||
| Front elbow/shoulder width [mm] | - | |||||
| Rear elbow/shoulder width [mm] | - | |||||
| Legroom front knees/total [mm] | - | |||||
| Legroom rear knees/total [mm] | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
