Citroën C-Crosser

Date of manufacture

2/2007 – 2012 (SUV)

Platform

Mitsubishi GS platform

Manufacturing locations

Okazaki, Japan

Kaluga, Russia

Designer

Car body style

SUV

Date of manufacture

2/2007 – 2012

Internal designation

Engine size

2.2 HDI 16V

Technical data

SUV

	2.2 HDI 16V	2.2 HDI 16V	2.2 HDI 16V	2.2 HDI 16V
Date of sale	-	-	-	-
Engine type	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2179	2179	2179	2179
Maximum output / speed [kW/min-1]	115/4000	115/4000	115/4000	115/4000
Maximum torque [Nm/min-1]	380/2000	380/2000	380/2000	380/2000
Bore and stroke [mm x mm]	85,0 x 96,0	85,0 x 96,0	85,0 x 96,0	85,0 x 96,0
Compression ratio	-	-	-	-
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4	4x4	4x4
Gearbox	6 gear manual	6 gear manual	6 gear automatic	6 gear automatic
Drive specifications	all-wheel drive (modes )	all-wheel drive (modes )	all-wheel drive (modes ) dual-clutch automatic gearbox DCS	all-wheel drive (modes ) dual-clutch automatic gearbox DCS

Top speed [km/h]	200	200	198	198
Acceleration 0–100 km/h [s]	9.9	9.9	11.1	11.1
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	9.5	9.0	9.3	9.3
Out of town [l]	5.9	5.9	6.1	6.0
Combined [l]	7.2	7.0	7.3	7.2
CO2 emissions [g/km]	191	185	192	189

Emission standard	EU4	EU5	EU4	EU5
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1715	1715	1735	1735
Overall weight [kg]	2410	2410	2410	2410
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2000	750/2000	750/2000
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-/80	-/80	-/80	-/80

Boot volume [l]	441-510	441-510	441-510	441-510
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1686	-/1686	-/1686	-/1686
Boot volume, third row of seats [l]	-	-	-	-
Boot volume, third row seats folded [l]	-	-	-	-
Boot length [mm]	970	970	970	970
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5.7	5.7	5.7	5.7
Fuel tank volume [l]	60	60	60	60
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser	MacPherson, coil springs, hydraulic shock absorbers, torsion stabiliser
Rear suspension	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar
Tyre dimensions front	215/70 R16	215/70 R16	215/70 R16	215/70 R16
Tyre dimensions rear	215/70 R16	215/70 R16	215/70 R16	215/70 R16
Wheel size front	6.5 J x16	6.5 J x16	6.5 J x16	6.5 J x16
Wheel size rear	6.5 J x16	6.5 J x16	6.5 J x16	6.5 J x16
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	-	-	-	-

Overall length [mm]	4646	4646	4646	4646
Overall width without/including mirrors [mm]	1806/-	1806/-	1806/-	1806/-
Overall height [mm]	1713	1713	1713	1713
Wheelbase [mm]	2670	2670	2670	2670
Front wheel track [mm]	1540	1540	1540	1540
Rear wheel track [mm]	1540	1540	1540	1540
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	174	174	174	174
Wading depth [mm]	-	-	-	-
Approach angle front [°]	22	22	22	22
Approach angle rear [°]	21	21	21	21
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	996	996	996	996
Headroom rear [mm]	917	917	917	917
Front elbow/shoulder width [mm]	1486/-	1486/-	1486/-	1486/-
Rear elbow/shoulder width [mm]	1480/-	1480/-	1480/-	1480/-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-
Third row of seats, headroom [mm]	785	785	785	785
Third row elbow/shoulder width [mm]	-	-	-	-

Gallery

Citroen C-Crosser 2007-2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
