DS DS4

Date of manufacture

2021 – to this day (Medium SUV)

Platform

PSA EMP2

Manufacturing locations

Rüsselsheim am Main, Germany

Designer

Car body style

Medium SUV

Date of manufacture

2021 – to this day

Internal designation

Engine size

Petrol

1.2 Puretech 130

1.6 Puretech 180

1.6 Puretech 225

Petrol + Electric

E-Tense 225

Diesel

1.5 BlueHDI 130

Euro NCAP

Technical data

Medium SUV

	1.2 Puretech 130	1.6 Puretech 180	1.6 Puretech 225	E-Tense 225	1.5 BlueHDI 130
Date of sale	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Petrol supercharged + Electric	Diesel supercharged
Number of cylinders/valves	3/12	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1199	1598	1598	1598	1499
Maximum output / speed [kW/min-1]	96/5500	133/5500	165/5500	133/6000 81/2500 el. 165 total	96/3750
Maximum torque [Nm/min-1]	230/1750	250/1650	300/1900	300/3000 320 el. 360 total	300/1750
Bore and stroke [mm x mm]	75 x 90,5	77,0 x 85,8	77,0 x 85,8	77,0 x 85,8	75.0 x 84,8
Compression ratio	10.5:1	10.2:1	10.2:1	10.2:1	16.4:1
Oil volume [l]	4.4	4.8	4.8	-	4.1
Coolant volume [l]	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged Twinscroll variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged Twinscroll variable timing of intake valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves variable lift of intake valves Gasoline Particulate Filter start&stop system	Plug‐in Hybrid direct injection turbo-supercharged Twinscroll variable timing of intake valves Gasoline Particulate Filter start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	Front	Front	Front	Front	Front
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	eight-speed automatic gearbox	eight-speed automatic gearbox	eight-speed automatic gearbox	eight-speed automatic gearbox	eight-speed automatic gearbox

Top speed [km/h]	210	230	235	233	203
Acceleration 0–100 km/h [s]	9.7	8.0	7.9	7.7	10.9
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	6.0	6,6	6,6	-	4,2
Out of town [l]	4.5	4,7	4,7	-	3,5
Combined [l]	5.1	5,4	5,4	1.4	3,8
CO2 emissions [g/km]	116	123	123	32	100

Low speed [l]	7,7-7,8	8,3-8,6	8,3-8,5	7.7-7.4	5,5-5,7
Medium speed [l]	5,8-6,1	6,5-6,7	6,5-6,7	6.4-6.1	4,6-4,8
High speed [l]	5,1-5,2	5,6-5,7	5,7-6,0	5.8-5.6	4,1-4,2
Extra high speed [l]	6,1-6,3	6,5-6,7	6,8-7,1	7.4-6.9	5,1-5,3
Combined speed [l]	5,9-6,1	6,5-6,7	6,6-6,9	1.4-1.3 [15.2-14.6 kWh]	4,8-4,9
CO2 emissions [g/km]	135-139	146-151	149-155	32-29	125-129

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

System voltage [V]	-	-	-	-	-
Battery type and capacity	-	-	-	Lithium-Ionen-Akkumulator, 12.4 kWh	-
Range with fully charged battery [km]	-	-	-	55 [WLTP]	-
Charging time	-	-	-	to 100%, 7:05 hodiny, charger 1.8 kW to 100%, 3:50 hodiny, charger 3.7 kW from 0% to 100%, 1:55 hours, charger 22 kW AC	-
Number of modules/cells	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-
Charger	-	-	-	7.4 kW on-board charger	-

Standby weight [kg]	1352	1420	1419	1653	1414
Overall weight [kg]	1920	1980	1990	2200	2000
Maximum trailer weight unbraked/braked [kg]	710/1100-1400	740/1600	745/1600	750/1400	740/1500
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	70	71	72	70	73
Maximum load on roof/carrier [kg]	85/-	86/-	87/-	89/-	88/-

Boot volume [l]	430	430	430	390	430
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1240	-/1240	-/1240	-/1240	-/1240
Boot length [mm]	830	830	830	830	830
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-/1104	-/1104	-/1104	-/1104	-/1104
Boot height to headliner/ceiling [mm]	533/-	533/-	533/-	474/-	533/-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	52	52	52	40	53
AdBlue tank volume [l]	-	-	-	-	15
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	215/65 R17 99V	205/55 R19 97V	205/55 R19 97V	215/65 R17 99V	215/65 R17 99V
Tyre dimensions rear	215/65 R17 99V	205/55 R19 97V	205/55 R19 97V	215/65 R17 99V	215/65 R17 99V
Wheel size front	-	-	-	-	-
Wheel size rear	-	-	-	-	-
Brake dimensions front	304 x 28	330 x 28	330 x 28	330 x 28	304 x 28
Brake dimensions rear	268 x 12	290 x 12	290 x 12	290 x 12	268 x 12
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	10.82/-	10.82/-	10.82/-	10.82/-	10.82/-

Overall length [mm]	4400	4400	4400	4400	4400
Overall width without/including mirrors [mm]	1830/2061	1830/2061	1830/2061	1830/2061	1830/2061
Overall height [mm]	1490	1490	1490	1490	1490
Wheelbase [mm]	2675	2675	2675	2675	2675
Front wheel track [mm]	1600	1600	1600	1600	1600
Rear wheel track [mm]	1605	1605	1605	1605	1605
Forward overhang [mm]	925	925	925	925	925
Rear overhang [mm]	800	800	800	800	800
Clearance [mm]	189	189	189	189	189
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-
