Citroën C-Elysée

Date of manufacture

11/2012 – 2016 (Sedan)

Platform

PSA PF1 platform

Manufacturing locations

Vigo, Spain

Designer

Car body style

Sedan

Date of manufacture

11/2012 – 2016

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Sedan

	1.2 VTI	1.2 VTI	1.2 PureTech 82	1.2 PureTech 82	1.6 VTI	1.6 VTI
Date of sale	from to 2014	from to 2014	from to 2015	from 2015 to	-	from to 2014
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	3/12	3/12	3/12	3/12	4/16	4/16
Engine displacement [cm³]	1199	1199	1199	1199	1587	1587
Maximum output / speed [kW/min-1]	53/5500	53/5500	59/5750	59/5750	85/6050	85/6050
Maximum torque [Nm/min-1]	110/3000	110/3000	117/2750	117/2750	150/4000	150/4000
Bore and stroke [mm x mm]	75,0 x 90,5	75,0 x 90,5	75,0 x 90,5	75,0 x 90,5	78,5 x 82,0	78,5 x 82,0
Compression ratio	11,0:1	11,0:1	-	-	11,1:1	11,1:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves	variable timing of intake valves	variable timing of intake valves	variable timing of intake valves start&stop system	variable timing of intake valves	variable timing of intake valves

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear robotic manual	5 gear manual	5 gear robotic manual	5 gear manual	4 gear automatic
Drive specifications	-	robotic gearbox ETG (automatic or manual mode)	-	robotic gearbox ETG (automatic or manual mode)	-	automatic gearbox

Top speed [km/h]	160	160	168	169	188	188
Acceleration 0–100 km/h [s]	14.2	16.3	12.9	15.3	9.4	10.8
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.9	6.4	6.0	4.9	8.7	10.0
Out of town [l]	4.2	4.3	4.3	3.9	5.1	5.5
Combined [l]	5.2	5.1	4.9	4.3	6.4	7.1
CO2 emissions [g/km]	119	116	114	99	148	164

Emission standard	EU5	EU5	EU6	EU6	EU5 - EU6	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1020	1020	1055	1055	1165	1110
Overall weight [kg]	1459	1467	1470	1490	1524	1559
Maximum trailer weight unbraked/braked [kg]	450/720	450/720	450/720	450/720	580/1010	600/1010
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-/55	-/55	-/55	-/55	-/55	-/55

Boot volume [l]	506	506	506	506	506	506
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	1091	1091	1091	1091	1091	1091
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-/1032	-/1032	-/1032	-/1032	-/1032	-/1032
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	50	50	50	50	50	50
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.32	0.32	0.32	0.32	0.32	0.32
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Wheel size front	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23
Wheel size rear	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23
Brake dimensions front	266x13	266x13	266x13	266x13	266x22	266x22
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.9	10.9	10.9	10.9	10.9	10.9

Overall length [mm]	4427	4427	4427	4427	4427	4427
Overall width without/including mirrors [mm]	1748/-	1748/-	1748/-	1748/-	1748/-	1748/-
Overall height [mm]	1466	1466	1466	1466	1466	1466
Wheelbase [mm]	2652	2652	2652	2652	2652	2652
Front wheel track [mm]	1501	1501	1501	1501	1501	1501
Rear wheel track [mm]	1478	1478	1478	1478	1478	1478
Forward overhang [mm]	808	808	808	808	808	808
Rear overhang [mm]	967	967	967	967	967	967
Clearance [mm]	142	142	142	142	139	138
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	892	892	892	892	892	892
Headroom rear [mm]	848	848	848	848	848	848
Front elbow/shoulder width [mm]	1409/-	1409/-	1409/-	1409/-	1409/-	1409/-
Rear elbow/shoulder width [mm]	1395/-	1395/-	1395/-	1395/-	1395/-	1395/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.6 VTI	1.6 HDI	1.6 BlueHDi 100
Date of sale	from 2015 to	from to 2014	from 2015 to
Engine type	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/8	4/8
Engine displacement [cm³]	1587	1560	1560
Maximum output / speed [kW/min-1]	85/6050	68/4000	73/3750
Maximum torque [Nm/min-1]	150/4000	230/1750	245/1750
Bore and stroke [mm x mm]	78,5 x 82,0	75,0 x 88,3	75,0 x 88,3
Compression ratio	11,1:1	16,0:1	-
Oil volume [l]	-	-	-
Coolant volume [l]	-	-	-
Technical specifications	variable timing of intake valves	direct injection Common Rail turbo-supercharged particulate filter	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter with AdBlue additive injection

Drive axle	Front	Front	Front
Gearbox	6 gear automatic	5 gear manual	5 gear manual
Drive specifications	six-speed automatic gearbox	-	-

Top speed [km/h]	180	180	180
Acceleration 0–100 km/h [s]	11.1	11.2	10.8
Acceleration 0–80 km/h [s]	-	-	-
Acceleration 80–120 km/h [s]	-	-	-

City [l]	9.2	4.8	4.6
Out of town [l]	5.3	3.7	3.3
Combined [l]	6.8	4.1	3.8
CO2 emissions [g/km]	157	108	98

Emission standard	EU6	EU5	EU6
Standard for fuel consumption measurement	-	-	-
Energy class	-	-	-
Stationary vehicle noise [dB]	-	-	-
Driving noise [dB]	-	-	-

Standby weight [kg]	1190	1095	1165
Overall weight [kg]	1585	1548	1585
Maximum trailer weight unbraked/braked [kg]	580/1010	580/1010	580/1010
Maximum front/rear axle load [kg]	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-
Maximum load on roof/carrier [kg]	-/75	-/55	-/55

Boot volume [l]	506	506	506
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-
Boot length [mm]	1091	1091	1091
Boot length with rear seats folded [mm]	-	-	-
Boot width between wheels/max [mm]	-/1032	-/1032	-/1032
Boot height to headliner/ceiling [mm]	-	-	-
Loading edge height [mm]	-	-	-
Height of the open boot door [mm]	-	-	-
Boot opening height [mm]	-	-	-
Boot opening width min/max [mm]	-	-	-

Number of doors	4	4	4
Number of seats	5	5	5
Fuel tank volume [l]	50	50	50
AdBlue tank volume [l]	-	-	-
Air resistance [Cd]	0.32	0.32	0.32
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	torsion bar	torsion bar	torsion bar
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15
Wheel size front	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23
Wheel size rear	6.0J x 15 E23	6.0J x 15 E23	6.0J x 15 E23
Brake dimensions front	266x22	266x22	266x22
Brake dimensions rear	-	-	-
Steering	-	-	-
Number of steering wheel turns	-	-	-
Turning diameter track/circumference [m]	10.9	10.9	10.9

Overall length [mm]	4427	4427	4427
Overall width without/including mirrors [mm]	1748/-	1748/-	1748/-
Overall height [mm]	1466	1466	1466
Wheelbase [mm]	2652	2652	2652
Front wheel track [mm]	1501	1501	1501
Rear wheel track [mm]	1478	1478	1478
Forward overhang [mm]	808	808	808
Rear overhang [mm]	967	967	967
Clearance [mm]	139	139	139
Wading depth [mm]	-	-	-
Approach angle front [°]	-	-	-
Approach angle rear [°]	-	-	-
Transition angle [°]	-	-	-
Climbing rate [°]	-	-	-
Maximum side tilt [°]	-	-	-

Headroom front [mm]	892	892	892
Headroom rear [mm]	848	848	848
Front elbow/shoulder width [mm]	1409/-	1409/-	1409/-
Rear elbow/shoulder width [mm]	1395/-	1395/-	1395/-
Legroom front knees/total [mm]	-	-	-
Legroom rear knees/total [mm]	-	-	-

Gallery

Citroen C-Elysee 2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
