Cupra Ateca

Date of manufacture

2020 – to this day (Medium SUV)

Platform

Volkswagen Group MQB A1

Manufacturing locations

Kvasiny, Czechia

Relizane, Algeria

Designer

Car body style

Medium SUV

Date of manufacture

2020 – to this day

Internal designation

KHP

Engine size

2.0 TSI 300

Technical data

Medium SUV

	2.0 TSI 300
Date of sale	-
Engine type	Ignition supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	1984
Maximum output / speed [kW/min-1]	221/5450-6500
Maximum torque [Nm/min-1]	400/2000-5450
Bore and stroke [mm x mm]	82,5 x 92,8
Compression ratio	9.3:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct and indirect injection system turbo-supercharged variable timing of intake and exhaust valves variable lift of exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation

Drive axle	Front
Gearbox	7 gear automatic
Drive specifications	seven-speed dual-clutch automatic gearbox DSG

Top speed [km/h]	249
Acceleration 0–100 km/h [s]	4.9
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	9.6
Out of town [l]	6.6
Combined [l]	7.7
CO2 emissions [g/km]	175

Low speed [l]	12.8
Medium speed [l]	8.9
High speed [l]	7.7
Extra high speed [l]	8.6
Combined speed [l]	8.9-9.5
CO2 emissions [g/km]	201-215

Emission standard	Euro 6d
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1626
Overall weight [kg]	2170
Maximum trailer weight unbraked/braked [kg]	750/2100
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	80
Maximum load on roof/carrier [kg]	75/-

Boot volume [l]	485
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1579
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	55
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	multilink
Tyre dimensions front	245/40 R19 94W
Tyre dimensions rear	245/40 R19 94W
Wheel size front	8Jx 19 ET45
Wheel size rear	8Jx 19 ET45
Brake dimensions front	340 x 30
Brake dimensions rear	310 x 22
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.8/-

Overall length [mm]	4394
Overall width without/including mirrors [mm]	1841/2078
Overall height [mm]	1599
Wheelbase [mm]	2630
Front wheel track [mm]	1575
Rear wheel track [mm]	1549
Forward overhang [mm]	877
Rear overhang [mm]	879
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	1063
Headroom rear [mm]	1020
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
