Chevrolet Camaro

Date of manufacture

3/2009 – 2013 (Coupé)

1/2011 – 2013 (Convertible)

Platform

GM Zeta platform

Manufacturing locations

Oshawa, Canada

Designer

Sangyup Lee

Tom Peters

Car body style

Coupé

Date of manufacture

3/2009 – 2013

Internal designation

Engine size

6.2L V8

Convertible

Date of manufacture

1/2011 – 2013

Internal designation

Engine size

6.2L V8

Technical data

Coupé

	6.2L V8	6.2L V8
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	8/16	8/16
Engine displacement [cm³]	6162	6162
Maximum output / speed [kW/min-1]	318/5900	298/5900
Maximum torque [Nm/min-1]	569/4600	556/4300
Bore and stroke [mm x mm]	103,25 x 92,00	103,25 x 92,00
Compression ratio	10,7:1	10,4:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	-	variable valve timing Active Fuel Management (automatic cylinder shutdown at partial load)

Drive axle	Rear	Rear
Gearbox	6 gear manual	6 gear automatic
Drive specifications	gearbox Tremec TR6060	automatic gearbox Hydra-Matic 6L80

Top speed [km/h]	250	250
Acceleration 0–100 km/h [s]	5.2	5.4
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	20.9	18.9
Out of town [l]	10.2	9.7
Combined [l]	14.1	13.1
CO2 emissions [g/km]	329	304

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1844	1795
Overall weight [kg]	2200	2200
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	364	364
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	4	4
Fuel tank volume [l]	72	72
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	double wishbone, coil springs	double wishbone, coil springs
Rear suspension	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar
Tyre dimensions front	245/45 ZR20 103 Y	245/45 ZR20 103 Y
Tyre dimensions rear	275/40 ZR20 106 Y	275/40 ZR20 106 Y
Wheel size front	8.0J x 20	8.0J x 20
Wheel size rear	9.0J x 20	9.0J x 20
Brake dimensions front	355 x 32	355 x 32
Brake dimensions rear	365 x 28	365 x 28
Steering	Rack & pinion with variable effect hydraulic power steering	Rack & pinion with variable effect hydraulic power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	11.6/-	11.6/-

Overall length [mm]	4837	4837
Overall width without/including mirrors [mm]	1917/-	1917/-
Overall height [mm]	1360	1360
Wheelbase [mm]	2852	2852
Front wheel track [mm]	1618	1618
Rear wheel track [mm]	1618	1618
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	950	950
Headroom rear [mm]	897	897
Front elbow/shoulder width [mm]	-/1444	-/1444
Rear elbow/shoulder width [mm]	-/1080	-/1080
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Convertible

	6.2L V8	6.2L V8
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	8/16	8/16
Engine displacement [cm³]	6162	6162
Maximum output / speed [kW/min-1]	318/5900	298/5900
Maximum torque [Nm/min-1]	569/4600	556/4300
Bore and stroke [mm x mm]	103,25 x 92,00	103,25 x 92,00
Compression ratio	10,7:1	10,4:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	-	variable valve timing Active Fuel Management (automatic cylinder shutdown at partial load)

Drive axle	Rear	Rear
Gearbox	6 gear manual	6 gear automatic
Drive specifications	gearbox Tremec TR6060	automatic gearbox Hydra-Matic 6L80

Top speed [km/h]	250	250
Acceleration 0–100 km/h [s]	5.4	5.6
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	20.9	18.9
Out of town [l]	10.2	9.7
Combined [l]	14.1	13.1
CO2 emissions [g/km]	329	304

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1965	1995
Overall weight [kg]	2300	2300
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	364	267-308
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	4	4
Fuel tank volume [l]	72	72
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	double wishbone, coil springs	double wishbone, coil springs
Rear suspension	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar
Tyre dimensions front	245/45 ZR20 103 Y	245/45 ZR20 103 Y
Tyre dimensions rear	275/40 ZR20 106 Y	275/40 ZR20 106 Y
Wheel size front	8.0J x 20	8.0J x 20
Wheel size rear	9.0J x 20	9.0J x 20
Brake dimensions front	355 x 32	355 x 32
Brake dimensions rear	365 x 28	365 x 28
Steering	Rack & pinion with variable effect hydraulic power steering	Rack & pinion with variable effect hydraulic power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	11.6/-	11.6/-

Overall length [mm]	4837	4837
Overall width without/including mirrors [mm]	1917/-	1917/-
Overall height [mm]	1379	1379
Wheelbase [mm]	2852	2852
Front wheel track [mm]	1618	1618
Rear wheel track [mm]	1618	1618
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	960	960
Headroom rear [mm]	908	908
Front elbow/shoulder width [mm]	-/1444	-/1444
Rear elbow/shoulder width [mm]	-/1079	-/1079
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-
