Citroën C3 Aircross

Date of manufacture

2021 – to this day (Small SUV)

Platform

PSA PF1

Manufacturing locations

Zaragoza, Spain

Designer

Car body style

Small SUV

Date of manufacture

2021 – to this day

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Test year 2017

pre-facelift version (2017)

Technical data

Small SUV

	1.2 PureTech 110	1.2 PureTech 130	1.5 BlueHDi 110	1.5 BlueHDi 120
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	3/12	3/12	4/16	4/16
Engine displacement [cm³]	1199	1199	1499	1499
Maximum output / speed [kW/min-1]	81/5500	96/5500	81/3750	88/3750
Maximum torque [Nm/min-1]	205/1500	230/1750	250/1750	300/1750
Bore and stroke [mm x mm]	75,0 x 90,5	75,0 x 90,5	75,0 x 88,3	75 x 84,8
Compression ratio	10,5:1	10,5:1	16.5:1	16.5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter with AdBlue additive injection start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	-	six-speed automatic gearbox	-	six-speed automatic gearbox EAT6

Top speed [km/h]	183	195	184	179
Acceleration 0–100 km/h [s]	11,5	10,3	12,1	10,8
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5.9	5.9	4.2	4.4
Out of town [l]	4.2	4.5	3.2	3.7
Combined [l]	4.8	5.0	3.6	3.9
CO2 emissions [g/km]	110	114	94	104

Low speed [l]	7,0-6,8	7,9-7,7	5,0-4,8	5,8-5,6
Medium speed [l]	5,8-5,5	6,2-6,0	4,5-4,3	4,8-4,7
High speed [l]	5,3-5,0	5,4-5,2	4,3-4,1	4,4-4,3
Extra high speed [l]	6,6-6,2	6,7-6,4	5,4-5,2	5,7-5,5
Combined speed [l]	6,1-5,8	6,3-6,1	4,8-4,6	5,1-5,0
CO2 emissions [g/km]	138-132	143-139	126-122	135-131

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1254-1410	1280-1459	1280-1458	1335-1487
Overall weight [kg]	1795	1835	1835	1860
Maximum trailer weight unbraked/braked [kg]	600/840	600/840	620/840	640/870
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	65	65	65	55
Maximum load on roof/carrier [kg]	40/-	40/-	40/-	40/-

Boot volume [l]	410	410	410	410
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1289	-/1289	-/1289	-/1289
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	7
Fuel tank volume [l]	45	45	45	45
AdBlue tank volume [l]	-	-	17	17
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	205/60 R16	205/60 R16	205/60 R16	205/60 R17
Tyre dimensions rear	205/60 R16	205/60 R16	205/60 R16	205/60 R17
Wheel size front	-	-	-	-
Wheel size rear	-	-	-	-
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10,8/-	10,8/-	10,8/-	10,8/-

Overall length [mm]	4160	4160	4160	4160
Overall width without/including mirrors [mm]	1756/1976	1756/1976	1756/1976	1756/1976
Overall height [mm]	1597	1597	1597	1597
Wheelbase [mm]	2604	2604	2604	2604
Front wheel track [mm]	1513	1513	1513	1513
Rear wheel track [mm]	1491	1491	1491	1491
Forward overhang [mm]	842	842	842	842
Rear overhang [mm]	714	714	714	714
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Citroen C3 Aircross facelift 2021 interior

Citroen C3 Aircross facelift 2021 infotainment

Citroen C3 Aircross facelift 2021 front seats

Citroen C3 Aircross facelift 2021 rear seats

Citroen C3 Aircross facelift 2021 boot volume 410 l

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
