Citroën C4
Date of manufacture
2010 – 2015 (Five-door hatchback)
Platform
PSA PF2 platform
Manufacturing locations
Mulhouse, France
Kaluga, Russia
Designer
-
Tags
C-segment
French cars
The new Citroën C4 is available in a five-door hatchback version. The car was launched in 2010 and is produced in France and Russia on the PSA PF2 platform. The engine range includes petrol and diesel engines, the most powerful of which is the 1.6 THP with 115 kW. The top speed is 214 km/h and the lowest fuel consumption of 3.7 l/100 km applies to the 1.6 e-HDi Airdream with CO2 emissions of 95 g/km. The luggage compartment has a capacity of 380 l. The Citroën C4 model received a rating of 5 out of 5 during the EURONCAP safety tests in 2010.
Car body style
Five-door hatchback
Date of manufacture
2010 – 2015Internal designation
B7
Technical data
Five-door hatchback
| 1.4 VTi | 1.6 VTi | 1.6 VTi | 1.2 e-THP | 1.6 THP | 1.6 HDi | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Ignition supercharged | Ignition supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 3/12 | 4/16 | 4/8 |
| Engine displacement [cm³] | 1397 | 1598 | 1598 | 1199 | 1598 | 1560 |
| Maximum output / speed [kW/min-1] | 70/6000 | 88/6000 | 88/6000 | 96/5500 | 115/6000 | 68/4000 |
| Maximum torque [Nm/min-1] | 135/4000 | 160/4250 | 160/4250 | 230/1750 | 240/1400-4000 | 230/1750 |
| Bore and stroke [mm x mm] | 77,0 x 75,0 | 77,0 x 85,5 | 77,0 x 85,5 | 75,0 x 90,5 | 77,0 x 85,8 | 75,0 x 88,3 |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear manual | 4 gear automatic | 6 gear manual | 6 gear robotic manual | 5 gear manual |
| Drive specifications | - | - | - | - |
| - |
| Top speed [km/h] | 182 | 193 | 188 | 199 | 214 | 180 |
| Acceleration 0–100 km/h [s] | 11.9 | 10.8 | 12.5 | 10.8 | 8.7 | 12.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8.2 | 8.8 | 10.0 | 5.9 | 8.4 | 4.9 |
| Out of town [l] | 4.9 | 4.7 | 5.1 | 4.2 | 5.0 | 3.6 |
| Combined [l] | 6.1 | 6.2 | 6.9 | 4.8 | 6.3 | 4.1 |
| CO2 emissions [g/km] | 140 | 143 | 159 | 110 | 145 | 106 |
| Emission standard | EU5 | EU5 | EU5 | EU6 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1255 | 1295 | 1305 | 1205 | 1345 | 1313 |
| Overall weight [kg] | 1720 | 1765 | 1755 | 1790 | 1805 | 1790 |
| Maximum trailer weight unbraked/braked [kg] | 635/1450 | 640/1550 | 670/155 | 640/1550 | 675/1650 | 640/1350 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | -/55 | -/55 | -/55 | -/55 | -/55 | -/55 |
| Boot volume [l] | 380 | 380 | 380 | 380 | 380 | 380 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1183 | -/1183 | -/1183 | -/1183 | -/1183 | -/1183 |
| Boot length [mm] | 877 | 877 | 877 | 877 | 877 | 877 |
| Boot length with rear seats folded [mm] | 1565 | 1565 | 1565 | 1565 | 1565 | 1565 |
| Boot width between wheels/max [mm] | -/1027 | -/1027 | -/1027 | -/1027 | -/1027 | -/1027 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser |
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar |
| Tyre dimensions front | 195/65 R15 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 195/65 R15 |
| Tyre dimensions rear | 195/65 R15 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 195/65 R15 |
| Wheel size front | 6.5 J x 15 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 6.5 J x 15 |
| Wheel size rear | 6.5 J x 15 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 6.5 J x 15 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.2 | 11.2 | 11.2 | 11.2 | 11.2 | 11.2 |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1789/2050 | 1789/2050 | 1789/2050 | 1789/2050 | 1789/2050 | 1789/2050 |
| Overall height [mm] | 1489 | 1489 | 1489 | 1489 | 1489 | 1489 |
| Wheelbase [mm] | 2608 | 2608 | 2608 | 2608 | 2608 | 2608 |
| Front wheel track [mm] | 1522 | 1522 | 1522 | 1522 | 1522 | 1522 |
| Rear wheel track [mm] | 1515 | 1515 | 1515 | 1515 | 1515 | 1515 |
| Forward overhang [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Rear overhang [mm] | 786 | 786 | 786 | 786 | 786 | 786 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 904 | 904 | 904 | 904 | 904 | 904 |
| Headroom rear [mm] | 860 | 860 | 860 | 860 | 860 | 860 |
| Front elbow/shoulder width [mm] | 1457/- | 1457/- | 1457/- | 1457/- | 1457/- | 1457/- |
| Rear elbow/shoulder width [mm] | 1451/- | 1451/- | 1451/- | 1451/- | 1451/- | 1451/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.6 HDi | 1.6 e-HDi Airdream | 1.6 e-HDi Airdream | 1.6 e-HDi Airdream | 2.0 HDi | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/8 | 4/8 | 4/8 | 4/8 | 4/16 | |
| Engine displacement [cm³] | 1560 | 1560 | 1560 | 1560 | 1997 | |
| Maximum output / speed [kW/min-1] | 82/3600 | 82/3600 | 84/3600 | 84/3600 | 110/3750 | |
| Maximum torque [Nm/min-1] | 270/2000 | 270/2000 | 270/2000 | 270/2000 | 340/2000-2750 | |
| Bore and stroke [mm x mm] | 75,0 x 88,3 | 75,0 x 88,3 | 75,0 x 88,3 | 75,0 x 88,3 | 85,0 x 88,0 | |
| Compression ratio | - | - | - | - | - | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Front | Front | Front | Front | Front | |
| Gearbox | 6 gear manual | 6 gear robotic manual | 6 gear manual | 6 gear robotic manual | 6 gear manual | |
| Drive specifications | - |
| - |
| - | |
| Top speed [km/h] | 190 | 190 | 190 | 190 | 207 | |
| Acceleration 0–100 km/h [s] | 11.3 | 11.2 | 11.3 | 11.2 | 8.6 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 5.8 | 4.7 | 4.3 | 4.2 | 6.5 | |
| Out of town [l] | 3.9 | 3.8 | 3.3 | 3.5 | 4.0 | |
| Combined [l] | 4.6 | 4.2 | 3.7 | 3.8 | 4.9 | |
| CO2 emissions [g/km] | 119 | 109 | 95 | 98 | 127 | |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | - | - | 1373 | 1365 | 1426 | |
| Overall weight [kg] | 1810 | 1825 | 1825 | 1825 | 1885 | |
| Maximum trailer weight unbraked/braked [kg] | 675/1550 | 680/1550 | 675/1550 | 635/1550 | 695/1885 | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | |
| Maximum load on roof/carrier [kg] | -/55 | -/55 | -/55 | -/55 | -/55 | |
| Boot volume [l] | 380 | 380 | 380 | 380 | 380 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1183 | -/1183 | -/1183 | -/1183 | -/1183 | |
| Boot length [mm] | 877 | 877 | 877 | 877 | 877 | |
| Boot length with rear seats folded [mm] | 1565 | 1565 | 1565 | 1565 | 1565 | |
| Boot width between wheels/max [mm] | -/1027 | -/1027 | -/1027 | -/1027 | -/1027 | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | - | - | - | - | - | |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | |
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar | |
| Tyre dimensions front | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | |
| Tyre dimensions rear | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | 205/55 R16 | |
| Wheel size front | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | |
| Wheel size rear | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | 7 J x 16 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.2 | 11.2 | 11.2 | 11.2 | 11.2 | |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | |
| Overall width without/including mirrors [mm] | 1789/2050 | 1789/2050 | 1789/2050 | 1789/2050 | 1789/2050 | |
| Overall height [mm] | 1489 | 1489 | 1489 | 1489 | 1489 | |
| Wheelbase [mm] | 2608 | 2608 | 2608 | 2608 | 2608 | |
| Front wheel track [mm] | 1522 | 1522 | 1522 | 1522 | 1522 | |
| Rear wheel track [mm] | 1515 | 1515 | 1515 | 1515 | 1515 | |
| Forward overhang [mm] | 935 | 935 | 935 | 935 | 935 | |
| Rear overhang [mm] | 786 | 786 | 786 | 786 | 786 | |
| Clearance [mm] | - | - | - | - | - | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | - | - | - | - | - | |
| Approach angle rear [°] | - | - | - | - | - | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 904 | 904 | 904 | 904 | 904 | |
| Headroom rear [mm] | 860 | 860 | 860 | 860 | 860 | |
| Front elbow/shoulder width [mm] | 1457/- | 1457/- | 1457/- | 1457/- | 1457/- | |
| Rear elbow/shoulder width [mm] | 1451/- | 1451/- | 1451/- | 1451/- | 1451/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
