Basic information Technical Specifications Gallery

Cupra Born

Date of manufacture

2021 – to this day (Five-door hatchback)

Platform

Volkswagen Group MEB

Manufacturing locations

Zwickau, Germany

Designer

Car body style

Five-door hatchback

Date of manufacture

2021 – to this day

Internal designation

K11

Engine size

150 kW / 62 kWh

Euro NCAP

Technical data

Five-door hatchback

	150 kW / 62 kWh
Date of sale	-
Engine type	Electric
Number of cylinders/valves	-
Engine displacement [cm³]	-
Maximum output / speed [kW/min-1]	150
Maximum torque [Nm/min-1]	310
Bore and stroke [mm x mm]	-
Compression ratio	-
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	electric synchronous motor with permanent magnet

Drive axle	Front
Gearbox	1 gear automatic
Drive specifications	constant ratio gearbox

Top speed [km/h]	160
Acceleration 0–100 km/h [s]	7.3
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	-
Out of town [l]	-
Combined [l]	-
CO2 emissions [g/km]	-

Low speed [l]	-
Medium speed [l]	-
High speed [l]	-
Extra high speed [l]	-
Combined speed [l]	16.8-15.5
CO2 emissions [g/km]	-

Emission standard	-
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	270-459
Battery type and capacity	Lithium-ion, 62 kWh (58 net)
Range with fully charged battery [km]	424 [WLTP]
Charging time	from 0% to 100%, 6:15 hours, charger 11 kW AC from 5% to 80%, 0:35 hours, charger DC 100 kW
Number of modules/cells	-
Battery weight [kg]	-
Charger	120 kW fast charging, 11 kW on-board charger

Standby weight [kg]	1736
Overall weight [kg]	2260
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	385
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	-
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	multilink
Tyre dimensions front	215/55 R 18
Tyre dimensions rear	215/55 R18
Wheel size front	7,5J x 18
Wheel size rear	7,5J x 18
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.15/-

Overall length [mm]	4322
Overall width without/including mirrors [mm]	1809/-
Overall height [mm]	1540
Wheelbase [mm]	2766
Front wheel track [mm]	1537
Rear wheel track [mm]	1514
Forward overhang [mm]	-
Rear overhang [mm]	-
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
