Citroën C5 Aircross

Date of manufacture

2018 – to this day (Medium SUV)

Platform

PSA EMP2

Manufacturing locations

Rennes, France

Designer

Car body style

Medium SUV

Date of manufacture

2018 – to this day

Internal designation

Engine size

Petrol

1.2 PureTech 130

1.6 PureTech 180

Petrol + Electric

HYBRID ë-EAT8

Diesel

1.5 BlueHDi 130

2.0 BlueHDI 180

Euro NCAP

Technical data

Medium SUV

	1.2 PureTech 130	1.2 PureTech 130	1.6 PureTech 180	HYBRID ë-EAT8	1.5 BlueHDi 130	1.5 BlueHDi 130
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Petrol supercharged + Electric	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	3/12	3/12	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1199	1199	1598	1598	1499	1499
Maximum output / speed [kW/min-1]	96/5500	96/5500	133/5500	133/600 81/2500 el. 165 total	96/3750	96/3750
Maximum torque [Nm/min-1]	230/1750	230/1750	250/1650	300/3000 320/500-2500 el. 360 total	300/1750	300/1750
Bore and stroke [mm x mm]	75,0 x 90,5	75,0 x 90,5	77.0 x 85.8	77.0 x 85.8	75 x 84,8	75 x 84,8
Compression ratio	10.5:1	10.5:1	10.8:1	10.5:1	16.5:1	16.5:1
Oil volume [l]	4.4	4.4	4.8	4.8	4.1	4.1
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves variable lift of intake valves Gasoline Particulate Filter start&stop system	Plug‐in Hybrid direct injection turbo-supercharged variable timing of intake and exhaust valves variable lift of intake valves Gasoline Particulate Filter start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	6 gear manual	8 gear automatic	8 gear automatic	8 gear automatic	6 gear manual	8 gear automatic
Drive specifications	-	eight-speed automatic gearbox EAT8	eight-speed automatic gearbox EAT8	eight-speed automatic gearbox EAT8	-	eight-speed automatic gearbox EAT8

Top speed [km/h]	195	196	216	225 [135 el.]	188	189
Acceleration 0–100 km/h [s]	10.5	10.3	8.2	8.9	10.4	10.6
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.1-6.0	6.1	7.2-7.0	-	4.8-4.4	4.5-4.4
Out of town [l]	4.9-4.7	4.8	5.0-4.8	-	3.9-3.7	4.0-3.8
Combined [l]	5.3-5.2	5.3	5.8-5.6	1.6	4.3-3.9	4.2-4.1
CO2 emissions [g/km]	118	120	128-125	36	106-104	107

Low speed [l]	7.4-7.3	8.2-8.1	9.0-8.8	-	5.2-5.1	6.2-6.0
Medium speed [l]	6.3-6.2	6.5-6.4	6.9-6.7	-	4.8-4.7	5.3-5.1
High speed [l]	5.6-5.6	5.7-5.5	6.0-5.9	-	4.5-4.4	4.5-4.4
Extra high speed [l]	6.9	7.2-6.9	7.2-7.0	-	5.7-5.6	5.7-5.6
Combined speed [l]	6.5-6.4	6.7-6.6	7.0-6.9	1.4 [15.8-15.6 kWh]	5.1-4.9	5.1-4.9
CO2 emissions [g/km]	145-147	151-147	158-155	31-33	133-130	133-130

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	-	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	-	-	-	200	-	-
Battery type and capacity	-	-	-	Lithium-Ionen-Akkumulator, 13.2 kWh	-	-
Range with fully charged battery [km]	-	-	-	55-64	-	-
Charging time	-	-	-	to 100%, 7:20 hodiny, charger 1.8 kW to 100%, 3:40 hodiny, charger 3.7 kW to 100%, 1:50 hodiny, charger 7.4 kW 32A	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1490-1622	1505-1637	1505-1634	1845-1942	1505-1659	1574-1710
Overall weight [kg]	1940	1960	1990	2300	2000	2030
Maximum trailer weight unbraked/braked [kg]	740/1350	740/1300	750/1500	750/1300	750/1450	750/1250
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	65	65	65	65	65	65
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	580/720	580/720	580/720	460-600	580/720	580/720
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1630	-/1630	-/1630	-/1510	-/1630	-/1630
Boot length [mm]	999	999	999	999	999	999
Boot length with rear seats folded [mm]	1907	1907	1907	1907	1907	1907
Boot width between wheels/max [mm]	1053/-	1053/-	1053/-	1053/-	1053/-	1053/-
Boot height to headliner/ceiling [mm]	474/583	474/583	474/583	474/583	474/583	474/583
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	53	53	53	43	53	53
AdBlue tank volume [l]	-	-	-	-	17	17
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	multilink	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	215/65 R17	215/65 R17	215/65 R17	225/55 R18	215/65 R17	215/65 R17
Tyre dimensions rear	215/65 R17	215/65 R17	215/65 R17	225/55 R18	215/65 R17	215/65 R17
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10,7/-	10,7/-	10,7/-	10,7/-	10,7/-	10,7/-

Overall length [mm]	4500	4500	4500	4500	4500	4500
Overall width without/including mirrors [mm]	-/2099	-/2099	-/2099	-/2099	-/2099	-/2099
Overall height [mm]	1654	1654	1654	1654	1654	1654
Wheelbase [mm]	2730	2730	2730	2730	2730	2730
Front wheel track [mm]	1579-1601	1579-1601	1579-1601	1579-1601	1579-1601	1579-1601
Rear wheel track [mm]	1608-1630	1608-1630	1608-1630	1608-1630	1608-1630	1608-1630
Forward overhang [mm]	917	917	917	917	917	917
Rear overhang [mm]	853	853	853	853	853	853
Clearance [mm]	230	230	230	230	230	230
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.0 BlueHDI 180
Date of sale	from to 2020
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	1997
Maximum output / speed [kW/min-1]	133/3750
Maximum torque [Nm/min-1]	400/2000
Bore and stroke [mm x mm]	85,0 x 88,0
Compression ratio	16.7:1
Oil volume [l]	5.1
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	Front
Gearbox	8 gear automatic
Drive specifications	eight-speed automatic gearbox EAT8

Top speed [km/h]	211
Acceleration 0–100 km/h [s]	8.6
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	5.3-5.2
Out of town [l]	4.6-4.5
Combined [l]	4.9-4.7
CO2 emissions [g/km]	124

Emission standard	Euro 6d-TEMP
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	-
Overall weight [kg]	2110
Maximum trailer weight unbraked/braked [kg]	750/1650
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	65
Maximum load on roof/carrier [kg]	-

Boot volume [l]	580/720
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1630
Boot length [mm]	999
Boot length with rear seats folded [mm]	1907
Boot width between wheels/max [mm]	1053/-
Boot height to headliner/ceiling [mm]	474/583
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	53
AdBlue tank volume [l]	17
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	twist beam axle with trailing arms
Tyre dimensions front	215/65 R17
Tyre dimensions rear	215/65 R17
Wheel size front	-
Wheel size rear	-
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10,7/-

Overall length [mm]	4500
Overall width without/including mirrors [mm]	-/2099
Overall height [mm]	1654
Wheelbase [mm]	2730
Front wheel track [mm]	1579-1601
Rear wheel track [mm]	1608-1630
Forward overhang [mm]	917
Rear overhang [mm]	853
Clearance [mm]	230
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Citroen C5 Aircross 2018 rear folding seats

citroen c5 aircross hybrid 2020 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
